Cassida PRO Series Service Manual

Cassida PRO Series Service Manual

2-pocket currency discriminator
Hide thumbs Also See for PRO Series:

Advertisement

Quick Links

Download this manual See also: User Manual
Zeus
2-POCKET CURRENCY
DISCRIMINATOR
SERVICE MANUAL
· Trou les ooting ui e
CassidaPRO Zeus: Service Manual
Rev: 09/05/2018
cassidapro.com/partner/
2018 Cassida Corporation. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PRO Series and is the answer not in the manual?

Questions and answers

Related Manuals for Cassida PRO Series

Summary of Contents for Cassida PRO Series

  • Page 1 Zeus 2-POCKET CURRENCY DISCRIMINATOR SERVICE MANUAL · Trou les ooting ui e CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 2 B.) Check ‘Upper Door’ (PS1) and ‘Lower Door’ (PS2) C.) ‘1’ means the door is open. If all the doors are closed but the level is ‘1’, then the sensor is not working. [Fig. 2] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 3 C.) Normal levels: Door open: < 1V (typically < 0.5V) ii. Door closed: > 4.0V (typically 4.5~4.8V) D.) Abnormal levels Door open: > 2.7V ii. Door closed: < 3.2V CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 4 Quality -> [4] Scanned Image. F.) If all the images are correctly received from the CIS sensor as in [Fig. 2], then test the machine with additional bills. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 5 Replace the CIS which is currently installed in the machine G.) Otherwise if the image looks like [Fig. 4] ii.) Replace the PBA_MAIN board H.) Calibrate CIS (R) and CIS (T) once unit is reassembled CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 6 ID ERROR bill rejection may occur. [Fig. 1] has green lines in the background caused by improper IR illumination while [Fig. 2] is displaying correctly. In tandem, attempting a calibration will likely fail. [Fig. 1] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 7 Causes and Solution: 1. Poor connections to the harness between the UV light source and Mecha PBA A.) Reseat the connectors B.) Re-calibrate [Fig. 3] [Fig. 4] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 8 A.) Gently pull on each wire in the connector. All wires should be securely clipped into the plastic connector B.) If a wire connector is not clipped into the connector, then it looks like the below picture. [Fig. 6] GOOD CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 9 B.) Replace the Main board with the original board C.) Replace the Mecha board. D.) Power on unit and check if error has resolved E.) Adjust Double level CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 10 After initialization, an emergency or failure message will splash to the main screen 2. Emergency screen pops up – NEVER press the [EXIT] button CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
  • Page 11 • Incorrect date or date reset to 1970 after shutdown • Occasional need to power cycle unit several times to start up unit • All modes reset back to default CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.

  • Page 12: Return Merchandise Authorization

    APX IV RETURN MERCHANDISE AUTHORIZATION In order to begin the process of a return (and repair or exchange), Cassida PRO Tech Support requires the following information before unit is sent to Cassida: • Model and Serial Number of Unit •...
  • Page 13 Cassida is not liable for damages resulting from use of the unit for purposes other than for the intended purpose without prior written consent from Cassida. Modifications made to the unit by persons other than Cassida or its authorized contractor/ subcontractor is strictly prohibited.

This manual is also suitable for:

Zeus
