Zeus 2-POCKET CURRENCY DISCRIMINATOR SERVICE MANUAL · Specifications · Assembly · Procedures · Troubleshooting · Quality Testing · Parts Information CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Assembly Hopper and Top Panel 4.4. Upper Door This service manual is confidential and 4.5. Fly Wheel exclusively for the use of current Cassida 4.6. Encoder Disk PRO Series partners and their technicians. 4.7. Assembly Lower Guide This manual shall not be shared with outside 4.8.
1.1. INTRODUCTION FROM CASSIDA USA Thank you for partnering with Cassida PRO to sell and service the industry leading counterfeit detection equipment. Cassida PRO is proud to provide the best in class recognition and detection and dedicated service to our partners. Please visit our partner page listed below for the most up to date software, manuals, and information regarding our PRO Series products.
Orientation Mode Value Sort Mode Add Feature Strap Feature (by denomination, by count, by custom) OPTIONAL FEATURES: Bar Code Mode Bar Code + Cash Mode Serial Capture Mode CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Example of RS232 male - USB-A converter cable: Communication data format: This is available in the ZEUS Protocol Manual. If you need this information, please contact Support@CassidaPro. com. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 7
CONNECTION WITH A PC Required cable: RJ1 1 to RS232 female (RS232 PC Port) • The RJ1 1 to RS232 female cable is a custom cable. • Please contact Cassida PRO for pricing and availability. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/...
Required cable: USB-B – USB-A (USB-A PC Port) • Communication data format: API manual available upon request. • Requires Windows Driver (linux-cdc-acm.inf) which can be provided by Cassida PRO Tech Support upon request. Example of USB-B – USB-A cable: CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/...
· Universal Cash Handling Thermal Printer · Cassida Air Duster · CleanBill Pro Cleaning Cards · CleanPro Cleaning Swabs *Please contact Cassida PRO for pricing and availability of the items above. 1.6. REQUIRED TOOLS FOR SERVICE AND DISASSEMBLY #2 Screwdriver (+) 2.5mm Screwdriver (-)
• Chain: A misfeed error where two banknotes pass through the unit too closely after one another, so that the unit cannot differentiate the two bills CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
The following tests are suggested to be performed as a first pass to check overall unit health. These checks are similar to the Cassida PRO in-house QC process and cover the majority of the functions and diagnostic features provided by the Zeus.
A of pickup rubber is better if it is on highest position. And when position of A is at right position, ADF value in sensor detail menu becomes ‘1’. Check this value while turning the pickup roller. [Fig. 1] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 15
• Cover the reject sensor and the value should change to Rejector ‘1’ and Diff to <100 14) Stacker (Stacker Pocket Sensor) • Open the upper door and check the value of L and R. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 16
2) Press every key until ZEUS displays “Keypad Press Test: OK” and the [EXIT] key becomes available. Press [EXIT] to return to the service menu. [Fig. 2] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
(ex. face to the right, face to the left, back to the right, back to the left). Do this for each denomination, from $1 to $100. The amount of bills used depends on availability, but Cassida recommends testing with a large quantity of bills (100 per denomination).
Page 18
In this menu, you may check the magnetic head signals for scanned notes. ‘dbR’(Blue) shows the note is passing the magnetic sensors. There are three channels of magnetic sensors, MHL(Left), MHC(Center), and MHR(Right). CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 19
ADF rollers. The red and blue pulses for each PS1 and PS2 sensor are the sensed position of the note in the bill transport path. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 20
· Cable connections to MAIN board · CIS sensor for debris, dirt, damage, or cracking · UV/IR emitters for debris, dirt, damage, or cracking · Calibration waveforms CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 21
If this occurs, clean the surface of the CIS and calibrate the CIS again. If the waveform is still the same following cleaning and calibration, the CIS should be replaced. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 22
If the waveform doesn’t look similar to Fig. 10, clean the IR/UV bar and attempt a calibration. If discontinuities are still present, replace the IR/UV bar. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
7. Tighten screws while holding tensioner in position and verify proper dust cover operation. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
7. Turn on the power and go into Service Menu ->[1] Diagnosis ->[7] Sensor Detail. You can close the dust cover by pressing [9] key. If necessary, adjust the tension [3.2 .Dust Cover Tension Adjustment] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
CONNECTING REMOTE DISPLAY Please refer to picture below. RJ1 1 (ZEUS) <-> MAIN (Display) DISPLAY DISPLAY LINK MAIN LINK MAIN LINK (1st Display) <-> MAIN (2nd Display) CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
1) Loosen 1 screw (M3x6 SEMS) and remove FRONT_GND_1WAY wire 2) Spread wings outward and then pull out towards you 3) Pull up the connector cover and remove the harness (FRONT_TO_MAIN_FFC). CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 28
3) Loosen 4 screws (M3x6) and remove the upper door DISASSEMBLE FLY_WHEEL 4.5. (Fly Wheel - Right Side Panel) 1) Loosen 1 screw (SET SCREW M4x8) with Allen key 2) Remove the flywheel CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 29
3) Take out the clips holding the supports in place 4) Guide the harness (PS2_HARNESS_1WAY) into the interior and pull the ASSEMBLY_ GUIDE_LOWER toward you and downward at the same time. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
1) Loosen 2 screws(M3x6) and remove the ASSY_COVER_REAR 2) Loosen 2 screws (M3x6) 3) Take out the power cable (ASSY_SMPS_HARNESS) 4) Take out the ASSY_SMPS handling the power cable carefully. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 31
DISASSEMBLE ASSEMBLY_SMPS 4.8. (Assembly Power Supply) CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
5) Loosen 1 Nut (M8) with spanner #13 (M8) and #5.5 (M3). Remove the circular Right Hinge (HINGE_R_DUST_COVER) 6) Remove COVER_STACKER_LOWER by pressing the tabs on its sides and pulling it outward. 7) Take out DUST_COVER, squeezing the sides lightly if necessary. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 34
DISASSEMBLE DUST_COVER 4.11. (Dust Cover) CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
3) Loosen 1 screw (M3x6 SEMS) and remove the encoder sensor 4) Carefully cut the tie-wraps and remove tie-wraps from shaft 5) Remove 2 c-clips (5 ) and remove the shaft 6) Take out ASSEMBLY_GUIDE_CIS_UPPER CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
5) Remove CIS while supporting its harness with tweezers 6) Remove c-clip (6 ) and remove PULLEY_ADF_42S3M and PULLEY_ADF_16S3M 7) Loosen 4 screws (M3x6 tap) on both sides CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 37
DISASSEMBLE ASSEMBLY_GUIDE_CIS_LOWER 4.13. (Assembly Guide CIS Lower) CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
2) Disassemble PBA_MECHA and turn it down, disconnecting any harnesses attached to PBA_MECHA as necessary to reach screws behind board 3) Loosen 2 screws (M3x6 tap) on Left Side 4) Loosen 2 screws (M3x6 tap) on Right Side CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 40
4. Close the Upper door tightly and press [YES] to start calibration. 5. Open the Upper door and remove the shading sheet. 6. Close the Upper door tightly and go into [6. CIS calibration (T)] and press [YES]. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 41
2. Adjust the variable resisters confirming the double level is in 2000 ~ 3500 ranges. 3. Open the Upper door and check the double levels. They should be 4095. If not, repeat Step 2. (Right) (Left) CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 42
ROLLER_EXIT_PINCH 4-1, 4-7 FEED_PINCH_ROLLER 4-1, 4-7 (BEARING) ASSEMBLY_EXIT_ROLLER 4-1, 4-4, 4-5, 4-6, 4-12, 4-13 ASSEMBLY_FEED_ROLLER 4-1, 4-4, 4-5, 4-6, 4-12, 4-13 ROLLER_R_FINCH 4-1, 4-2 RUBBER_PICKUP No Need CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 43
1) Disassemble according to 2-1, 2-2, 2-3, and 2-9 2) Loosen 4 screws (M3x6 SEMS) on both sides 3) Tilt up the ASSY_REJECT_PLATE 4) Loosen 2 screws (M3x6 SEMS) CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
B.) Check ‘Upper Door’ (PS1) and ‘Lower Door’ (PS2) C.) ‘1’ means the door is open. If all the doors are closed but the level is ‘1’, then the sensor is not working. [Fig. 2] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 45
C.) Normal levels: Door open: < 1V (typically < 0.5V) ii. Door closed: > 4.0V (typically 4.5~4.8V) D.) Abnormal levels Door open: > 2.7V ii. Door closed: < 3.2V CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Quality -> [4] Scanned Image. F.) If all the images are correctly received from the CIS sensor as in [Fig. 2], then test the machine with additional bills. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 47
Replace the CIS which is currently installed in the machine G.) Otherwise if the image looks like [Fig. 4] ii.) Replace the PBA_MAIN board H.) Calibrate CIS (R) and CIS (T) once unit is reassembled CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
ID ERROR bill rejection may occur. [Fig. 1] has green lines in the background caused by improper IR illumination while [Fig. 2] is displaying correctly. In tandem, attempting a calibration will likely fail. [Fig. 1] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 49
Causes and Solution: 1. Poor connections to the harness between the UV light source and Mecha PBA A.) Reseat the connectors B.) Re-calibrate [Fig. 3] [Fig. 4] CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 50
A.) Gently pull on each wire in the connector. All wires should be securely clipped into the plastic connector B.) If a wire connector is not clipped into the connector, then it looks like the below picture. [Fig. 6] GOOD CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
B.) Replace the Main board with the original board C.) Replace the Mecha board. D.) Power on unit and check if error has resolved E.) Adjust Double level CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
After initialization, an emergency or failure message will splash to the main screen 2. Emergency screen pops up – NEVER press the [EXIT] button CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
• Incorrect date or date reset to 1970 after shutdown • Occasional need to power cycle unit several times to start up unit • All modes reset back to default CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
• In many cases, the end user has no desire to use the optional dust cover which is disabled by default. In the case that the end user prefers to use the dust cover, the technician may enable the dust cover CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 55
CIS illumination. Check for inconsistencies, unlit portions, or blinking/ wavering light. Use this in conjunction with scanning and calibration graphs to check proper operation of the CIS sensor. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 56
• ADF - TEAL - Position of the rollers as given by the encoder wheel. This graph should be a well formed square wave with longer pulses at the start and end of the graph for when the rollers CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 57
• Pressing [5] will cycle through the detailed UV, IR, and RGB throughput information. • RGB IR - This image displays the per-pixel values of each portion of the full illumination bar. Note any flat areas, or CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 58
• This menu provides the unit’s CPU IDs (CPU0 and CPU1) and detailed information about the unit. This information is stored on the main board of the unit. Cassida may request this information if the technician or end user needs to unlock the Zeus for extra software features.
• The CIS calibration should be done any time CIS replacement, main board replacement, or extensive repair work is performed. In order to run this calibration, the Cassida PRO specific shading sheet must be used. Affix the magnetic side of the CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/...
The unit will detect all settings files stored in the root directory, ensure that the correct settings are selected using the [UP]/[DOWN] arrow keys before loading. Press the [SET] key to load the selected file. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Ensure that the settings being loaded were originally captured from the same unit. [3] Factory Default Set • Selecting this option resets all unit settings to the default as shipped from Cassida. This option will reset ALL user menu and test menu settings. [4] Software Rebuild Selecting this option performs a software rebuild.
• Input the proper code and press [ENTER] before collecting data. The unit will beep and the filed “CURRENT CODE” will be updated with the user input code. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
• Turn on/off the CIS LED and back light LED. Repeatedly press [2] to check the LEDs in this order: 1. Back light 2. Blue CIS 3. Red CIS 4. UV CIS 5. Green CIS CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 64
• The graph is toggled whenever the [2] key is pressed; Left -> Center -> Right -> ALL. The picture immediately above on the right is magnified and scrolled properly from the original magnetic sensors’ output waveform. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 65
[C] to exit completely from the test menu. 1-6 CPU S/N • This function reports CPU serial numbers. This may be required for specific software updates or upgrades. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 66
ADF: 1 (Pickup Roller Position Normal) Upper/Lower Door L, R: 0 (closed), 1(opened) For other sensors’ output, please refer to “3. ADJUSTMENT”. 1-8 Keypad Test • Press every key until the screen displays “Keypad Press Test: OK.” CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Page 72
Remove Bills from Hopper. Adjust Feeding Mechanism Make sure path is clear and all belts are connected properly. MOTOR ERROR Test Motor in both directions using the Service Menu CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
Inspect reflectors for physical damage and cracking. Clear track / check upper door. CHECK PS2 Use DVM to check Voltage Level. Inspect reflectors for physical damage and cracking. CassidaPRO Zeus: Service Manual Rev: 09/05/2018 cassidapro.com/partner/ 2018 Cassida Corporation. All rights reserved.
APX IV RETURN MERCHANDISE AUTHORIZATION In order to begin the process of a return (and repair or exchange), Cassida PRO Tech Support requires the following information before unit is sent to Cassida: • Model and Serial Number of Unit •...
Page 75
Cassida is not liable for damages resulting from use of the unit for purposes other than for the intended purpose without prior written consent from Cassida. Modifications made to the unit by persons other than Cassida or its authorized contractor/ subcontractor is strictly prohibited.
