SECTION 50&·101-201
TABLE 8
SETTING CHARGE RATE OF TOTALIZER
Lowest Chargeable
Rot•te Shaft
Rate
in Proper Direction
(From Bonom to
Top)
5
cenls
One $~e p
10
cent.
Two steps
IS
cen ts
'Thrf'e s le ps
20
cents
Four
steps
25
cents
Fivl' steps
30 •. .
:t'llh
Si x
3Lc p=-
J .
TESTING
1.
01 Before replacing cover, (.;Qnnect
chal:;sls
w
lth P lL C cest co r d,
tocalizer Jn the following manner:
cover to
and rest
(ll
Provide ground
to
line
by
strapping ground
around contac ts on coln relay (Fig. 10).
PlA.CC p npcr clip,
or oq.uiva.lcnt, from C
term inal to terminal No. 3.
(2) Be sure trigger on coin relay is not
crip·
pcd.
(3)
Dia l tone should now
be
heard.
(4)
Dial any
digit.
Dial ton e will not
be
broken.
(5)
Remove
paper
ellp, or equivalent, and
replace cover.
1.02 Final testing should be made with the
cover Jn place and include the following:
(a) With handset OK switchhook:
Page 8
(!)
Deposit nick
e
I . Coin shall pass
t hrough the coin chute and be re-
f unded by operar1on of the coin relay.
(2) Repeat with dime and quarter.
(b) With handset OFF switchhook:
(ll
Deposit penny to check coln r e lease
mechanis m. Co.tn will s top ln chute.
(2)
Operate coin r e J e a se lever. Penny
w ill
drop Into coln r<turn .
(3) Deposit nickels, dimes, and qoaners
a• shown in Ta ble
C. All
co ins will
p O:oa through coin cl- .utc, s tepping to-
talizer once for e ach 5 cents depos-
ited.
(c)
Coin tone s ig naling:
(1)
Contact loca l tescbca r d or operator
for coi n c beck.
(2)
O ne beep should be t.eard for nickels,
two beeps for dimes, and a series of
five beeps for quarters. T hese beeps
can be monitored on the tip •nd ring
of the line using a I OllB test set ln
t he monitor position.
Fig.
I 0 - Method of Strappillg
Ground
Around Contacts
