- Page 1 Air purifier Air Purifier ServiceManual Philips Consumer Lifestyle AC0920 AC0921 AC0950 AC0951 Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification...
-
Page 2: Change List
Change List Version Detail Remark Date Owner Initial Service manual 2024.5.24 CC Chen Add service part list for AC0920/10 UK & AC0921/14 UK & AC0950/10 ANZ & 2024.5.24 CC Chen AC0950/10UK... - Page 3 Product overview Error Code: E1 (the issue with Motor)
-
Page 6: Safety Precautions
Safety precautions ◆ This manual is only for maintenance professionals r eference. ◆ Non-professionals do not disassemble the machine, So as not to cause injury to the a dultbody ◆ Please turn off and unplug the power cord when the appliance is m aintained. ◆... -
Page 7: Disassembly Instruction
DISASSEMBLY INSTRUCTION Before you start dismantling! For your safety be sure the plug is disconnected from the mains! If installation, perform the reverse operation, then test the basic functions accordingly. 1.Take the Filter cover, Filter, control panel assembly out. 2.Remove four screws from the lower housing. 3. - Page 8 DISASSEMBLY INSTRUCTION 4. Remove 4pcs screws from Air inlet bracket and 1pcs screw from Cable channel, then take out Cable channel, Air inlet bracket and lower housing. 5. Remove 4pcs screws from the upper housing. 6. Remove 3pcs screws from the Wind_Grid and take out the Air duct supporter cover and the Wind_Grid.
- Page 9 DISASSEMBLY INSTRUCTION 8. Remove 1pcs screw from the sensor and take out the sensor. 9. Remove 3pcs screws from the Air Duct and take out the Air Duct. 10. Take out nut, D-type gasket, Fan, fan gasket. 11. Remove 3pcs screws and take out the Motor and Air duct supporter.
- Page 10 DISASSEMBLY INSTRUCTION 12. Remove 3pcs screws from Motor and take out the cable. 13. Remove 3pcs screws from the control board and take out the control board. If removing the panel first, you can contrarotate the panel by your hand or by the tooling in the picture above.(BG can support the special tooling.)
- Page 12 SERVICE PART LIST Unicorn Mini AC0920/10 EU (688001001361) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001014965 8001001361 Control PCBA AC0920/10 EU9 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
- Page 13 SERVICE PART LIST Unicorn Mini AC0920/60 India (688001001355) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001015006 8001001355 Control PCBA AC0920/10 EU9 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
- Page 14 SERVICE PART LIST Unicorn Mini AC0921/14 EU (688001001363) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001015009 12780121CNOC09 Display UI panel ASSY 642001015010 8001001363 Control PCBA AC0921/14 EU9 642001015011 12780121CNOC12 Upper Body 642001015012 12780121CNOC04 Sensor cover assy 642001015013 22780WH8006 Wind_Grid...
- Page 15 SERVICE PART LIST Unicorn Mini AC0950/10 EU (688001001366) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001014986 8001001366 Control PCBA AC0950/10 EU9 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
- Page 16 SERVICE PART LIST Unicorn Mini AC0950/60 India (688001001381) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001015025 8001001381 Control PCBA AC0950/60 IN 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
- Page 17 SERVICE PART LIST Unicorn Mini AC0950/80 TW (688001001382) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001015027 8001001382 Control PCBA AC0950/80 TW 642001015113 12780121CNOC11 Upper Body TW 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001...
- Page 18 SERVICE PART LIST Unicorn Mini AC0951/13 EU (688001001369) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014951 12780121CNOC03 Display UI panel ASSY 642001015029 8001001369 Control PCBA AC0951/13 EU9 642001015035 12780121CNOC14 Upper Body 642001015038 12780121CNOC05 Sensor cover assy 642001015041 22780GY8008 Wind_Grid...
- Page 19 SERVICE PART LIST Unicorn Mini AC0920/10 UK (688001001362) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001015949 8001001362 Control PCBA AC0920/10 UK 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
- Page 20 SERVICE PART LIST Unicorn Mini AC0921/14 UK (688001001364) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001015009 12780121CNOC09 Display UI panel ASSY 642001015934 8001001364 Control PCBA AC0921/14 UK 642001015011 12780121CNOC12 Upper Body 642001015012 12780121CNOC04 Sensor cover assy 642001015013 22780WH8006 Wind_Grid...
- Page 21 SERVICE PART LIST Unicorn Mini AC0950/10 ANZ (688001001365) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001015935 8001001365 Control PCBA AC0950/10 ANZ 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
- Page 22 SERVICE PART LIST Unicorn Mini AC0950/10 UK (688001001367) Item Philips 12NC PCM CODE Part Name-English 1,2,5 642001014964 12780121CNOC08 Display UI panel ASSY 642001015937 8001001367 Control PCBA AC0950/10 UK 642001014966 12780121CNOC13 Upper Body 642001014967 12780121CNOC10 Sensor cover assy 642001014968 22780GY8001 Wind_Grid...
