- Page 1 MPC-3000 Series Quick Installation Guide Version 1.0, July 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802030001010 *1802030001010*...
-
Page 2: Package Checklist
With two software selectable RS-232/422/485 serial ports and two Gigabit Ethernet ports, the MPC-3000 Series panel computers support a wide variety of serial interfaces as well as high-speed IT communications, all with native network redundancy. Both regular and wide-screen models are available to meeting the display needs of various field applications. - Page 3 MPC-3100 MPC-3120 MPC-3120W - 3 -...
- Page 4 MPC-3150 MPC-3150W Dimensions MPC-3070W - 4 -...
- Page 5 MPC-3100 MPC-3120 MPC-3120W - 5 -...
-
Page 6: Display-Control Buttons
MPC-3150 MPC-3150W Display-control Buttons The MPC-3000 is provided with three display-control buttons on the right panel. - 6 -... -
Page 7: Hardware Installation
The display-control buttons can be used as described in the following table: Symbol and Name Usage Function Power on Enter sleep or hibernation mode Press Wake up Power NOTE: You can modify the function of the Power button in the OS settings menu Press and hold for 4... - Page 8 To install the panel-mounting kit on the MPC-3000, insert the mounting clamps in the mounting holes provided on the rear panel and slide the clamps to the ends of the panel as shown in the following figures: Use a torque of 5 kgf-cm to secure the mounting screws to fasten the panel-mounting kit onto the wall.
-
Page 9: Vesa Mounting (Optional)
VESA Mounting (optional) ATTENTION VESA mounting is not applicable to the marine applications. The MPC-3000 is provided with VESA-mounting holes on the back panel, which you can use directly without the need for an adapter. The dimensions of the VESA mounting area are 75 mm x 75 mm. You will require four 10-mm M4 screws to VESA mount the MPC-3000. -
Page 10: Connector Descriptions
MPC-3150 MPC-3150W Connector Descriptions DC Power Input The MPC-3000 uses a DC power input. The DC pin assignments are shown in the figure. To connect the power source to the 2-pin terminal block, use the 60-W power adapter. The terminal block is available in the accessories package. -
Page 11: Ethernet Ports
Ethernet Ports The pin assignments for the two Fast Ethernet 10/100/1000 Mbps RJ45 ports are shown in the following table: 10/100 Mbps 1000 Mbps ETx+ TRD(0)+ ETx- TRD(0)- ERx+ TRD(1)+ – TRD(2)+ – TRD(2)- ERx- TRD(1)- – TRD(3)+ – TRD(3)- The LEDs on the LAN ports indicate the following: LAN 1/LAN 2 Green... -
Page 12: Real-Time Clock
Installing a CFast or SD Card MPC-3000 provides two storage options—CFast and SD card. The storage slots are located on the right panel. You can install the OS on the CFast card and save your data into the SD card. For a list of compatible CFast models, check the MPC-3000 component compatibility report available on Moxa’s website. - Page 13 Grounding the MPC-3000 Proper grounding and wire routing help to limit the effects of noise from electromagnetic interference (EMI). Run the ground connection from the ground screw to the grounding surface prior to connecting the power source. The minimum cross-sectional area required for the protective earthing conductor is 3.31 mm².
