Parts List
To assist you in identifying your vacuum's components, the parts have been numbered as follows.
![Bissell - BG9100NM - Parts List Parts List]()
- Handle
- Tube A
- Tube B
- Top cover
- Lock slider, dust box cover
- Release spring, dust box cover
- Battery package
- Switch box
- Belt
- Bottom base
- Monster Pet Brushroll
- Dust box
- Crystal window
- Release button for Brush
- Dust box cover
- Standard Carpet Brushroll
Assembly
Assembly Instructions
- Attach wall mount to a flat surface using the screws provided.
![]()
- Insert the round end of the brushroll against the side-intake. Push the end cap of the opposite end of the brushroll into the channel until the end cap "snaps" into place.
![]()
- Attach handle to the end of strut with the telescopic wand adjustment pressing down the locking tab, slide shorter strut over longer strut until locking tab catches. Insert assembled handle into base until it locks in place. Loosen the telescopic wand adjustment to lengthen or shorten the handle to the desired length and then tighten telescopic wand adjustment.
![]()
- Insert battery into battery compartment until it "snaps" in place. Connect the power adapter and allow the unit to charge for 4 hours (NC) / 10 hours (NM)
You can use the machine when the LED charging indicator change from red to green. Keep charging about one hour after the LED charging indicator turn green, it can extend the runtime. The LED charging display will light when charging.
NOTE: The unit will not charge if left in the ON position. It is recommended that you remove the power adapter from the unit once the unit has completely charged
![]()
Operation
Operating Instructions
- Press the "
" switch on top of power head when ready to operate.
![]()
- Place foot on power head and lean handle back gently to release lock for vacuum use. Return handle to the full upright position to engage lock.
NOTE: Do not operate the unit while in the upright and locked position. Do not let the unit run while in any one stationary position for any period of time. Keep the unit moving while in operation.
![]()
Maintenance
The performance of your new cleaner greatly depends upon care and maintenance The instructions in this manual will guide you in performing basic care and maintenance. To obtain the most satisfying years of service read the instructions and keep them handy for future reference.
Emptying Dirt Container:
- Firmly grasp the unit at handle base and with the other hand, press the dirt container release.
Note: Make sure to have a firm grasp on the handle base and carefully lay the handle flat.
![]()
- Lift the dirt container out of the unit and dump contents into wastebasket. Reinsert the dirt container into the unit. Grasp the handle base and carefully rotate it forward until it locks into place.
![]()
Storage
- Attach the lip of the brushroll chamber over the hooks of the wall mount. Rotate handle upwards until it snaps into the handle lock.
![Bissell - BG9100NM - Storage Storage]()
Cleaning Standard Carpet Brushroll
- Press the Brushroll Release to remove the brushroll from the brushroll chamber. Remove any wound up debris using a knife or scissors. Cut debris along patented cleaning grooves in the brushroll for easier cleaning. Reinstall brushroll into brushroll chamber.
![Bissell - BG9100NM - Cleaning Standard Carpet Brushroll Cleaning Standard Carpet Brushroll]()
Cleaning Monster Pet Brushroll
- Press the Brushroll Release to remove the brushroll from the brushroll clamber. Pull the round end of the brushroll to remove it from the cleaning cover. All debris to be discarded will be left on the brushroll cover. Remove any wound up debis using a knife or scissors. After cleaning brushroll, insert it back into the cleaning cover. Reinstall brushroll into brushroll chamber.
![Bissell - BG9100NM - Cleaning Monster Pet Brushroll Cleaning Monster Pet Brushroll]()
Troubleshooting
Service problems that appear to be major can often be solved easily. You can be your own troubleshooter by reviewing this guide. All other servicing should be done by Bissell BigGreen Commercial authorized service center.
Problem | What to do |
Unit does not turn on | - Charge battery again.
- Check electrical source-fuse or circuit breaker.
|
LED charging indicator not lit while charging | - Make sure the charging adapter is plugged in the electrical outlet and charging socket properly.
- Check electrical source -fuse or circuit breaker.
|
Suction power is not sufficient | - Empty dirt container.
- Charge battery again New battery may be required, contact an Authorized Service Center
|
Running time is not sufficient | - Charge battery again.
- New battery may be required, contact an Authorized Service Center.
|
Brushroll does not work while operating | - Clean brushroll.
- Contact an Authorized Service Center.
|
Unit still does not Operate properly | - Contact Bissell BigGreen Commercial for service.
|
Customer Service Hotline
USA: 800-242-1378 Canada: 1-888-676-7325
Website: www.bissellcommercial.com
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER
![]()
To reduce the risk of fire, electric shock, or injury:
- Do not use outdoors or on wet surfaces.
- Do not expose to rain, store indoors. Do not allow to be used as a toy. Close attention is necessary when used by children Use only as described in this manual. Use only manufacturer' s recommended attachments.
- Do not use extension cords or outlets with inadequate current carrying capacity.
- Do not handle charger or vacuum cleaner with wet hands.
- Do not incinerate or mutilate batteries as they will explode at high temperatures.
- Do not pick up anything that is burning or smoking such as cigarettes, matches, or hot material.
- Do not allow the battery to run down completely before charging. In doing so, serious problems may occur in the battery life cycle.
- Do not pick up flammable or combustible liquids such as gasoline, or use in areas where they are present.
- Store the adapter indoors in a cool dry area not exposed to the weather to avoid electrical shock and/or cleaner damage.
- Only use the adapter provided by the manufacturer to recharge the appliance.
Additional Safeguards
- Always disconnect cord from electrical outlet before servicing the cleaner. Only charge the unit indoors.
Lubrication
- Lubrication is not necessary since the motor and brush roll are permanently lubricated.
SAVE THESE INSTRUCTIONS
If the adapter or the interconnection cord is damaged, it must be scrapped
IMPORTANT BATTERY HANDLING INSTRUCTIONS
When using an electrical appliance containing a NC/NM battery basic precaution should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE CHARGING THE BATTERY
![]()
To reduce the risk of fire, electric shock, or injury:
Battery charging
- Charge batteries for 4 hours(NC) /10hours (NM) before initial use. Never modify the electrical system.
- Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury.
- The battery must be handled by adults only. Dropping the Battery could result in serious injury.
- Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery. Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury.
- Lift and carry the battery by the case only. Read the safety instructions on the battery.
- Examine the battery, charger and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part.
Care
- If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag.
- Please refer to the information on this page for proper disposal. If a cid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.
- If acid is internally ingested, give water, milk of magnesia or egg whites immediately. Never give emetics or induce vomiting. Call a physician
- Do not allow the battery to run down completely before charging. Charge the battery at least once per month, even if the vacuum has not been used. Leaving the battery in a discharged condition will ruin it.
- Do not store the battery in temperatures above 75ºF or below -10ºF
