HCS6700 Product Description

The HCS6700 is one of the LG CodePlus™ series transcoder cards. Pairing an HCS6700 card, in
the appropriate CodePlus card frame, with a DIRECTV COM 23 satellite receiver will provide one
channel of MPEG-4 DIRECTV content.
Features
• Part of modular system, easily scaled for each application
• Transcodes satellite content to encapsulated MPEG-4 Transport Stream
®
• Built-in Pro:Idiom content protection
• DVB-ASI output available to connect to external MUX or modulator
• Internal LVDS serial output available at CONTROLLER card slot on mother board
• Transcoded output supports Closed Captions and V-Chip (Parental Control)
• Short 3U height profile to minimize rack-space usage
The HCS6700 is intended to provide access for Pro:Idiom TV (MPEG-4 only) installations to
DIRECTV MPEG-4 encoded programming. The HCS6700 converts the DIRECTV MPEG-4 HD
programming to an encrypted MPEG-4 encoded transport stream.
*
If included in the signal source.
6
*
HCS6700
X PORT LINK
SERVICE
PORT
RESET
STATUS
ASI OUT
S/N XXXXXXX
MAC ADDRESS
XX XX XX XX XX
206-4120
