LG CodePlus HCS6700 Series Installation & Setup Manual Warranty page 12

System Setup (Cont.)
Typical Setup Flow Chart for a Single HD Channel
RF Cable
RF In
COM 23
Satellite
Receiver
Ethernet
ASI
ASI In
VSB or QAM
Modulator
IF Out
Note: This flow chart shows setup connections
where a unique feature card is NOT installed in
the card frame CONTROLLER slot.
12
DIRECTV Satellite Signal*
*Multi-switch will be necessary if
the number of transcoders exceeds
the dish antenna's capacity.
Access
Card
X-Port In
HCS6700
ASI Out
IF In
DTV
RF
Coaxial
Upconverter
Cable
Combiner
RF
Cable
RF Out
A/V
Cables
(for monitor only)
NTSC
Monitor
206-4120
