Table of Contents

Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Instructions. . . . . . . . . . . . 34
Table of Contents / Setup Information . . . . . . . 5
HCS6700 Product Description . . . . . . . . . . . . 6
Transcoder Product Description . . . . . . . . . . . 7
Card Description . . . . . . . . . . . . . . . . . . . . . . . 8
Installing CodePlus Transcoder Cards . . . . . . . 9
Setup Information
This document provides installation and setup support only for an HCS6700 transcoder card. The sat-
ellite dish antenna and DIRECTV
you can proceed to set up the HCS6700. LG recommends that the system be professionally installed.
Check the items listed below before you begin the HCS6700 installation and setup procedures.
Satellite Dish Antenna
__ The satellite dish must be located where it
will have unobstructed access to the satellite
signals. At least RG-6 or larger coaxial
cables must be installed between the satel-
lite dish antenna system and the COM 23.
Refer to documentation provided with the
satellite dish antenna.
__ For MPEG-4 reception, a 5-LNB satellite
dish configuration is required. If the number
of transcoders exceeds the dish antenna
capacity, multi-switch equipment will be
required. For more information, refer online
to www.DIRECTV.com.
Satellite Receiver
__ Refer to COM 23 documentation, and care-
fully follow the system setup procedures for
the satellite receiver. (The COM 23 provides
the X-port signal input for the HCS6700.)
206-4120
Table of Contents / Setup Information
®
COM 23 satellite receiver must be installed and operating before
DIRECTV COM 23 Satellite Receiver & HCS6700
Initialization & Setup Connections . . . . . . . . . . 10
System Setup . . . . . . . . . . . . . . . . . . . . . .11-12
Configuration Options . . . . . . . . . . . . . . . 13-17
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 18
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 19
Document Revision History / Notes . . . . . . . 20
Warranty . . . . . . . . . . . . . . . . . . . . . Back Cover
__ DIRECTV authorization is required for
HD channels. Contact DIRECTV, Inc. to get
subscription programming authorization for
the COM 23 satellite receiver.
ASI Output (Optional)
__ If applicable, install the DTV modulator and
upconverter that will receive the ASI output
signal from the HCS6700. Refer to the man-
ufacturer's documentation.
HCS6700
__ If the HCS6700 will be used with a unique
feature card (Example: HCS6300) in the card
frame CONTROLLER slot, you will need a
copy of the Installation & Setup Guide for the
feature card in order to complete the
HCS6700 system setup.
__ For HSC6700 Service Port connections, you
must use an FTDI TTL-USB cable (P/N TTL-
232R-5V-AJ).
5
