- Page 1 HCS6700 CodePlus Series ™ ® DIRECTV HD Transcoder (MPEG-4 Compatibility) Installation & Setup Guide Warranty Part No: 206-4120 © Copyright 2010, LG Electronics U.S.A., Inc.
-
Page 2: Safety Warnings
CAUTION: Do not attempt to modify this product in any way without written authorization from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate this product. -
Page 3: Important Safety Instructions
11. Test Equipment 4. Follow all instructions. In some cases, LG has supplied or recom- Follow all operating and use instructions. mended the use of test equipment and 5. Do not use this apparatus near water. - Page 4 IMPORTANT SAFETY INSTRUCTIONS 14. Servicing (Continued from previous page) Caution: These servicing instruc- 13. Damage Requiring Service tions are for use by qualified ser- Unplug this product from the wall power out- vice personnel only. To reduce the let and refer servicing to qualified service risk of electrical shock, do not perform personnel under the following conditions: any servicing other than that described in...
-
Page 5: Table Of Contents
COM 23 satellite receiver must be installed and operating before you can proceed to set up the HCS6700. LG recommends that the system be professionally installed. Check the items listed below before you begin the HCS6700 installation and setup procedures. -
Page 6: Hcs6700 Product Description
HCS6700 Product Description The HCS6700 is one of the LG CodePlus™ series transcoder cards. Pairing an HCS6700 card, in the appropriate CodePlus card frame, with a DIRECTV COM 23 satellite receiver will provide one channel of MPEG-4 DIRECTV content. Features •... -
Page 7: Transcoder Product Description
The HCS6700 changes the DIRECTV encryption scheme to a Pro:Idiom encryption scheme. A proper session ID must be set at the TV in order for Pro:Idiom decryption to be enabled. LG’s Pay- Per-View (PPV) partners can properly set up this session through their interface. An LG Free-To- Guest (FTG) card is substituted for the supplied Multiple Protocol Interface (MPI) card and can set the session to allow decryption. -
Page 8: Card Description
Card Description HCS6700 Retaining Screw Install after inserting HCS6700 card X PORT LINK X-PORT Link Ethernet port to COM 23 satellite receiver Service Port SERVICE TTL-USB serial port PORT connection (use FTDI RESET TTL-232R-5V-AJ cable) STATUS Reset Reboots card ASI OUT Status ASI Out Blinking pattern indicates... -
Page 9: Installing Codeplus Transcoder Cards
HCS6700 card. Always observe proper install the HCS6700. Note: All cards must be precautions with respect to static electricity used in an LG-approved card frame for this and mechanical shock. When not installed in a product. card frame, return the HCS6700 card to the 3. -
Page 10: Directv Com 23 Satellite Receiver & Hcs6700 Initialization & Setup Connections
DIRECTV COM 23 Satellite Receiver & HCS6700 Initialization & Setup Connections COM 23 ..DIRECTV Satellite Signal V ID V ID X-Port Link to HCS6700 Power Outlet (120V 60Hz AC) Composite Video H C S 6 and L/R Audio 7 0 0 HCS 670... -
Page 11: System Setup
System Setup Typical HCS6700 System Installation & Test (see also Typical Setup Flow Chart on page 12) 1. Verify that the COM 23 satellite receiver is set • If the HCS6700 will be used with a unique up and functioning (i.e., check that the COM feature card in the CONTROLLER slot, the 23 is connected to an NTSC monitor [for tun- cable to the ASI OUT port may not be... - Page 12 System Setup (Cont.) Typical Setup Flow Chart for a Single HD Channel DIRECTV Satellite Signal* RF Cable *Multi-switch will be necessary if the number of transcoders exceeds the dish antenna's capacity. RF In COM 23 Access Satellite Card Receiver Cables (for monitor only) Ethernet X-Port In...
-
Page 13: Configuration Options
Configuration Options The HCS6700 contains several internal registers for different configuration options. These can either be left at their default values or configured by the user. There are two methods available for configuration purposes: • Service Port Method • Controller Card Method This document describes configuration procedures using the Service Port Method, which requires that you connect a PC directly to the transcoder Service Port. - Page 14 Configuration Options (Cont.) (Continued from previous page) View the Pro:Idiom Key Checksum Use the following procedure if you wish to dis- Note: In order for a Pro:Idiom play the Pro:Idiom Key checksum. encrypted channel to be displayed, the following conditions are required: 1.
- Page 15 3. With the Main Menu on display, type the num- ID (firmware version), software versions, MAC ber corresponding to the Update Firmware address, and serial number. LG suggests that option, and press Enter. you record this information for future reference. If...
- Page 16 Configuration Options (Cont.) 7. Repeat steps 2 to 6 of this procedure for (Continued from previous page) each HCS6700 card whose firmware you TFTP Transfer wish to update. Note: TFTP transfer requires that you be able 8. Upon successful installation(s), power cycle to set up a TFTP server on the PC.
- Page 17 Configuration Options (Cont.) Satellite Receiver Menu Commands View MUX Bitrate Data Bitrate data is useful for system monitoring and • Currently Selected Channel: Returns you to troubleshooting purposes. Use the following pro- the currently selected DIRECTV channel num- cedure to view MUX bitrate data. ber.
-
Page 18: Troubleshooting
Troubleshooting Many problems can be corrected with a simple reset of the COM 23 and/or the HCS6700. Running the system test on the COM 23 satellite receiver can also help you diagnose and solve many com- mon problems. If you experience image freezes, audio freezes, or a blank screen, try the following (in order): •... -
Page 19: Specifications
Specifications Satellite Dish Antenna Requirements To provide the X-port signal input to HCS6700, a 5-LNB satellite dish configuration connected to a DIRECTV COM 23 satellite receiver is required. If the number of satellite receivers exceeds the dish antenna capacity, multi-switch equipment will be required. For more information, refer online to www.DIRECTV.com. -
Page 20: Document Revision History / Notes
Document Revision History / Notes Document Revision History Date Description February 2010 Revision A: New document Product documentation is available online at: www.LGcommercial.com/products. From the ® Products page, select Head End Systems, then CodePlus™ Transcoder Series, then DIRECTV Modular Systems, then the applicable CodePlus series card frame, then HCS6700. Click the Downloads &... -
Page 21: Warranty
God or other causes beyond the control of LG. Any alteration of the product after manufacture voids this warranty in its entirety.
