Hkoenig ti700 Manual

PRODUCT OVERVIEW

1. Voltage: 220-240V;
   Frequency: 50Hz;
   Power: 2000-2400W;
   Capacity: 1.7L;
   Standby power consumption: 1.0W below;
2. Intelligent temperature control heating; with optional 70℃, 80℃, 90℃, and 100℃ heating;
3. Intelligent insulation; with optional 70℃, 80℃, and 90℃
4. Six touch key + 6LED luminotron tube + buzzer operation indication;
5. START/CANCEL key: To start / stop heating;
6. HOLD TEMP key: Select or cancel the insulation;
7. 70℃ -100℃ water temperature key: To select the required temperatures of 70°C,80°C, 90°C, or 100°C;

NOTICE BEFORE USE

1. Before use, first check that the voltage required by the electric kettle is accordance with your supplied voltage. If not accordant, do not use this product to avoid accident!
2. Please place this product at level plane to prevent the turnover to damage this product, causing the accident. In use, the kettle power plug should be firmly inserted into the corresponding socket.
3. Please select the suitable lid. There are water lid (Fig. 1)

   Fig. 1

   and tea lid (Fig. 2).

   Fig. 2
4. This product is equipped with the dry-burning automatic power off device, to automatically cut off the power in case of dry overheating, thus preventing the product damage.
5. In use process, if the kettle is dry burn accidentally, first unplug the power plug and add the appropriate cold water to reduce the electric hot tray temperature, so the power off device will automatically reset. Drain the first cooked water and then normally use the kettle.
6. Six indicator lamps are set on the base, to indicate the selected temperature (70℃, 80℃, 90℃, and 100℃) and the insulation and power turning-on indication function.
7. The tea bags group can be dismantled, with the special dismantlement method referring to dismantlement mark (Fig. 3)

   Fig. 3

KETTLE GENERAL VIEW

Fig. 4

1. Spout;
2. Lid;
3. Handle;
4. Glass body;
5. Base;

BASE GENERAL VIEW

Fig. 5

6, 7, 8 and 9. Temperature selection button;
10. Insulation button;
11. Heating / Stop button;

USE METHOD

1. For burning the water, Select the cover shown in Figure 1. If cooking the tea, you can directly remove the lid (shown in Fig. 6)

   Fig. 6

   to place the tea into the tea bag and then add the appropriate water to the level between MIN and MAX shown by the kettle water gauge.

   Fig. 7

2. After adding water, place the lid properly; lift up the tea bag (Fig. 8) after covering the lid and then place the kettle on the base; insert the power plug into the corresponding power socket and then the buzzer will beep twice and all indicators is on for one second, so the kettle is at the standby state if no any other operation.

   Fig. 8
3. The corresponding indicator will be on if the heating temperature is set, so the heating will start if the heating button presses. The indicator will flash, the buzzer will beep twice and the temperature indicator will be on if up to the setting temperature, so the kettle is at the standby state if no any other operation for one minute.
4. Press the insulation button twice to start and press it again to cancel. Only the 70℃, 80℃, and 90℃ can be selected for insulation rather than 100℃. If the insulation function has been selected, this function will be canceled if the temperature is set to 100°C.
   In case of the insulation function selected, if the heating button can not be pressed within one minute, the insulation function will be canceled to enter into the standby mode. In case of the insulation function selected, if the heating button is pressed within one minute, the insulation timing of 30 minutes will count down.
5. In the heating process, if the temperature indicator flashes, there indicates the setting heat temperature; if this indicator is on, the water temperature has been up to or above this setting value;
6. Others

If the insulation function has been not selected, the kettle will be lifted up from the base to enter into the standby state, so the program will be initialized.
In case of the insulation function selected, if the kettle is lifted up from the base, this state before lifting will be kept; if the base can not detect the kettle within one minute, the beep sound will be given to enter into the standby state and the program will be initialized; if the base can detect it within one minute, the front lifting will continue on.
In standby mode, all LEDs are off and the heating process stops.
In standby mode, if there is no kettle on the base, all buttons and indicators disable.

FAULT STATE DESCRIPTION

1. In case of NTC short-circuit, all indicators flash and the heating process stops, so all buttons will disable.
2. In case of NTC open-circuit, all indicators flash and the heating process stops, so all buttons will disable.
3. In case of kettle dry burning, all indicators flash and the heating process stops, so all buttons will disable.

DESCALING

1. Cleaning
   • Before cleaning, please carefully read the "Warning" section;
   • Before cleaning, remove the power plug and allow the kettle cool;
   • Wipe the kettle outside and bottom cover with a damp cloth and then dry it with dry cloth. Do not use rough cleaning materials, otherwise it will scratch the kettle body.
   • Clean and remove the debris and attachments with the soap water or cleaning agent rather than strong acids or other corrosive detergent.
2. Descaling
   • Descale the kettle regularly to ensure a longer product life;
   • At least descale twice each year in normal use;
   • Add the vinegar to the MAX level shown in water gauge and boil;
   • Cut off the power (remove the power plug);
   • Add the cooked vinegar into the kettle for one night and then drain;
   • Add the water to the MAX level shown in water gauge to boil and then drain; after that, rinse the remaining dirt and vinegar off;
   • Wash the kettle with cleaning water for descaling.
   • Cleaning and maintenance should not be carried out by children unless they are at least 8 years of age and are supervised by an adult.

WARRANTY

The warranty period for our products is 2 years, unless otherwise stated, starting from the date of initial purchase or the date of delivery.

If you have any problems or questions, you can easily access our help pages, troubleshooting tips, FAQ, and user manuals on our service site: https://sav.hkoenig.com. By typing the reference name of your device in the search bar, you can access all available online support, designed to best meet your needs.

If you still cannot find an answer to your question or problem, then click on "Did the answer solve your problem?". This will direct you to the Customer Support Request Form, which you can fill out to validate your request and get help.

SAFETY WARNINGS

• This product is designed only for burning water or cooking teat indoors, with other liquid into this kettle or other purpose forbidden. In use process, do not replace the lid for cooking the tea after burning the water!
• Before use, be sure to add the water and then turn on the power.
• Do not exceed the rated maximum capacity, to prevent the boiling water overflow to cause the scald.
• Be sure to move the kettle only after the power is cut off;
• Do not touch the kettle filling with boiling water except for handle, to avoid burns.
• In use process, do not hang the power wire near the table or similar part to avoid any danger.
• To avoid the water erode the internal parts, do not immerse the kettle into any liquid. Please refer to the "Descaling"
• Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has been damaged or dropped. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
• This appliance may be used by persons with reduced physical, sensory or mental capabilities or lack of experience or knowledge, provided that they are supervised or instructed in the safe use of the appliance and that they fully understand the potential hazards.
• Children should be supervised to ensure that they do not play with the appliance.
• This appliance is intended to be used in household and similar applications such as:
  • Staff kitchen areas in shops, offices and other working environments;
  • Farm houses;
  • Guest rooms.
• If the kettle is overfilled, boiling water may be ejected.
• The appliance must not be immersed.
• The kettle is only to be used with the stand provided
• The device must not be used if it has been dropped, it obvious signs of damage are visible or if it has leaks.
• This appliance may be used by children of at least 8 years of age, as long as they are supervised and have been given instructions about using the appliance safely and are fully aware of the dangers involved.
• Keep the appliance and its power cord out of reach of children under 8 years of age.
• When using electrical equipment, safety precautions must always be taken to prevent the risk of fire, electric shock and/or injury in the event of misuse.
• Make sure that the voltage rating on the type plate corresponds to your main voltage of your installation. If this is not the case, contact the dealer and do not connect the unit
• Never leave the unit unattended while in operation.
• Never open the appliance from the front, always position yourself slightly to the side to avoid burning yourself with steam.
• Cleaning and maintenance should not be carried out by children unless they are at least 8 years of age and are supervised by an adult.
