J007-6603

Quick Installation Guide

J0076603

Checking the Computer and

Check the power source.

Installation Area

The power requirements of this printer are as follows:

100-120V, 50/60Hz, 1A or more.

The area where the printer is to be

Warning

placed.

• Keep the machine away from humidity and dust. Oth-

Choose a flat, stable area to install the printer. Make

sure that all four printer legs make firm contact with

erwise a fire or an electric shock might occur.

the surface beneath.

• Place the machine on a strong and level surface. Oth-

• The surface should be level within two degrees, left to

erwise, the machine might fall and cause personal

right and front to back.

injury.

• To prevent condensation, install the printer in an area

• If you use the machine in a confined space, confirm

where temperature and humidity conditions do not ex-

that there is a continuous flow of air.

ceed those indicated in the diagram below.

Warning

• The printer may cease to print if these limitations are

• Only connect the machine to the power source de-

exceeded.

scribed on this sheet.

• Avoid multi-wiring.

• Connect the power cord directly into a wall outlet and

never use an extension cord.

• Do not damage, break or make any modifications to

the power cord. Do not place heavy objects on it. Do

not pull it hard nor bend it more than necessary. These

actions could cause an electric shock or fire.

Warning

ZDJX006J

• Do not plug or unplug the power cord with your hands

wet. Otherwise, an electric shock might occur.

Warning

• Make sure the wall outlet is near the machine and

freely accessible so that in event of an emergency it

can be unplugged easily.

TS4K031E

Checking the Computer to be Con-

• White area: Permissible Range

• Gray area: Recommended Range

nected.

To use this printer, a computer must have an operat-

• The diagram below shows the ideal clearance for load-

ing environment that meets the following specifica-

ing paper, replacing print cartridges, and removing

tions:

jammed paper.

• MS-DOS/V compatible with USB interface

• Operating system: Windows 98/Me/2000/XP, Windows

Server 2003, Windows NT 4.0 or later

• 80-100 MB (minimum) available hard disk space

❢Limitation

❒ For Windows NT 4.0, IE 4.0 or later is required.

❒ Windows NT 4.0 do not support USB connection

with your printer. Connect your printer via a net-

work in this case.

❒ USB connection is supported by Windows 98/Me/

AKR127S

1. At least 19 cm (7.5 inches)

2000/XP and Windows Server 2003.

❒ USB connection speed under Windows 98/Me is

2. At least 12 cm (4.8 inches)

If you attach the multi bypass tray (Option), pro-

USB 1.1 equivalent.

vide additional clearance of 23 cm (9.1 inches).

Note

Important

❒ To print at the highest quality, the following

❒ To avoid malfunctions, position the printer away

memory capacities are required.

• Windows 98/Me (64MB or more recommended)

from the following:

• direct sunlight

• Windows 2000/XP (128MB or more recom-

• flow of air from air conditioners or heaters

mended)

• radios, televisions, or other electronic devices

• Windows Server 2003 (256MB or more recom-

areas of high/low temperature and high/low

mended)

• Windows NT 4.0 (64MB or more recom-

moisture

• humidifying appliances

mended)*1

• oil stoves and ammonia-emitting appliances

*1 We recommend at least 128 MB of memory for

(such as diazo copiers)

high quality printing on glossy paper.

❒ The machine does not support Windows XP 64-

Bit Edition or Windows Server 2003 64-Bit Edi-

tion.

Checking the Supplied Items

Attaching the Network

and Unpacking the Printer

Interface Board Type GX2

Open the box and take out all supplied items.

(Option)

Check that all the following items are present:

Starter cartridge - Cyan

Important

Starter cartridge - Magenta

❒ Before touching the network interface board,

Starter cartridge - Yellow

ground yourself by touching something metal to

Starter cartridge - Black

discharge any static electricity.

❒ Do not subject the network interface board to im-

Quick Installation Guide (this manual)

pact or other physical stress.

Setup Handbook

"Driver, Manual & Utility" CD-ROM

Check the product and its supplied

User Guide is included on this.

components.

Note

Check that the power cord of the

❒ USB cable and LAN cables are not supplied.

printer is not plugged in.

Important

❒ Do not turn the printer on until you have read how

Using a coin, turn the network inter-

to do so.

face board cover screw counterclock-

wise, and then remove the cover.

Remove the spacer in the network in-

terface board cover.

AKR006S

Take off the protective covering.

Remove the orange tape from the

The removed spacer will not be used again.

printer body.

Important

Align network interface board notch

❒ Remove all the orange tape, except the tape around

with the triangular mark on the

the power cord.

printer, and then push in the network

interface board in by pressing the part

marked "PUSH".

Reattach the network interface board

cover to the printer, and then fasten it

using the screw.

Note

❒ Be sure to push the network interface board fully

into the printer.

❒ If the network interface board is not installed prop-

erly, repeat the entire installation procedure. If you

cannot install it properly even after attempting re-

installation, contact your sales or service represen-

tative.

Dispose of the removed component as general plastic

waste or hand it in for collection.

Read this sheet carefully before you use this product and keep it handy for future refer-

ence. For safe and correct use, please be sure to read the Safety Information in the

Setup Handbook before using the product.

Attaching the Multi Bypass

Tray Type BY1000 (Option)

Check that the power cord of the

printer is not plugged in.

Take the multi bypass tray out of its

box.

Remove the orange tape from multi

bypass tray.

Attach the multi bypass tray by push-

ing it in until it clicks.

AKR091S

Extend the multi bypass tray.

AKR130S

AKR131S

Installing the Print Cartridges

Caution

• If ink comes into contact with your eyes, rinse imme-

diately in running water. For other symptoms, consult

a doctor.

• If ink is ingested, induce vomiting by drinking a strong

saline solution. Consult a doctor immediately.

• If your skin comes into contact with ink, wash the af-

fected area thoroughly with soap and water.

Caution

• Keep the ink or ink container out of reach of children.

Important

❒ Print cartridges and supplies comply with the

manufacturer's safety specifications. To ensure

safety and reliability, use genuine print cartridges

and supplies.

Unpack the print cartridges.

Open the Right Front Cover.

AKR003S

Check the cartridge's orientation, and

then gently insert it.

AKR004S

Important

❒ Take care to insert the colors in the right order.

❒ Take care not to touch the cartridge chip.

Push in the cartridge using the PUSH

area.

Repeat steps 3 to 4 for all four car-

tridges.
