oneisall LM2 - Pet Grooming Vacuum Manual

Package List

Product Overview

Product Overview

Product Technical Parameters

Product Technical Parameters

Operation Instructions

  1. Install the Dust Cup
  1. Align the snap-fit.
  1. Press the dust cup down by your hand.

information NOTE
If the device has no suction or is very noisy. please reinstall the dust cup

  1. Ready to Use
    1. Connect the accessory to the vacuum cleaner through the hose.
      Operation Instructions - Step 1
    2. Insert the plug into the socket.
    3. Turn on the switch and begin vacuuming.
    4. Select the speed you need. We suggest starting with silence mode for first-time use.
      Operation Instructions - Step 2
    5. Grooming Your Pet.
      Operation Instructions - Step 3
    6. The hair you collect can go straight into the trash.
      Operation Instructions - Step 4

information NOTE
There are 3 Cleaning Modes: Silence Mode, Standard Mode, and Max Mode. We suggest starting with the Silence Mode for first-time use as your pet will slowly get used to the noise.

Use of Different Accessories

  1. Daily Grooming Brush
    Used to clean floating hair and dander, making the hair more healthy, shiny, and soft
    Use of Different Accessories - Daily Grooming Brush
  1. Electric Clipper
    1. Used to trim the pet's hair without leaving a mess as the hair will not fly around.
    2. While cutting, it suctions the cut hair!
      Use of Different Accessories - Electric Clipper - Step 1
      Use with vacuum or the clippers alone
    3. Dual-purpose: can be used for pet hair trimming or with the device.
      Use of Different Accessories - Electric Clipper - Step 2

information NOTE
Remember to pay attention to the cutting edge and position, and do not use excessive force as it causes skin irritation.

Install Guide Comb (used with electric clippers)
Choose the length guide comb according to the length of pet hair you want to leave. The guide comb ((3mm/6mm/9mm/12mm/18mm/23mm)) is applicable for grooming different hair lengths.

  • The guide comb set is small; keep it stored properly when it is not in use.
    Install Guide Comb
  1. De-shedding Brush
    Used to remove the pet's long and unnecessary thick hair
     Use of Different Accessories - De-shedding Brush

information NOTE
During use, pay attention to the cutting edge and position, do not use excessive force as it causes skin irritation.

  1. Cleaning Brush
    Used to clean pet's paws or pet hair on clothes and furniture.
    Use of Different Accessories - Cleaning Brush
  1. Crevice Tool
    Used to clean hair on the furniture and or hard-to-reach areas.
    Use of Different Accessories - Crevice Tool
  1. Pet Paw Trimmer
    Used to groom pet's paws, eyes, ears, face, and rump hair.
    Use of Different Accessories- Pet Paw Trimmer

information NOTE
During use, pay attention to the cutting edge and position, do not use excessive force as it causes skin irritation.

  1. Pet Nail Grinder
    Used to groom your pet's nails.
    Use of Different Accessories - Pet Nail Grinder

information NOTE
Be careful on the soft parts of the pet's skin, and do not use excessive force as it causes skin irritation.

Accessory and Power Mode

  • The following chart is for advice only, please choose accessories and modes according to your needs!
Accessory Power Mode
Silence Mode Standard Mode Max Mode
Cleans fallen hair from the sofa, corner, or other hard-to-reach areas Cleans the fallen hair from the sofa, corner, or other hard-to-reach areas Deep cleaning of stubborn dust. (A little noisy, but recommended)
Cleans surface dust and makes the hair smooth Airflow massage makes the hair glossy. (Recommended) Deep cleaning to remove dead hair. (A little noisy)
Trim styling, handling hairstyle detail. (Recommended) With soft suction to trim and suck removed hair. Don't recommend.
Soft suction power to clean the pet hair on clothes. Deep clean hair on your clothes Strong suction power. (A little noisy, but recommended)
Remove loose hair. With soft suction to de-shed pet hair. Suction to de-shed pet hair. (A little noisy)
For dog and cat paws, eyes, ears, face, and rump hair. With soft suction to trim and suck removed hair. Don't recommend.
Polish your pet's nails by rounding them out. With soft suction to trim pet's nails. Don't recommend.

Care and Maintenance

Cleaning the Dust Cup

  1. Press the remove button and take off the dust cup.
     Cleaning the Dust Cup - Step 1
  2. Press the release button and pour out the hair.
     Cleaning the Dust Cup - Step 2
  3. Assemble the dust cup according to the arrow direction
     Cleaning the Dust Cup - Step 3
  • If the removed dust cup is cleaned with water or a wet cloth, be sure to install it after the dust cup is completely dry. Otherwise, it will damage the motor.
  • Please take dust cup lightly, if it drops will damaged easily, if have any problems with the cup, please contact us on Amazon or contact us email: support@oneisall.com

Cleaning the Electric Clippers

  1. Remove the blade by turning it counterclockwise.
    Cleaning the Electric Clippers - Step 1
  1. Vacuum out and clean the debris from the blade and the clipper.
    Cleaning the Electric Clippers - Step 2
  1. Place oil on the blade.
    Cleaning the Electric Clippers - Step 3
    Note: Our products do not contain oil, you need to buy it yourself.

Cleaning the HEPA & Sponge Filter

  1. Remove the dust cup and remove the HEPA & sponge filter.
    Cleaning the HEPA & Sponge Filter - Step 1
  1. Tap it or clean it with brush. Don't wash it with water.
    Cleaning the HEPA & Sponge Filter - Step 2
  1. Place the HEPA & sponge filter back into the machine.
    Cleaning the HEPA & Sponge Filter - Step 3

Troubleshooting

Problems Possible Causes Solutions

Cannot be turned on

Plug not been inserted well Reinsert the plug
Switch not been turned on Press switch button to turn it on

Weak suction

Flexible hose is clogged Clean flexible hose and suction mouth
Dust cup is too full Empty dust cup
Filter is dirty Clean filter

The Pet Clippers heats up during use

Internal parts of the machine have debris Please remove the blade. Wash and oil

The hose is broken

Accidental damage The hose is detachable and can be stored in the bag we provided
Bitten by pets at home

Whistle-like noise when the machine is running

The Dust Cup snap is not aligned Please check whether the Dust Cup is installed
  • If the above solutions do not solve the problem, please stop using the product, and contact our customer support: support@oneisall.com

information NOTE
The product is equipped with voltage protection device. If you hear a "didi" sound when you press the switch, and the gear lights are all flashing, means that the machine voltage is not consistent. Please check your voltage. If you have any problems, please contact us at any time with our email support@oneisall.com

Safety Warnings and Use Precautions

  • This product is only for home use, not for commercial or industrial use, nor for outdoor or humid places.
  • Supervise use for children and people with physical and mental disabilities.
  • Please use the machine in a safe environment and under the instruction and supervision of a person who understands the safe use method and dangers of the product. In the absence of such a person, never let a child use it
  • Please pay attention when using it near children and pets. In addition, please do not let children and pets play with this product.
  • Please do not touch the power plug and the product with wet hands.
  • Do not use this product if the power cord or power plug is damaged
  • Do not use this product if the power cord is damaged or if the product is not working normally or damaged; contact our company.
  • Please do not disassemble the product; the wrong assembly method may cause electric shock or fire; please contact our company if maintenance is needed
  • Please do not inhale flammable or combustible liquids such as gasoline; in addition, please do not use the machine in or near an environment with flammable or combustible gases
  • Do not pull the power cord, do not put heavy objects on top of the machine, and do not pinch the cord.
  • Do not use it while smoking or working with other high-temperature items (matches, hot ash, etc.)
  • Please do not put things into the opening or block the opening.
  • Please unplug the power cord when you need to change the parts or conduct maintenance.
  • Please do not use or keep it outdoors or in other wet places.
  • Please do not use products with fragrance as the fragrance may contain flammable chemicals.

Use Precautions

  • Please do not operate with wet hands or unplug the power cord to avoid failure and electric shock.
  • Please do not smoke or use other flammable material. Please do not use the machine in or near an environment with flammable or combustible gases.
  • There may be a strange smell during the first use; however, it will not cause adverse effects on the body.
  • When using this product for the first time, it will smell, but it will disappear after a while. Please understand, however, that if the scorching smell persists, stop using it immediately!
  • Please keep the dust cup and filter clean; if the dust cup and filter are used while dirty, they may cause failure, and unexpected accidents may occur.
  • During maintenance, turn off the power supply and unplug the power cord before proceeding.
  • If the power is turned on for maintenance, it will cause electric shock, unexpected accidents, or injury.
  • The product will stop working when the temperature rises abnormally; in case of abnormal heating of the motor, stop using it immediately. If the suction opening is blocked, please stop using it immediately. Take out the dust cup and clean the inlet and filter, then open it again after 60 minutes. Please be sure to install and use the filter; if you remove the filter, it will lead to failure.

How to Initiate a Warranty Claim

If your appliance operates improperly while in use under normal household conditions within the warranty period, please contact our customer support team [support@oneisall.com] to initiate a warranty claim

For more warranty details, please refer to www.oneisall.com.

Any problems you have, please contact us: support@oneisall.com

Scan the QR-Code to get the product installation video and join us to get more prize
