Summary of Contents for oneisall PFD-002
- Page 1 Automatic Pet Feeder with Dial PFD-002 User Manual ON-D03EU...
- Page 2 Video Tutorial oneisall Support oneisall Official Community Thank you for choosing us! To use the feeder correctly, please take a moment to read this User Manual before you use the product.If any accessories are missing, there are quality issues, or you have any questions about this feeder’s usage, please feel free to contact us via support@oneisall.com...
-
Page 3: Table Of Contents
Contents In the Package Product Overview LED Display Introduction Assemble the Feeder Program Settings Statement for LED Display The Desired Amount of Kibbles Tips for Cleaning Specification Use Precautions Troubleshooting Warranty... -
Page 4: In The Package
In the Package 1xAutomatic 2xStainless Steel 1xPower Cord 1xDesiccant Bag Pet Feeder Bowl and Holder with Adapter Quick Guide 1xUser Manual 1xQuick Guide 1xSponge 4xMetal Post 2xFood Slides Product Overview Lid button Food tank Desiccant box Switch for LED Display Battery compartment the tank Dial... -
Page 5: Led Display Introduction
LED Display Introduction Set the Manual feeding current time Schedule the Record a feeding plan message The dial to adjust numbers or press to confirm the settings. Current time or feeding time Lock/unlock Reset the feeder The amount of kibbles you would Battery icon. -
Page 6: Assemble The Feeder
Assemble the Feeder 1. Take out the machine, press 2. Invert the machine and install 4 the button in front of the top lid, AA batteries. open the tank and take out all Note: accessories. The back-up batteries are not included in the package. - Page 7 5. Take out 4 metal posts and insert 6. Align the 2 holes at the bottom of the them into four holes at the bottom of bowl holder with 2 metal posts and the machine. install them properly. Do the same on the other side.
-
Page 8: Program Settings
Program Settings You may need to know before setting: If the feeder is locked, press and hold the button for 3 seconds to unlock it. Click for confirmation. Rotate to select menu and adjust numbers. Current Time Setting 1. Rotate the dial to select the TIME 2. - Page 9 Feed Plan Settings 1. Rotate the dial to select the FEED 2. Turn the dial to select the feed serial PLAN menu. Click to enter the feed number.and click the dial to confirm it. settings. 4. Turn the dial to adjust the portion 3.
- Page 10 Manual Feeding Setting 1. Rotate the dial to select the 2. Click it to release 1 portion of food. FEED menu. Note: When the FEED menu flashes, click the dial for multiple times within 1 second to release more portions. Record A Message 1.
-
Page 11: Statement For Led Display
Reset the Feeder 1. Rotate the dial to select 2. Press and hold for 7 seconds to restore the device to factory settings. Tips: You will hear 2 sounds of Beep when the feeder restore to factory. Statement for LED Display 1. -
Page 12: The Desired Amount Of Kibbles
5. The battery icon only occurs when 6. The meal serial number would be off using the battery as the only power when the plan execution is completed. supply. The icon would flash when the It would lights up again at 12:00 AM. battery gets low. - Page 13 Here are the steps: 1. In the following steps, let's assume that your two pets eat the same amount. 2. For example, ½ cup equals to 6 portions, so ¼ cup would equals to 3 portions. ½ 6 portions ¼ 3 portions 3.
-
Page 14: Tips For Cleaning
Tips for Cleaning 1. Unplug the charging cord before 2. Unlock the tank and take it off. cleaning. Pour out the remaining cat food. 3. Wash the lip, food tank, stainless 4. The machine and tank base can steel bowl, and bowl holder. Then air only be cleaned with a soft dry cloth. -
Page 15: Specification
Specification Model: PFD-002 Product Size: 7.4 x 7.2 x 9.9 in Capacity: 20 Cups (4.7 lb dry food) Portion Size: 6 Portions=1/2 Cup=55 G Material: ABS+304 stainless steel Input: 5V DC/1A Food: Dry food, less than 0.5 inch in diameter... -
Page 16: Troubleshooting
The feeder can not work Unplug the cord and use new batteries to see if it works. Desiccant Replacement Email us:support@oneisall.com Try to press and hold it for 3 seconds to unlock the The dial do not work feeder. Make sure the kibble size less than 0.5 inch in diameter. -
Page 17: Warranty
Oneisall offers a standard 2-year warranty. If you have any issues with your Oneisall product, please do not hesitate to contact us. Be sure to include your proof of purchase, model number, and any relevant photos or videos in your message to expedite the process. - Page 18 Video Tutorial oneisall Support oneisall Official Community...
Need help?
Do you have a question about the PFD-002 and is the answer not in the manual?
Questions and answers
Any way to block one of the discharges to convert to a one feeder?
The Oneisall PFD-002 feeder is designed for dual-pet feeding, but the manual does not provide instructions for blocking one discharge port. To convert it to a single feeder, you can physically block one of the food outlets using a safe, non-toxic material that fits securely and prevents food from dispensing. Ensure the blockage does not interfere with the feeder’s operation or internal mechanisms.
This answer is automatically generated
The LED display is not showing. I have new batteries installed and it is also plugged into an outlet (the outlet does work). The feeder works fine but I can't see anything on the display to change time, record a new message, if battery is low, etc.
If the Oneisall PFD-002 feeder is using only batteries, the LED display turns off automatically to save power, but the feeder still works normally. If the feeder is plugged in and the display is still not showing, check if the cord is connected properly or try using a different Type-C charging cord. If the issue persists, unplug the cord and use new batteries to see if the display turns on.
This answer is automatically generated
