Refer to Safety chapters.
Refer to installation instruction document to install your appliance.
Fix the appliance in accordance with installation instruction document to avoid a risk of instability of the appliance.
Overall dimensions ¹
H1 | mm | 1769 |
W1 | mm | 556 |
D1 | mm | 549 |
¹ the height, width and depth of the appliance without the handle
Space required in use ²
H2 (A+B) | mm | 1816 |
W2 | mm | 560 |
D2 | mm | 552 |
A | mm | 1780 |
B | mm | 36 |
² the height, width and depth of the appliance including the handle, plus the space necessary for free circulation of the cooling air
Overall space required in use ³
H3 (A+B) | mm | 1816 |
W3 | mm | 780 |
D3 | mm | 1085 |
³ the height, width and depth of the appliance including the handle, plus the space necessary for free circulation of the cooling air, plus the space necessary to allow door opening to the minimum angle permitting removal of all internal equipment
To ensure appliance's best functionality, you should not install the appliance in a place with direct sunlight. Do not install the appliance close to radiators or cookers, ovens, or hobs, unless otherwise specified in the installation instructions.
Make sure that air can circulate freely around the back of the cabinet.
This appliance should be installed in a dry, well ventilated indoor position.
This appliance is intended to be used at ambient temperature ranging from 10°C to 43°C.
Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed.
The wires in the mains lead are coloured in accordance with the following code:
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:
A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard.
Ensure that it is disposed of safely.
The airflow behind the appliance must be sufficient.
Refer to the installation instructions for the installation.
Please refer to the separate document with instructions on installation and door reversal.
At every stage of reversing the door protect the floor from scratching with a durable material.
It is possible to change predefined sound of buttons by pressing together Mode and temperature colder button for a few seconds. Change is reversible.
To select a different set temperature refer to "Temperature regulation".
If "dEMo" appears on the display, refer to "Troubleshooting".
Set the temperature of the appliance by pressing the temperature regulators.
Recommended set temperature is:
The temperature range may vary between 2°C and 8°C for fridge.
The temperature indicators show the set temperature.
The set temperature will be reached within 24 hours.
After a power failure the set temperature remains stored.
If you need to insert in the fridge compartment a large amount of warm food, for example after doing the grocery shopping, we suggest activating the FastCool function to chill the products more rapidly and to avoid warming the other food which is already in the refrigerator.
This function stops automatically after approximately 6 hours.
You can deactivate the FastCool function before its automatic end by repeating the procedure or by selecting a different fridge set temperature.
This mode allows you to keep the appliance empty during a long holiday period reducing the formation of bad odours.
This mode switches off after selecting a different temperature.
The refrigerator compartment is equipped with a device that allows rapid cooling of food and keeps more uniform temperature in the compartment.
This device activates automatically when needed or manually.
To switch on the function:
To switch off the function repeat the procedure until the DYNAMICAIR indicator turns off.
If the function is activated automatically the DYNAMICAIR indicator is not shown (refer to "DYNAMICAIR" section in "Daily use").
The activation of the DYNAMICAIR function increase the energy consumption.
The fan operates only when the door is closed.
Activate the ChildLock function to lock the buttons from unintentional operation.
To deactivate the ChildLock function, repeat the procedure until the ChildLock indicator turns off.
The DrinksChill function is to be used to set an acoustic alarm at the preferred time, useful for example when a recipe requires to cool down food products for a certain period of time.
The Timer starts to flash (min). At the end of the countdown the "0 min" indicator flashes and an audible alarm sounds. Press OK to switch off the sound and terminate the function.
To switch off the function repeat the procedure until the DrinksChill indicator turns off.
It is possible to change the time at any time during the countdown and at the end by pressing the Temperature colder button and the Temperature warmer button.
If the fridge door is left open for approximately 5 minutes, the sound is on and alarm indicator flashes.
The alarm stops after closing the door. During the alarm, the sound can be muted by pressing any button.
If you do not press any button, the sound switches off automatically after around one hour to avoid disturbing.
This refrigerating appliance is not suitable for freezing foodstuffs.
To permit storage of food packages of various sizes, the door shelves can be placed at different heights.
The walls of the refrigerator are equipped with a series of runners so that the shelves can be positioned as desired.
This appliance is also equipped with a shelf consisting of two parts. The front half of the shelf can be placed under the second half to make better use of space.
To fold the shelf:
Do not move the glass shelf above the vegetable drawer to ensure correct air circulation.
The drawer is suitable for storing fruit and vegetables. To remove the drawer (e.g. for cleaning):
To reassemble:
Pull out the drawer again and check if it is placed correctly on both rear and front hooks.
The glass shelf incorporates a device with slits (adjustable by means of a sliding lever), which makes it possible to regulate the humidity in the vegetable drawer(s).
Do not place any food products on the humidity control device.
The position of the humidity control depends on the type and on the amount of fruits and vegetables:
The refrigerator compartment is equipped with a device that allows rapid cooling of foods and keeps more uniform temperature in the compartment.
Do not remove the Styrofoam at the bottom of the device.
This device activates automatically when needed.
It is also possible to switch on the device manually when needed (refer to "DYNAMICAIR function").
The fan operates only when the door is closed.
Your appliance is equipped with the CleanAir carbon filter in a drawer inside the DYNAMICAIR device.
The filter purifies the air from unwanted odours in the fridge compartment, improving the storage quality.
On delivery, the filter is in a plastic bag (refer to "Care and cleaning" chapter for the installation).
During the operation, always keep the air ventilation drawer closed.
Refer to Safety chapters.
Before using the appliance for the first time, the interior and all internal accessories should be washed with lukewarm water and some neutral soap to remove the typical smell of a brand-new product, then dried thoroughly.
Do not use detergents, abrasive powders, chlorine or oil-based cleaners as they will damage the finish.
The accessories and parts of the appliance are not suitable for washing in a dishwasher.
The equipment has to be cleaned regularly:
Frost is automatically eliminated from the evaporator of the refrigerator compartment during normal use. The defrost water drains out through a trough into a special container at the back of the appliance, over the motor compressor, where it evaporates.
It is important to periodically clean the defrost water drain hole in the middle of the refrigerator compartment channel to prevent the water overflowing and dripping onto the food inside.
For this purpose use the tube cleaner provided with the appliance.
The CleanAir filter is an active carbon filter which absorbs bad odours and permits to maintain the best flavour and aroma for all foodstuffs without risk of odour cross contamination.
The air filter should be handled carefully to prevent its surface from being scratched.
On delivery, the carbon filter is in a plastic bag to preserve performance. Place the filter in the slot before activating the appliance.
The air filter is a consumable accessory and as such is not covered by the guarantee.
New active air filters can be purchased from your local dealer. To change the air filter repeat the procedure.
When the appliance is not in use for long period, take the following precautions:
Refer to Safety chapters.
Problem | Possible cause | Solution |
The appliance does not operate. | The appliance is switched off. | Switch on the appliance. |
The mains plug is not connected to the mains socket correctly. | Connect the mains plug to the mains socket correctly. | |
There is no voltage in the mains socket. | Connect a different electrical appliance to the mains socket. Contact a qualified electrician. | |
The appliance is noisy. | The appliance is not supported properly. | Check if the appliance stands stable. |
Acoustic or visual alarm is on. | The door is left open. | Close the door. |
The compressor operates continually. | Temperature is set incorrectly. | Refer to "Control panel" chapter. |
Many food products were put in at the same time. | Wait a few hours and then check the temperature again. | |
The room temperature is too high. | Refer to "Installation" chapter. | |
Food products placed in the appliance were too warm. | Allow food products to cool to room temperature before storing. | |
The door is not closed correctly. | Refer to "Closing the door" section. | |
The FastCool function is switched on. | Refer to "FastCool function" section. | |
The compressor does not start immediately after pressing the "Fast‐Cool", or after changing the temperature. | The compressor starts after a period of time. | This is normal, no error has occurred. |
Door is misaligned or interferes with ventilation grill. | The appliance is not levelled. | Refer to installation instructions. |
Door does not open easily. | You attempted to re-open the door immediately after closing. | Wait a few seconds between closing and re-opening of the door. |
The lamp does not work. | The lamp is in stand-by mode. | Close and open the door. |
The lamp is defective. | Contact the nearest Authorized Service Centre. | |
There is too much frost and ice. | The door is not closed correctly. | Refer to "Closing the door" section. |
The gasket is deformed or dirty. | Refer to "Closing the door" section. | |
Food products are not wrapped properly. | Wrap the food products better. | |
Temperature is set incorrectly. | Refer to "Control panel" chapter. | |
Appliance is fully loaded and is set to the lowest temperature. | Set a higher temperature. Refer to "Control panel" chapter. | |
Temperature set in the appliance is too low and the ambient temperature is too high. | Set a higher temperature. Refer to "Control panel" chapter. | |
Water flows on the rear plate of the refrigerator. | During the automatic defrosting process, frost melts on the rear plate. | This is correct. |
There is too much condensed water on the rear wall of the refrigerator. | Door was opened too frequently. | Open the door only when necessary. |
Door was not closed completely. | Make sure the door is closed completely. | |
Stored food was not wrapped. | Wrap food in suitable packaging before storing it in the appliance. | |
Water flows inside the refrigerator. | Food products prevent the water from flowing into the water collector. | Make sure that food products do not touch the rear plate. |
The water outlet is clogged. | Clean the water outlet. | |
Water flows on the floor. | The melting water outlet is not connected to the evaporative tray above the compressor. | Attach the melting water outlet to the evaporative tray. |
Temperature cannot be set. | The FastCool function is switched on. | Switch off FastCool function manually, or wait until the function deactivates automatically to set the temperature. Refer to "FastCool function" section. |
The temperature in the appliance is too low/too high. | The temperature is not set correctly. | Set a higher/lower temperature. |
The door is not closed correctly. | Refer to "Closing the door" section. | |
The food products' temperature is too high. | Let the food products temperature decrease to room temperature before storage. | |
Many food products are stored at the same time. | Store less food products at the same time. | |
The door has been opened often. | Open the door only if necessary. | |
The FastCool function is switched on. | Refer to "FastCool function" section. | |
There is no cold air circulation in the appliance. | Make sure that there is cold air circulation in the appliance. Refer to "Hints and tips" chapter. | |
DEMO appears on the display. | The appliance is in the demonstration mode. | To exit the demonstration mode, press and hold the OK button for approximately 10 seconds until you hear a long sound and the display turns off for a short time. |
A ![]() ![]() ![]() | Temperature sensor problem. | Contact the nearest Authorized Service Centre. The cooling system will continue to keep food products cold, but temperature adjustment will not be possible. |
If the advice does not lead to the desired result, call the nearest Authorized Service Centre
The appliance is equipped with a long life LED interior light.
Only service is allowed to replace the lighting device. Contact your Authorised Service Centre.
The technical information is situated in the rating plate on the internal side of the appliance and on the energy label.
The QR code on the EU and UK energy labels supplied with the appliance provide a web link to the information related to the performance of the appliance. For the energy label with the EU flag, it is also possible to find the information in the EU EPREL database using the link https://eprel.ec.europa.eu and the model name and product number that you find on the rating plate of the appliance. Keep the energy labels for reference together with the user manual and all other documents provided with this appliance.
Installation and preparation of the appliance for any EcoDesign verification shall be compliant with BS EN 62552 (UK) or EN 62552 (EU). Ventilation requirements, recess dimensions and minimum rear clearances shall be as stated in this User Manual in "Installation". Please contact the manufacturer for any other further information, including loading plans.
Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
Only a qualified person must install this appliance.
Risk of fire and electric shock.
When positioning the appliance, ensure the supply cord is not trapped or damaged.
Do not use multi-plug adapters and extension cables.
Risk of injury, burns, electric shock or fire.
The appliance contains flammable gas, isobutane (R600a), a natural gas with a high level of environmental compatibility. Be careful not to cause damage to the refrigerant circuit containing isobutane.
Risk of electric shock.
Risk of injury or damage to the appliance.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information: www.electrolux.com/support
Register your product for better service: www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance: www.electrolux.com/shop
* When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
