REMOVING & REPLACING THE HARNESS STRAP:
1. Unhook the four inner and outer face seal skirt loops from the harness mounting points inside the helmet.
2. Remove the harness strap by un-popping the arm from the receiver (hold the helmet and receiver firmly whilst doing so).
3. Repeat this process for all the arms then take the harness strap out from the helmet. Dispose of used strap in accordance with
local legislation.
4. Place the replacement strap inside the helmet shell, then pop the first arm back into position and repeat the process for all the arms.
5. Feed the outer set of skirt loops behind the harness strap inside the helmet. Hook the loops over the harness mounting points inside
the helmet.
6. Hook the inner set of skirt loops over the harness mounting point and outer loops. Repeat with the loops on the other end of the
sealing skirt.
7. The foam blocks must be exposed as shown in figure 7.
1
SKIRT LOOPS
4
7
2
5
15
3
6
