Free Standing Patio Heater Dimensions; Built-In Patio Heater Dimensions; Gas Requirements For Free Standing Patio Heater; Gas Requirements For Built-In Patio Heater - DCS PHFS-P4 Datasheet

Free Standing Patio Heater Dimensions

33"
17"

Built-in Patio Heater Dimensions

Minimum Distance to Combustible Material

Installation to combustible (front view)
Summer 2008
51
6"
85"
MODEL NUMBER
HEATER BTU/HR
SAFETY SHUT-OFF
31"
Ordering Data: Please specify gas type
(natural or propane) when ordering.
19"
MODEL NUMBER
HEATER
EXTENSION MOUNTING KIT
Minimum Distance to Combustible Material
19" min.
Gas Requirements:
Natural
PHFS-P4
• 1/2" NPT male with a 3/8" flare adapter
40,000
• Operational Pressure: 4" W.C.
• Supply Pressure: 5" to 9" W.C.

Propane
• 1/2" NPT male with a 3/8" flare adapter
• Operational Pressure: 10" W.C.
• Supply Pressure: 11" to 14" W.C.
30° installation to combustible
(side view)
DCS-DRH-48N
56,000 BTU/HR

27" min.
0° installation to combustible
(side view)
Gas Requirements:
Natural
• Max. Pressure: 1/2 psig
• Min. Pressure: 6" W.C.
• Manifold Pressure: 5" W.C.
• Internal 5" W.C. regulator
