DeluxeFlushElectricToilets
Instruction Manual
Fresh Water
Sea Water
Solenoid Valve
Switch Panel
Rinse Pump
Switch Panel
SFMTE1-06 12V
SFMTE1-05 12V
SFMTE2-05 24V
SFMTE2-06 24V
SEAFLO Deluxe Flush Electric Toilets feature low noise levels, so sleeping guests will not be
disturbed when the toilet is used. There are options of either flushing with fresh water from the
boat's own supply or with salt, river or lake water from outside the boat. All plumbing and wiring
easily concealed.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Seaflo SFMTE1-06
Summary of Contents for Seaflo SFMTE1-06
- Page 1 SFMTE2-05 24V SFMTE2-06 24V SEAFLO Deluxe Flush Electric Toilets feature low noise levels, so sleeping guests will not be disturbed when the toilet is used. There are options of either flushing with fresh water from the boat's own supply or with salt, river or lake water from outside the boat. All plumbing and wiring...
-
Page 2: Specifications
APPLICATIONS You may install SEAFLO Deluxe Flush Toilet electrically operated marine toilets in both power and sailing craft, either above or below the waterline, for use on sea, river, lake or canal. Your installation may discharge the waste either overboard (provided that your national and local regulations allow this), or into a treatment system or into an on-board holding tank (U.S.C.G. -
Page 3: Installation Instructions
HAZARD RISK: ACCIDENTAL DAMAGE. INSTALLATION INSTRUCTIONS USE SEACOCKS! Your toilet is just one part of a system. Correct installation of the whole system is essential if you If the toilet is connected to any through-hull fittings and if the toilet or pipework is want the toilet to perform properly, operate reliably and safely, and give satisfactory length of life. - Page 4 Option 2: Toilet always above the heeled waterline Avoid sharp bends in the hoses as this may cause them to become kinked. Keep all pipework runs as straight and as short as possible, avoiding rising and falling over obstructions Run ¾” (19mm) hose by the most direct route from the inlet seacock to the inlet of the strainer fitted to the which creates airlocks.
-
Page 5: Servicing Instructions
flows into the toilet bowl. Thereafter they are automatically switched by the Control Panel. SAFETY SEAFLO Deluxe Flush Electric Toilets do not normally require maintenance during the season, provided that they are winterised in the autumn. Ensure that this instruction manual reaches the owner, skipper or operator of the craft as it contains essential Regularly check all fastenings for tightness and leaks. - Page 6 SERVICING - FLUSH PUMP FIT NEW SHAFT SEAL You must: Have perfectly clean and dry fingers when you handle the ceramic seal, or wear surgical gloves. CAUTION! Do NOT allow anything at all to touch or fall onto the mating faces of the Place the toilet upside down, loosen the new ceramic seal! three clamps with a screwdriver in turn, and...
-
Page 7: Electrical Connections
SERVICING & WINTERISATION - PREPARATION SEAFLO Deluxe Flush Electric Toilets are designed to be user serviceable and no special skills are required. Flush the toilet in accordance with the operating instructions and ensure that all waste has left the discharge pipework and that the bowl is empty. -
Page 8: Exploded View
SERVICING - TESTING EXPLODED VIEW Open inlet and outlet seacocks (and secondary valves if fitted). Switch on power of replace fuse. Use touch pad controller as described on page 2, to check all functions, and then inspect for leaks. ON COMPLETION - CLOSE BOTH SEACOCKS TROUBLESHOOTING BOWL FILLS WHEN NOT IN USE Shut seacocks...
