  • Page 1 Installation and handling manual Solid fuel floor stove SD THERMO VULKAN PLUS...
  • Page 3: Table Of Contents

    Solid fuel floor stove - SD THERMO VULKAN PLUS DEAR CUSTOMER We appreciate your trust dedicated to us and your determination to buy our product. You made a good choice, since this stove has technical characteristics which place it into top class, and you will be assured of it during exploitation.
  • Page 4: Warning Before Usage

    Installation and handling manual WARNING BEFORE USAGE To obtain proper operation of your stove, it is important to read this manual and strictly observe directions for use and handling. For combustion, use solid fuels like woods, briquettes and low-caloric coal. It is forbidden to put explosive devices and materials into the burner or on the plate.
  • Page 5: Description

    Solid fuel floor stove - SD THERMO VULKAN PLUS STOVE DESCRIPTION Floor stove THERMO VULKAN PLUS S is produced and tested according to the European standard EN 13240. On figure no. 1 given in the introduction page, layout of the stove with integral parts important for handling is displayed.
  • Page 6 Installation and handling manual Floor stoves are intended for heating of residential facilities. Integral part of installation is thermal exhaust valve which serves as thermal fuse against eventual overheating. Recommended thermal fuse is Caleffi 544 ½, displayed in fig. 2. Exhaust valve for thermal protection limits water temperature in the boiler with installed heat exchanger for urgent interventions.
  • Page 7: Installation

    Solid fuel floor stove - SD THERMO VULKAN PLUS INSTALLATION Do not put the stove in direct vicinity of wooden elements, cooling devices, plastic parts of the furniture and other inflammable materials, since it creates high working temperature which is distributed at the exterior of the oven. The least distance between stove and surrounding elements is 50 cm, and from inflammable 80 cm.
  • Page 8: Installation To The Water Heating System

    Installation and handling manual As depicted in figure 4, defaults of the chimney may be: 1. Chimney is lower then top of the roof, small cross section of the exit 2. Too large slope 3. Abrupt alteration of the direction of smoke channel, 4.
  • Page 9 Solid fuel floor stove - SD THERMO VULKAN PLUS Layout of the closed central heating system Figure 5.1 - with fourfold mixing valve BOILER Figure 5.2 - with leaning pipe thermostat BOILER Pump Valve 1 Feeding line 2 System filling and emptying duct...
  • Page 10 Installation and handling manual Mounting on open heating system One of the aspects of carrying out installations is shown on fig. 6. At this system, on initial guide: safety distribution guide of expansion vessel and valve of the boiler are to be installed in order, and on initial guide of the system boiler valve, pump and valve are to be installed.
  • Page 11 Solid fuel floor stove - SD THERMO VULKAN PLUS Layout of the open central heating system Figure 6.1 - with fourfold mixing valve BOILER Figure 6.2 – with leaning pipe thermostat BOILER 1. Feeding line Pump 2. Overflow pipe with valve...
  • Page 12: Firing Up And Stoking

    Installation and handling manual FIRING UP AND STOKING Prior to the first stoking, wipe all enameled surfaces of the stove with dry mop to avoid combustion of dirt on the stove and creation of unpleasant scents. Firing up in the burner should be carried out as follows: •...
  • Page 13: Managing Operation Of The Stove

    Solid fuel floor stove - SD THERMO VULKAN PLUS We recommend burning on each 1h with the height of the fuel in the burner up to 15 cm with crosswise positioning of the woods due to higher air flow. Upon each filling, it is recommended to let stove to burn at least 30 minutes with maximal power, in order to burn all evaporable ingredients which are the reason of creation of condensate in the stove in this stage of combustion.
  • Page 14: Cleaning And Maintenance

    Installation and handling manual Stove is intended for operation in periodical mode. For maintenance of necessary nominal power, burner is to be periodically filled with indicated amount of fuel. Stove is not intended to operate in the mode of continual fire or in mode of heat accumulation.
  • Page 15: Irregularities During Operation And Troubleshooting

    Solid fuel floor stove - SD THERMO VULKAN PLUS a) Open oven door b) Remove cover from the c) Clean the boiler pipe oven bottom by unscrewing 6 screws Fig. 9. Procedure for boiler pipe cleaning Cleaning of glass surfaces – burner glass gets dirty during operation. For cleaning, use soft detergents.
  • Page 16: General Remarks

    Installation and handling manual - use dry woods Burner door glass - wet woods - see recommended amount of fuel for has tar after - too much fuel combustion given in the manual a short period - check connection with the chimney of operation - lack of air flow - carefully read manual and apply tips for...
  • Page 17: Environmental Issues

    Solid fuel floor stove - SD THERMO VULKAN PLUS ENVIRONMENTAL ISSUES Packaging - Packaging material may be 100 % recycled. - At disposing of the waste, observe local regulations. - Packaging material (plastic bags, parts of polystyrene-styropor etc.) should be kept out of reach of children, since it is potential source of danger.
  • Page 18 Installation and handling manual...
  • Page 20 Maber Comerc doo Smederevo Djure Strugara 20 l 11300 Smederevo l Serbia l tel: +381 26 633 600 / +381 26 633 601 l fax: +381 26 4629 941...
