  • Page 1 DPtech DPX29000 Series Switches Installation Manual...
  • Page 2 Owing to product upgrading or other reasons, information in this manual is subject to change. Hangzhou DPtech Technologies Co., Ltd. has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech Technologies Co., Ltd. made every effort...

  • Page 3: Table Of Contents

    DPtech DPX29000 Series Installation Manual v1.1.docx Contents 1 Product Introduction ..........................1-1 1.1 Product overview ..........................1-1 1.2 DPX29000 series product appearance ..................... 1-2 1.3 Product specifications ........................1-6 1.3.1 Chassis dimensions and weight ....................1-6 1.3.2 Voltage and current ......................... 1-6 1.3.3 Backplane ..........................
  • Page 4 DPtech DPX29000 Series Installation Manual v1.1.docx 2.2.10 Ventilation requirements ......................2-7 2.2.11 Space requirements ......................2-7 2.3 Installing tools ............................ 2-8 2.3.1 Installation accessories that come with the device ..............2-8 2.3.2 User-brought tools and equipment ..................2-8 3 Switch Installation ..........................3-1 3.1 Confirmation before installation ......................
  • Page 5 DPtech DPX29000 Series Installation Manual v1.1.docx 5.1 Power system problem handling ....................... 5-1 5.2 Motherboard troubleshoot ......................... 5-1 5.3 Line card troubleshooting ........................5-2 5.4 Exchange network board troubleshooting ..................5-3 5.5 Fan fault handling ..........................5-3 5.6 Configure system troubleshooting ..................... 5-4...

  • Page 6: Product Introduction

    DPX29000 series adopts advanced CLOS+ multi-level multi-plane orthogonal switching architecture, providing the industry's highest switching performance and the most rich cloud computing features. The DPtech DPX29000 series includes two models, as shown in Table 1-1 . Table 1-1 DPX29000 series models Main Control Board...

  • Page 7: Dpx29000 Series Product Appearance

    DPtech DPX29000 Series Installation Manual v1.1.docx DPX29000 series product appearance DPX29000-A10/DPX29000-A10-G chassis appearance and description (10) Figure 1-1 Front view of DPX29000-A10/DPX29000-A10-G (1) Main control slot (M1) (2) Main control slot (M2) (3) Service slot (L1) (4) Service slot (L2)
  • Page 8 DPtech DPX29000 Series Installation Manual v1.1.docx (1) (2) (4) (5) (6) (7)(8) (10) (11) (12) (13) (14) (16) (15) Figure 1-2 Rear view of DPX29000-A10/DPX29000-A10-G (1) Fan tray LED (2) Switching network board LED (3) Fan tray (4) Fan tray...
  • Page 9 DPtech DPX29000 Series Installation Manual v1.1.docx DPX29000-A18/DPX29000-A18-G chassis appearance and description (10) (11) (12) (13) (14) (15) (16) (17) (18) Figure 1-3 Front view of DPX29000-A18/DPX29000-A18-G (1) Main control slot (M1) (2) Main control slot (M2) (3) Service slot (L1)
  • Page 10 DPtech DPX29000 Series Installation Manual v1.1.docx (15) Service slot (L13) (16) Service slot (L14) (17) Service slot (L15) (18) Service slot (L16) (1) (2) (3) (4) (5) (6) (10) (11) (12) (13) (14) (15) (16) (18) (17) Figure 1-4 Rear view of DPX29000-A18/DPX29000-A18-G...

  • Page 11: Product Specifications

    DPtech DPX29000 Series Installation Manual v1.1.docx Power supply (PWR2) (12) Power supply (PW2) (13) Power supply (PWR4) (14) Power supply (PWR5) (15) Power supply (PWR6) (16) Power supply (PWR7) (17) Ground terminal (18) Ground sign Product specifications 1.3.1 Chassis dimensions and weight...

  • Page 12: Backplane

    DPtech DPX29000 Series Installation Manual v1.1.docx Online plugging means that when the device is configured with multiple power modules, under the condition of ensuring the normal operation of the system business, before pulling out the power module, turn off the power switch first, and then pull out; Before inserting the power module, first confirm that the power switch is in the off state, and then turn on after inserting.

  • Page 13: Working Environment

    DPtech DPX29000 Series Installation Manual v1.1.docx The DPX29000-A10/DPX29000-A10-G and DPX29000-A18/DPX29000-A18-G use different fan trays and cannot be mixed and inserted. Table 1-4 Specification table of network board fan tray Maximum Power Fabric Frame Product Fan tray Size Consumption of a Fan...

  • Page 14: Main Control Board

    E-MPU (E-MPU main control board) Introduction The E-MPU main control board plays a leading role in the DPX29000 series products, which realizes the initial configuration, management and control message processing of the system. Copyright © Hangzhou DPtech Technologies Co., Ltd.
  • Page 15 DPtech DPX29000 Series Installation Manual v1.1.docx (3) (4) (10)(11) (12) (13) (16) (14) (15) Figure 1-5 Front view of the main control board (E-MPU) (1) Management Ethernet Interface (MGMT) (2) USB interface (0) (3) CONSOLE port (CON) (4) DEBUG port...
  • Page 16 DPtech DPX29000 Series Installation Manual v1.1.docx Managing Ethernet 1 (10/100/1000BASE-T) Interfaces CF cards USB port Reset buttons Weight 5.95 Kg Flash is used to store the bootloader file Conboot when booting. The memory is used to store the data when the system is running, and it is also used as the data cache when the packet is forwarded.
  • Page 17 DPtech DPX29000 Series Installation Manual v1.1.docx Indicates that no recognizable card has been inserted into the slot, or the initialization of the slot card has not been completed Blinking Indicates that the switching mesh board is green (1Hz) working properly...
  • Page 18 DPtech DPX29000 Series Installation Manual v1.1.docx parameters. Memory Memory is used to store the data that the system communicates with the CPU while it is running. CF card CF (Compact Flash Card, standard flash card) can be used for logging logs, storing multiple host files and different profile files, etc.
  • Page 19 DPtech DPX29000 Series Installation Manual v1.1.docx The 10/100/1000M Ethernet electrical and management Ethernet interfaces of the DPX29000 series use RJ45 connectors, and the ports support MDI/MDIX adaptation. In use, the use of category 5 twisted pair and RJ45 crystal head to make the network cable.

  • Page 20: E-Mpu-G (E-Mpu-G Main Control Board)

    CF card, otherwise the file system of the device may be damaged. 1.4.2 E-MPU-G (E-MPU-G main control board) Introduction The E-MPU-G main control board plays a leading role in the DPX29000 series products, which 1-15 Copyright © Hangzhou DPtech Technologies Co., Ltd.
  • Page 21 DPtech DPX29000 Series Installation Manual v1.1.docx realizes the initial configuration, management and control message processing of the system. （12） (10)(11) (3) (4) (13) (16) (14) (15) Table 1-8 Main control board (E-MPU-G) front view (1) Management Ethernet Interface (MGMT) (2) USB interface (0)
  • Page 22 DPtech DPX29000 Series Installation Manual v1.1.docx Managing Ethernet 1 (10/100/1000BASE-T) interfaces CF card USB port Reset buttons Weight 5.95 Kg Flash is used to store the bootloader file Conboot when booting. ⚫ The memory is used to store the data when the system is running, and it is also used as ⚫...
  • Page 23 DPtech DPX29000 Series Installation Manual v1.1.docx Blinking Indicates that the switching mesh board is green (1Hz) working properly (9) Switching network Indicates that the switching network board is board slot running status Steady red working abnormally LED (Fabric1) (Dual color, green/red)

  • Page 24: E-Mpu-Gs (E-Mpu-Eg Main Control Board)

    Reset button See also E-MPU. 1.4.3 E-MPU-GS (E-MPU-EG main control board) Introduction E-MPU-GS main control board plays a leading role in DPX29000 series products, and realizes the system initialization configuration, management and control message processing. (3)(4) (9) (10) (11)(12)(13) (14)
  • Page 25 DPtech DPX29000 Series Installation Manual v1.1.docx (11) // (VSM) (12) Reset button (RST) (13) Main control board Master/Standby (14) // (HA) Status LED (ACT) (15) Management Ethernet Interface LED (MGMT) DPX29000-A18/DPX29000-A18-G,DPX29000-A10/DPX29000-A10-G support dual master control boards. The master control slot is M1, M2.
  • Page 26 DPtech DPX29000 Series Installation Manual v1.1.docx Flash is used to store the bootloader file Conboot when booting. ⚫ The memory is used to store the data when the system is running, and it is also used as ⚫ the data cache when the packet is forwarded.
  • Page 27 DPtech DPX29000 Series Installation Manual v1.1.docx Indicates that the power supply is working Steady green properly (8) Power status LED Indicates that the power supply is working (PWR0) Steady red abnormally (Dual color, green/red) Indicates that the power is not available or there...

  • Page 28: Interface Board

    DPtech DPX29000 Series Installation Manual v1.1.docx Ethernet electrical interface See also E-MPU. USB port See also E-MPUA. Reset button See also E-MPU. Interface board 1.5.1 E-32CQ (32*100GE light) Introduction The interface board (E-32CQ) plugs into the service slot and provides 32 QSFP28 100GE Ethernet optical interfaces.

  • Page 29: E-16Cq-G (16*100Ge Light)

    DPtech DPX29000 Series Installation Manual v1.1.docx （2） Figure 1-13 Interface board (E-32CQ) running status LED Status Description (2) QSFP28 100GE Steady Indicates port 1 has established a connection optical interface status LED (monochrome, green) 1 Constant Indicates no connection has been established at port extinction 1.5.2...

  • Page 30: E-48Xgs-G (48*10Ge Light)

    DPtech DPX29000 Series Installation Manual v1.1.docx 3 LED （2） Figure 1-15 Interface board (E-16CQ-G) running status LED Status Description (2) QSFP28 100GE Steady Indicates port 1 has established a connection optical interface status LED (monochrome, green) 1 Indicates no connection has been established at port 1.5.3...

  • Page 31: E-24Gt20Gp4Xgs-G (24*Ge Electric +20*Ge Optical +4*10Ge Optical)

    DPtech DPX29000 Series Installation Manual v1.1.docx Specifications Table 1-11 Interface board (A-4CQ-A) specifications Project Specification Optical interface 4*100GBASE-T Ethernet optical interfaces (QSFP28) （2） Figure 1-17 Interface board (E-32CQ) running status LED Status Description (2) QSFP28 100GE Steady Indicates port 1 has established a connection...
  • Page 32 DPtech DPX29000 Series Installation Manual v1.1.docx （1） （2） （3） （4） （6） （5） Figure 1-18 Interface board (E-24GT20GP4XGS-G) front view (1) 10/100/1000M Ethernet electrical interface (2) 10/100/1000M Ethernet electrical interface 47 (1) SFP+ 10GE optical interface 0 (2) SFP+ 10GE optical interface status LED...

  • Page 33: E-72Tfg (72*25Ge Optical)

    DPtech DPX29000 Series Installation Manual v1.1.docx LED (monochrome, Indicates no connection has been established at port green) 1 1.5.5 E-72TFG (72*25GE optical) Introduction The interface board (E-72TFG) plugs into the service slot and provides 20 SFP28 Gigabit Ethernet optical interfaces.

  • Page 34: Board Of Service

    1.6.1 Power supply module The DPX29000 series supports AC and DC power supply mode. Users can choose AC or DC power modules according to their actual needs, but different types of power modules cannot be mixed into the same DPX29000 series deep service switching gateway.
  • Page 35 DPtech DPX29000 Series Installation Manual v1.1.docx AC power supply module (PSU-AC3000) Figure 1-22 AC power supply (PSU-AC3000) structure diagram (1) Power plug (2) Power input LED (3) Power output LED Table 1-14 AC power specifications Item Specification AC power supply model: 100V AC ~ 120V AC/ 200V AC ~ 240V AC;...
  • Page 36 DPtech DPX29000 Series Installation Manual v1.1.docx Blinking Indicates that the power module output is overloaded 1-31 Copyright © Hangzhou DPtech Technologies Co., Ltd.

  • Page 37: Preparation Before Installation

    DPtech DPX29000 Series Installation Manual v1.1.docx Preparation before Installation In order to avoid harm to people and equipment, please read this chapter carefully before installing the equipment to understand the matters that need to be paid attention to during installation, use and maintenance. The actual situation includes but is not limited to the following precautions.

  • Page 38: Rack/Cabinet

    DPtech DPX29000 Series Installation Manual v1.1.docx  Make sure the cabinet and workbench are strong enough to support the weight of the equipment and its mounting accessories.  Ensure that the cabinets and workbenches are well grounded. In order to ensure the normal work of the equipment and extend the service life, the installation site should also meet the following requirements.

  • Page 39: Temperature/Humidity Requirements

    DPtech DPX29000 Series Installation Manual v1.1.docx 2.2.2 Temperature/humidity requirements In order to ensure the normal operation and service life of the equipment, a certain temperature and humidity should be maintained in the machine room. (1) If the long-term humidity in the machine room is too high, it is easy to cause poor insulation or even leakage of insulation materials, and sometimes it is also easy to occur changes in mechanical properties of materials and rust of metal parts.

  • Page 40: Anti-Static Requirements

    DPtech DPX29000 Series Installation Manual v1.1.docx Table 2-2 Equipment room dust content requirements Mechanically Active Units Content Substances 3 x 10 or less Dust particles Grains /m³ (No visible dust on the desktop within 3 days) Note: dust particles ≥5µm in diameter In addition to dust, there are also strict requirements for acid, alkali and sulfide contained in the air in the equipment room.

  • Page 41: Anti-Interference Requirements

    DPtech DPX29000 Series Installation Manual v1.1.docx 2.2.5 Anti-interference requirements Switch in use may be from outside the system interference, these interference through capacitive coupling, inductive coupling, electromagnetic wave radiation, public impedance (including grounding system) coupling and wire (power line, signal line and output line, etc.) conduction mode on the equipment.

  • Page 42: Wiring Requirements

    Power supply requirements A good power supply system is the basis for the switch to start up and run stably. In order to meet the power supply requirements of DPX29000 series switches, please complete the following steps: (1) Estimate the overall power consumption of the switch.

  • Page 43: Ventilation Requirements

    DPtech DPX29000 Series Installation Manual v1.1.docx overall power consumption of the switch (it is recommended to reserve a certain power consumption derating). After determining the power consumption of the switch and the power supply mode (AC or DC), you can choose the appropriate number of power supply modules.

  • Page 44: Installing Tools

    DPtech DPX29000 Series Installation Manual v1.1.docx In order to facilitate heat dissipation and switch maintenance, please do not install the switch against the wall, and the space before and after the switch should not be less than 0.8 meters. Installing tools 2.3.1...

  • Page 45: Switch Installation

    DPtech DPX29000 Series Installation Manual v1.1.docx Switch Installation Confirmation before installation (1) Make sure you have read and understood Chapter 3 carefully. (2) Make sure that the requirements outlined in Chapter 3 have been met. Copyright © Hangzhou DPtech Technologies Co., Ltd.

  • Page 46: Installation Process

    DPtech DPX29000 Series Installation Manual v1.1.docx Table 3-1 All power must be turned off before the device is installed. Installation process Copyright © Hangzhou DPtech Technologies Co., Ltd.
  • Page 47 DPtech DPX29000 Series Installation Manual v1.1.docx Start Install to a specific site Connecting ground wire Install general module Connecting power cord Connecting interface cable Wiring and binding cable during installation Installation check Turn on power switch Troubleshooting Normal？ Turn off power switch...

  • Page 48: Install The Switch To A Cabinet

    DPtech DPX29000 Series Installation Manual v1.1.docx Install the switch to a cabinet After the pre-installation preparation and confirmation work is completed, start installing the equipment. 3.2.1 Install case dust net (optional) A6 dust screen installation method Insert the dust proof net along the dust proof net slide, and tighten the loose dust proof net with a cross screw knife after inserting it into the head.

  • Page 49: Install Blank Handle Strips

    (3) Align the loose screw on the blank handle bar with a flat-head screw knife and turn it clockwise until it is tightened. The DPX29000 series of false handle bars and blank panels are distinguished as follows: Figure 3-2 DPX29000-A18 mesh slot false handle bar...
  • Page 50 DPtech DPX29000 Series Installation Manual v1.1.docx Figure 3-3 DPX29000-A18 line card slot blank panel Figure 3-4 DPX29000-A10 line card slot blank handle bar Figure 3-5 DPX29000-A10 network board slot blank panel3 Note 1: DPX29000-A18 mesh panel slot, all blank panels were switched to blank handle bars in April 2018.

  • Page 51: Install The Equipment To The Cabinet

    DPtech DPX29000 Series Installation Manual v1.1.docx 3.2.3 Install the equipment to the cabinet Preparation for installation (1) Check the grounding and smoothness of the cabinet, and confirm that the installation position of the switch in the cabinet has been arranged, and the inside of the cabinet and (2) There are no obstacles around the switch installation that affect it.

  • Page 52: Install The Switch To The Bench

    DPtech DPX29000 Series Installation Manual v1.1.docx Before installing the equipment to the cabinet, the hanging lugs need to be fixed to the hanging lug installation holes on the left and right sides of the equipment respectively. It should be noted that the hanging ears of A10 are symmetrical above and below.

  • Page 53: Installation Steps

    The resistance between the equipment and the ground should be less than 5 ohms. ⚫ The protective ground grounding terminal of DPX29000 series is located behind the case, in the lower right corner of the case, and has a ground identification.
  • Page 54 DPtech DPX29000 Series Installation Manual v1.1.docx (3) Ground marking (4) Grounding hole (5) OT terminal (6) Ground cable To connect the protective ground wire: (1) Remove the grounding hole connecting screw of the case. (2) Fit the OT terminal of the ground wire that was randomly included over the case grounding screw.

  • Page 55: Install The Universal Module

    DPtech DPX29000 Series Installation Manual v1.1.docx Install the universal module 3.5.1 Install the power module Please install the corresponding DC power supply module or AC power supply module according to your selected model (DC or AC power supply mode). If there is a blank panel at the location of the power module to be installed, please remove the blank panel first.

  • Page 56: Install The Main Control Board

    DPtech DPX29000 Series Installation Manual v1.1.docx (2) Hand fan tray bottom lift fan tray into the chassis fan tray slot, slowly push inward to the bottom. The fan tray is anti-reflective structure, when installing, please pay attention to the word of the attention label on the fan tray mask upward or the fan LOGO toward the outlet.

  • Page 57: Connect The Interface Cable

    DPtech DPX29000 Series Installation Manual v1.1.docx Connect the interface cable 3.6.1 Connect the configuration port cable The device provides RS232 asynchronous serial configuration port (Console), through this interface you can complete the configuration of the device. The Console port is connected to the terminal computer (PC) serial port through a configuration cable.

  • Page 58: Connect The Power Cord

    DPtech DPX29000 Series Installation Manual v1.1.docx interface of these optical modules is LC type optical fiber connector, requiring the use of optical fiber with LC type optical fiber connector. All optical modules support hot plugging. Connect the power cord 3.7.1...

  • Page 59: Connect The Dc Power Cord

    DPtech DPX29000 Series Installation Manual v1.1.docx 3.7.2 Connect the DC power cord Dc power supply DC power input range: -48V ~ -60V DC. Method of connecting DC power cord (1) Use a Phillips screw knife to loosen the retaining screws on the wiring terminals.

  • Page 60: Power On The Device

    DPtech DPX29000 Series Installation Manual v1.1.docx Power on the device See Chapter 5, Booting Up the Device, and 4.1.2, Powering Up the Device. 3-16 Copyright © Hangzhou DPtech Technologies Co., Ltd.

  • Page 61: Switch Startup

    DPtech DPX29000 Series Installation Manual v1.1.docx Switch Startup Switch startup 4.1.1 Setting up a configuration environment Connect the switch to the terminal computer Connect one end of the configuration port cable (RJ45 end) to the Console port of your device and the other end (DB9 end) to the serial port of your terminal computer as shown in Figure 4-1.
  • Page 62 DPtech DPX29000 Series Installation Manual v1.1.docx Figure 4-2 Hyperterminal connection description screen (2) Type the name of the new connection in the "Connection Description" interface, click the < OK > button, and the system will pop up the interface diagram as shown in Figure 5-3.
  • Page 63 DPtech DPX29000 Series Installation Manual v1.1.docx Set the default properties of the serial port in the Serial port Property Settings dialog in Figure 4- 3, as shown in Table 4-1. Table 4-1 Setting the serial interface properties Properties Value Baud rate...
  • Page 64 DPtech DPX29000 Series Installation Manual v1.1.docx Figure 4-3 Serial port parameter Settings (4) After setting the serial port parameters, click the < OK > button and the system will enter the super terminal window as shown in Figure 4-4. Copyright © Hangzhou DPtech Technologies Co., Ltd.
  • Page 65 DPtech DPX29000 Series Installation Manual v1.1.docx Figure 4-4 The hyperterminal window (5) Configuring the Hyperterminal properties. Select the [File/Properties/Settings] item in the Hyperterminal and go to the Property Settings window shown in Figure 4-6. Select the terminal emulation type as VT100 or Auto-Detect and click the < OK > button to return to the Hyperterminal window.

  • Page 66: Power On The Switch

    DPtech DPX29000 Series Installation Manual v1.1.docx Figure 4-5 Figure 4-6 Terminal type settings 4.1.2 Power on the switch Check before power on The following checks should be performed before the switch is powered on:  The power and ground cables are connected correctly.

  • Page 67: Startup Process

    Check method: After the switch is started, the startup interface can be directly seen on the terminal computer. You will be prompted to type Enter after the startup (i.e., self-test). When the command line prompt "<DPtech>" appears, you can configure it. 4.1.3 Startup process Power on to start the switch, the PC terminal will display the self-test information of the switch.
  • Page 68 DPtech DPX29000 Series Installation Manual v1.1.docx * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * ConBoot, basic Version 1.23.04...

  • Page 69: Web Default Login Method

    The default password here is "DPTECH". Web default login method DPX29000 series switches support Web network management, and the default IP address of the network management port is 192.168.0.1. Administrators can use the Web interface to manage and maintain DPX29000 series switches conveniently and intuitively.
  • Page 70 DPtech DPX29000 Series Installation Manual v1.1.docx Figure 4-6 WEB network management login interface It is not recommended that users use two different login methods (http, https) to login to Web network management on the same PC. After logging in for the first time, it is recommended that users change the default login password.

  • Page 71: Faq

    DPtech DPX29000 Series Installation Manual v1.1.docx Power system problem handling  Fault phenomenon The PWR On the front panel of the main control board does not light up.  Troubleshooting The power LED on the front panel is used to indicate the operation state of the power module.

  • Page 72: Line Card Troubleshooting

    DPtech DPX29000 Series Installation Manual v1.1.docx The main control board main and standby status LED MPU is bright red, indicating that the main control board is not connected to the power supply or single board fault.  Troubleshooting Follow these steps to check: (1) The Main control board is properly inserted into the Main control board slot.

  • Page 73: Exchange Network Board Troubleshooting

    DPtech DPX29000 Series Installation Manual v1.1.docx  If the device is powered on normally, check whether the line card is correctly inserted into the slot.  If the line card has been correctly inserted into the slot, it indicates that the line card is faulty.

  • Page 74: Configure System Troubleshooting

    DPtech DPX29000 Series Installation Manual v1.1.docx (1) If the device is properly powered on. (2) Check whether the air outlet and air inlet of the chassis are blocked by foreign objects. If there is a foreign body, please clean it to ensure that the air duct is unblocked.
  • Page 75 DPtech DPX29000 Series Installation Manual v1.1.docx Terminal display garbled code troubleshooting  Fault phenomenon After the equipment is powered on and started, garbled code is displayed on the terminal computer.  Troubleshooting Please confirm the parameter Settings of the terminal (such as super terminal) : baud rate is 9600, data bit is 8, parity is none, stop bit is 1, flow control is none, and terminal emulation is VT100.
