DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual...
Page 2
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Hangzhou DPtech Technologies Co., Ltd. provides full- range technical support. If you need any help, please contact Hangzhou DPtech Technologies Co., Ltd. and its sale agent, according to where you purchase their products.
Page 3
Hangzhou DPtech Technology Co., Ltd has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech Technology Co., Ltd made every effort in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind express or implied.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Table of Contents CHAPTER 1 PRODUCT INTRODUCTION ................1 1.1 P ......................... 1 RODUCT VERVIEW 1.2 I ........... 1 NTRODUCTION OF PRODUCT MODEL AND SPECIFICATIONS 1.3 T ..................... 2 HE FRONT VIEW INTRODUCTION 1.3.1 LSW5003-4GP-I-R ........................
Page 5
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual 3.3.2 M ................... 4 OUNTING SWITCH IN A INCH RACK 3.4 C ..................... 5 ONNECTING GROUNDING WIRES 3.5 C ....................6 ONNECTING INTERFACE CABLE 3.5.1 H ..................7 ARDWARE POWER FAILURE ALARM 3.5.2 C...
Page 6
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual List of Figures Figure1-1 LSW5003-4GP-I-R front view ....................2 Figure1-2 The front view indicator of LSW5003-4GP-I-R ..............3 Figure1-3 LSW5003-4GP-I-R rear view....................4 Figure1-4 RJ45 pinout diagram ........................ 6 Figure1-5 Ethernet cable diagram ......................6 Figure1-6 LC type connector appearance ....................
Page 7
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual List of Tables Table1-1 LSW5003 series Ethernet switch specification table ..............1 Table1-2 Console port attribute table ......................5 Table1-3 Ethernet electrical interface properties ..................5 Table1-4 SFP Ethernet optical interface attributes ................... 7 Table2-1 Temperature/humidity requirement ..................
Chapter 1 Product Introduction 1.1 Product Overview The DPtech LSW5003 series of industrial Ethernet switch is the product researched and developed by DPtech company, which aims at enterprise network and metropolitan area network and provides convergence and access layer devices for customers with abundant service features and routing capacities.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure1-2 The front view indicator of LSW5003-4GP-I-R Indicator Status Description (1) Slot SLOT2 interface Indicates that slot SLOT3 interface 0 is in communication state indicator 0 green Blinking Indicates slot SLOT3 interface 0 is sending and receiving data...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Indicator Status Description power indicator Indicates that the power 0 is not powered or that the power module is faulty (PWR0) green Indicates that the power 0 is work properly (6) Power indicator light...
1.4 Port introduction 1.4.1 Console port The front panel of LSW5003 series of industrial Ethernet switch has a RS232 asynchronous serial port configuration (CON), which can be used to connect to the computer terminal and can be used to debug, configure, maintain and manage and load software for the system.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Attribute Description Medium maximum Support 100m transmission distance transmission distance Interface standard IEEE 802.3i、802.3u、802.3ab 2.Ethernet interface (RJ45 connector) By using of the 5 categories or above 5 categories twisted pair cable to connect Ethernet, LSW5003 series Ethernet switch interfaces (10/100/1000M) adopt RJ45 connector and support MDI/MDIX auto-negotiation.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure1-6 LC type connector appearance Figure1-7 SC connector appearance Note: Using optical fiber to connect network device, make sure that the type of the optical fibre connector should correspond to the optical module.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure1-10 The service module (LSW-8FEL-E) appearance 1.5.3 Service module(LSW-6FES-E) The service module (LSW-6FES-E) provides 6*Fast Ethernet optical interfaces (SC). Figure1-11 The service module (LSW-6FES-E) appearance 1.5.4 Service module(LSW-8FEP-E) The service module (LSW-8FEP-E) provides 8*Fast Ethernet optical interfaces (SFP).
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure1-12 The service module (LSW-8FEP-E) appearance 1.5.5 Service Module(LSW-6FEST-E) The service module (LSW-6FEST-E) provides 6*Fast Ethernet optical interfaces (ST). Chapter 2Installation...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Chapter 2Preparing for Installation To avoid possible bodily injury and equipment damage, read all safety recommendations carefully before installation. Note that the recommendations do not cover every possible hazardous condition 2.1 General safety recommendations ...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Table2-1 Temperature/humidity requirement Temperature Relative humidity -40℃~70℃ 0%~95% (non-condensation) 2.2.2 Cleanliness Dust is a hazard to the operating safety of your device. The dust accumulated on the chassis can cause electrostatic adsorption, one of the sources that cause the poor contact of connectors or metal contact points.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Keep the equipment room as clean as possible. Maintain adequate temperature and humidity. Wear an ESD-preventive wrist strap and clothes when handling the circuit board. 2.2.4 Anti-interference requirement All interference sources, wherever they are from, impact the switch negatively in the conducted emission patterns of capacitance coupling, inductance coupling, electromagnetic wave radiation, and common impedance (including the grounding system) coupling.
2.4 EMC description CISPR22 compliance DPtech LSW5003 series complies with the requirements of CISPR22 for Class A Information Technology Equipment(ITE). Warning: if this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Chapter 3 Device Installation 3.1 Installation Preparation You have read Chapter 2 “Preparation for Installation” carefully. The requirements in Chapter 2 are satisfied Before install you should power off your device. Chapter 3 Device Installation...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual 3.2 Installation procedure Start Mount the switch on a Install switch to a 19-inch workbench rack Connect ground wire Connect power cable Connect the switch to a configuration terminal Verify the installation...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual 3.3 Mounting the switch to a specific site Adopt the following methods to the install your switch: Install the device on the table Install the device to the 19-inch cabinet 3.3.1 Mounting switch on workbench If a standard 19-inch rack is unavailable, you can place the switch on a clean workbench/tabletop.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure3-2 Mounting device on the workbench 3.3.2 Mounting switch in a 19-inch rack 1.Mounting ear Figure3-3 Mounting ear 2.Mounting the switch in a rack Figure3-4 Mounting the device to a rack (To see the image clearly, we only snapshot the device) 3.Fastening the switch...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure3-5 Fasten the switch 3.4 Connecting grounding wires Caution: When installing or using your switch, properly connect the grounding wire for lightning protection and anti-interference. The grounding resistance must be smaller than 5 ohm.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual To connect the ground cable, you should strip the ground wire insulation rubber about 15mm and hook the wire on a grounding pole clockwise and fasten the ground pole on the switch by hexagonal screw.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual 2.Method for connecting DC power cable Ensure that the protection grounding wire has been correctly connected to the earth, and check the voltage value of each pin (pictured above). The L is connected with a power supply live Wire, N is connected with zero line, grounding earth.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Caution: The serial ports on PCs do not support hot swapping. If the switch device has been powered on, always connect the console cable to the PC before connecting it to the switch, and when you connect PC to the switch, you should connect DB9 terminal configuration cable to PC and then RJ45 terminal.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Chapter 4Starting up the switch and upgrading software 4.1 Starting up the Switch at the Initial Boot 4.1.1 Setting up a Configuration Environment 1.Connecting the switch to the terminal pc Connect the RJ-45 connector of the console cable to the console port on the switch, and connect the DB-9 female connector of the console cable to the serial port on the PC that is used for configuring the switch, as shown in Figure4-1.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure4-2 Setting up a new connection Enter the name of the new connection in the Name field and click <OK>. The dialog box, as shown in Figure 4-3 displays. Select the serial port to be used from the Connect Using drop-down menu. The serial port must be the same port connected by the console cable.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Table4-1 Configure serial port properties Attribute Value Baud rate 9600bps(the default) Data bits Parity check None Stop bits Flow control None Note: To restore the default settings, click Restore Defaults. ...
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure4-5 Hyper Terminal Select File/Properties/Settings. In the Properties dialog box, select the Settings tab, as shown in Figure 4-6. Select VT100 or Auto detect in the Emulation dropdown menu. Click <OK>. Figure4-6 Settings tab 4.1.2 Booting the Switch...
Verify whether terminal PC display normally. Method: start up your device and on the terminal PC you can view the device initialization information. Enter password at the command line and then you can configure <DPtech> command line. 4.1.3 Starting procedure Power up your device, you can view the initialization information on the terminal PC display.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Figure4-7 Web management interface Caution: You should not login to the web management interface by using of http or https protocol on the same PC. After first time you login to the web management interface, modify the default login password.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual Chapter 5 Maintenance and Troubleshooting 5.1 Dealing with power system failures Trouble phenomenon PWR LED on the front panel isn’t on. Troubleshooting You can know whether the power system has failed by reading the PWR LED on the front panel. If the power system is operating normally, the PWR LED is ON.
DPtech LSW5003 Series Industrial Ethernet Switch Installation Manual is None, and Terminal Emulation is VT100. If your configuration is not same with the above parameters, reconfigure the configuration. 2.Garbled characters on the terminal Trouble phenomenon See the garbled characters on the terminal PC if you power-up your switch.
