DPtech LSW5662 Series Layer 3 Switches
Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSW5662 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DPtech LSW5662 Series

Summary of Contents for DPtech LSW5662 Series

  • Page 1 DPtech LSW5662 Series Layer 3 Switches Installation Manual...
  • Page 2 Owing to product upgrading or other reasons, information in this manual is subject to change. Hangzhou DPtech Technologies Co., Ltd. has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech Technologies Co., Ltd. made every effort...

  • Page 3: Table Of Contents

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Contents 1 Product Introduction ..........................1-1 1.1 Product overview ..........................1-1 1.2 Types and specifications of the product .................... 1-1 1.3 List module and the power consumption ................... 1-4 1.4 Front and rear panel introduction ...................... 1-5 1.4.1 LSW5662-48GT4XGS/LSW5662-48GT4XGS-SE product appearance .........
  • Page 4 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 2.4 Electromagnetic compatibility statement ................... 2-5 2.5 Installing Tools ........................... 2-5 3 Switch Installation ..........................3-1 3.1 Confirmation before the installation ....................3-1 3.2 Installation process ..........................3-2 3.3 Install switch to the specified location ....................3-3 3.3.1 Install switch to the workbench ....................

  • Page 5: Product Introduction

    Product Introduction Product overview The DPtech LSW5662 series Layer 3 switch is the DPtech company independent research and development of the main positioning for enterprise network and metropolitan area network convergence or access equipment. It can provide customers with a wealth of business features and routing functions, but also can be used for the connection of data center server clusters.
  • Page 6 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Weight 4.15 kg 4.15 kg 4.15 kg Management A RJ45 the Console port, a USB Console port, a RJ45 port management, is port located in the front panel Front panel 4* 10G base - R...
  • Page 7 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Item LSW5662-48GP4XGS LSW5662- 28GT4GP4XGS-G LSW5662-48GP4XGS-SE Overall 440mm*400mm*44mm 440mm*400mm*4 dimensions (W * D * H) Weight 4.15 kg 4.90 kg Management 1* RJ45 the Console port, a 1* RJ45 the of port USB Console port, a RJ45...

  • Page 8: List Module And The Power Consumption

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Working 10% ~ 95% environment relative humidity (non- condensing) List module and the power consumption Switches support module are as follows, power consumption is different in different modules, and the same module also vary in different stages of power consumption, specific module models of power consumption, please see the table below.

  • Page 9: Front And Rear Panel Introduction

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Front and rear panel introduction 1.4.1 LSW5662-48GT4XGS/LSW5662-48GT4XGS-SE product appearance 1.4.1.1 Front view Figure 1-1 LSW5662-48GT4XGS/LSW5662-48GT4XGS-SE front view (1) 10/100/1000M Ethernet electrical (2) Ethernet management port (MGMT) interface 0 (3) CONSOLE port (CON)
  • Page 10 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Indicates that the system without any warning (7) Stack Status LED Steady on Indicates that the system is in stacked state (VSM) (green) Indicates that the system in a state of the stack...

  • Page 11: Lsw5662-28 Gt4Xgs/Lsw5662-28Gt4Xgs-Se Product Appearance

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 1.4.1.2 Rear view Figure 1-3 Rear view of LSW5662-48GT4XGS/ LSW5662-48GT4xGS-SE(AC power) (1) Ground marking (2) SLOT (3) AC power socket 0 (4) AC power outlet 1 (5) Grounding terminal 1.4.2 LSW5662-28 GT4XGS/LSW5662-28GT4XGS-SE product appearance 1.4.2.1...
  • Page 12 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (13) SLOT LED (SLOT) (14) Virtual exchange matrix LED (VSM) (15) Ethernet management port LED (16) 10G Ethernet interface optical LED 28 (MGMT) (17) 10/100/1000M Ethernet electrical interface LED 0 Figure 1-5 LSW5662-28GT4XGS/LSW5662-28GT4XGS-SE LEDs on the front panel...
  • Page 13 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (14) Stack status LED Steady on Indicates that the system in the stack state (VSM) (green) Indicates that the system is not in stack state (13) SLOT LED Indicates that no identifiable module is inserted in...

  • Page 14: Lsw5662-24Gp4Xgs/Lsw5662-24Gp4Xgs-Se Product Appearance

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (3) AC power socket 0 (4) AC power outlet 1 (5) Grounding terminal 1.4.3 LSW5662-24GP4XGS/LSW5662-24GP4XGS-SE product appearance 1.4.3.1 Front view Figure 1-7 Front view of LSW5662-24GP4XGS/LSW5662-24GP4XGS-SE (1) 100/1000M optical Ethernet interface (2)10/100/1000M Ethernet electrical...
  • Page 15 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (9) ( 10) (11) (12) (17) (16) (15) (14) (13) Figure 1-8 LSW5662-24GP4XGS/LSW5662-24GP4XGS-SE front panel LED Status Description (3) 10/100/1000M Steady on Indicates that the GE electrical port 17 is in the...
  • Page 16 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (15) Ethernet Blinking Indicates that the management port MGMT is management port LED sending and receiving data (green) Indicates that the MGMT port is in connection state (16) 10G Ethernet Steady on...

  • Page 17: Lsw5662-48 Gp4Xgs/Lsw5662-48Gp4Xgs-Se Product Appearance

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 1.4.4 LSW5662-48 GP4XGS/LSW5662-48GP4XGS-SE product appearance 1.4.4.1 Front view Figure 1-10 LSW5662-48 GP4XGS/LSW5662-48 GP4XGS - SE front view (1) 1000M Ethernet interface LED 0 (2) Ethernet management port (MGMT) (3) CONSOLE port (CON)
  • Page 18 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (7) Stack status LEDs Steady on Indicates that the system is in a stacked state (VSM) (green) Indicates that the system in a state of the stack (8) SLOT LED (SLOT) Indicates that the there was no insert can identify...

  • Page 19: Lsw5662-28Gt4Gp4Xgs-G Product Appearance

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 1.4.4.2 Rear view Figure 1-12 Rear view of LSW5662-48GP4XGS/LSW5662-48GP4XGS-SE (AC power) (1) Ground marking (2) SLOT (3) AC power socket 0 (4) AC power outlet 1 (5) Grounding terminal 1.4.5 LSW5662-28GT4GP4XGS-G product appearance 1.4.5.1...
  • Page 20 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (15) Ethernet management port LED (16) 10G Ethernet optical interface LED 32 (MGMT) (17) 10/100/1000M Ethernet electrical interface LED 0 Figure 1-14 LSW5662-28 GT4GP4XGS-G front panel LEDs Status Description (3) 1000M Ethernet...
  • Page 21 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Steady on Indicates that the module inserted into slot 1 is working properly (14) stack status LEDs Steady on Indicates that the system in the stack state (VSM) (green) Indicates that the system in a state of the stack...

  • Page 22: Port Introduction

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Port Introduction 1.5.1 Console port The LSW 5600 series Layer 3 switches have a RS232 asynchronous serial configuration port (CON), which can be used to connect the terminal computer to debug, configure, maintain, manage the system and load the host software program.
  • Page 23 1.5.2.2 Ethernet electrical interface (RJ45 connector) The 10/100/1000M Ethernet electrical interface of LSW5662 series generally uses twisted-pair cables of category 5 or more to connect Ethernet. The electrical Ethernet interface uses RJ45 connector, and the port supports MDI/MDIX adaptation. In use, the use of class 5 twisted pair and RJ45 connector to make network cable.

  • Page 24: Combo Port

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx  Standard cable: also called direct cable, RJ45 connector on both ends of twisted pair line pressure to sequence is exactly the same, for terminal equipment (such as PC, router, etc.) to the HUB or connected to the LAN Switch. Equipment supplied cable as the standard line.

  • Page 25: Card Module

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Card module 1.6.1 Interface board (LSW-1XGES) Introduction LSW-1XGES is a 1-port 10 Gigabit Ethernet optical interface card. (1) 10 GE Ethernet optical interface (0) (2) 10 GE optical interface data sending and...
  • Page 26 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 1-19 DPtech LSW-1XGES running status LED Status Description (3) 10 GE XFP optical Steady Indicates that the port 0 is connected interface LINK status LEDs (LINK 0) Indicates that the port 0 isn’t connected...

  • Page 27: Interface Board (Lsw-2Xges)

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Fiber type 62.5/125μm multi- 9/125 mu m single 9/125μm single-mode mode fiber mode fiber fiber Maximum 300m 10km 40km transmission distance Way of working 10000 MBPS full-duplex mode 1.6.2 Interface board (LSW-2XGES) Introduction LSW - 2XGES is a 2-ports 10Gigabit Ethernet interface card.
  • Page 28 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 1-21 DPtech LSW-2XGES running status LED Status Description (3) 10 GE SFP + optical Steady on Indicates that the port 0 is connected interface LINK status LEDs (LINK 0) Indicates that the port 0 isn’t connected...

  • Page 29: Interface Board (Lsw-2Gep)

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 1.6.3 Interface board (LSW-2GEP) 1. Introduction LSW-2GEP is a 2-ports Gigabit Ethernet optical interface card. (1)1000M Ethernet optical interface (0) (2) 1000M optical interface data sending and receiving status LED (ACT 0)
  • Page 30 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 3. LED Figure 1-23 DPtech LSW-2GEP running status LED Status Description (3) 1000M SFP optical Steady Indicates that the port 0 is connected Interface LINK status LED (LINK 0) Indicates that the port 0 isn’t established...

  • Page 31: Interface Board (Lsw-2Xcx4)

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Short Long- Long- Long- Long-distance distance distance distance distance Type (1550nm) (850nm) (1310nm) (1310nm) (1550nm) Transmit optical optical optical optical optical optical interface power interface interface interface interface module module module module...
  • Page 32 Interface board specification list: Item Specification Optical interface 2* 1000M Ethernet optical interfaces (SFP) Figure 1-25 DPtech LSW - 2 XCX4 running status LED Status Description (3) 1000M SFP optical Steady Indicates that the port 0 is connected interface LINK status LED (LINK 0) Indicates that the port 0 isn’t connected...

  • Page 33: Interface Board (Lsw-4Xgs)

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Gigabit Ethernet interface The LSW-2XCX4 interface board (LSW-2XCX4) has two SFP 10000M Ethernet optical ports. The SFP port LED is located on the right side of the SFP connector and indicates the current...
  • Page 34 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (1) 10 GE Ethernet optical interface (0) (2) 10 GE Ethernet interface LED (0) (7) Loose screw Figure 1-26 LSW-4XGS front view Specifications Interface board specification list: Item Specification Optical interface 4* 10 GE Ethernet optical interfaces (SFP) Copyright ©...

  • Page 35: Product Components

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 1-27 LSW - 4 XGS running status LED Status Description (3) 10 GB Ethernet Steady on Indicates that the 10 GE optical interface 0 is optical interface LED 0 connected (green)

  • Page 36: All Kinds Of Interface

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Flash Flash is used to store the boot program file Conboot software. Memory Memory is used to store the data that the system communicates with the CPU while it is running. Battery Is used to maintain the Settings in the CMOS chip data is not lost, maintain the normal operation of the main time.
  • Page 37 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (1) 1000M Ethernet optical (2) 1000M Ethernet optical (3) 1000M Ethernet optical interface (0) interface (2) interface (4) (4) 1000M Ethernet optical (5) 1000M Ethernet optical (6) 1000M Ethernet optical interface (6)

  • Page 38: Installation Preparation

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Installation Preparation To avoid injury to people and equipment, read this chapter carefully before installing the equipment and understand what needs to be noted during installation, use, and maintenance. In practice including but not limited to the following considerations.

  • Page 39: Temperature/Humidity Requirements

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 2.2.1 Temperature/humidity requirements To guarantee the normal work of the equipment and service life, installation site need to maintain a certain temperature and humidity.  If the humidity is too high for a long time, easy cause insulation insulation fault leakage, even sometimes it is easy to change material mechanical performance, metal parts such as corrosion phenomenon;...

  • Page 40: Anti-Static Requirements

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx In addition to dust, the equipment also has strict requirements for acids, bases and sulfides contained in the air. These harmful gas will accelerate the corrosion of the metal and some parts of the aging process.

  • Page 41: Lighting Protection Requirements

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx  AC power supply system is a TN system, and AC power socket should use a single-phase three-wire power socket with protected ground wire (PE), so that the filter circuit on the equipment can effectively filter out grid interference.

  • Page 42: Laser Use Safety

    Electromagnetic compatibility statement CISPR22 compliance DPtech LSW5662 series complies with the requirements of CISPR22 for Class A Information Technology Equipment (ITE). Warning: if this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions.

  • Page 43: Installing Tools

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx This is A a-class products, in the living environment, the product may cause radio interference. In this case, and may require the user to take practical measures to the interference. Installing Tools ...

  • Page 44: Switch Installation

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Switch Installation Confirmation before the installation  Please confirm that you have carefully read and understand the content of chapter 2.  Please ensure that the requirements described in chapter 2 have been met.

  • Page 45: Installation Process

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Installation process Figure 3-1 Switch installation process Copyright © Hangzhou DPtech Technologies Co., Ltd.

  • Page 46: Install Switch To The Specified Location

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Install switch to the specified location  You can install the device in one of 2 ways:  Install equipment to the workbench  Install equipment to 19 inch rack 3.3.1 Install switch to the workbench If you are not using a standard 19 "cabinet, you can place the device on a clean work table.

  • Page 47: Install The Switch Into A 19-Inch Cabinet

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 3-2 Install the device on the workbench 3.3.2 Install the switch into a 19-inch cabinet 3.3.2.1 Install the mounting ears Figure 3-3 Install the mounting ears 3.3.2.2 Install the switch to a cabinet Figure 3-4 Install equipment to cabinet (cabinet omitted for clarity) 3.3.2.3...

  • Page 48: Connect Ground Wire

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 3-5 Fix the switch Connect ground wire In order to ensure the personal safety and equipment safety (Lighting protection, anti ⚫ interference), and must provide reliable grounding device. Between the equipment and the earth resistance to less than 5 ohms.
  • Page 49 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (5) Grounding screw hole connection Figure 3-6 Diagram of connecting grounding wire Ground connection protection method:  To remove the chassis grounding screw hole connection.  Will be included in the Grounding wire OT terminal on the chassis grounding screw.

  • Page 50: Connect The Interface Cable

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 3-7 Connection protection ground wire to the ground line Connect the interface cable 3.5.1 Connect with Console port cable The device provides RS232 asynchronous serial configuration port (Console), through this interface you can complete the configuration of the device. The Console port through configuration cable connected to the computer (PC) terminal serial ports.

  • Page 51: Connect With Service Ports

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Twisted-pair cable does not prepared along with the swtich in the packing box . When you use it, please prepare it by yourself. If the network management port directly connected to the terminal computer network card, you must use a crossover twisted-pair cable.

  • Page 52: Check After Installation

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx (1) Positive (+) of the power supply (2) Power NC (3) Power cathode (-) The device provides DC 12V power input. The meaning of each pin is as shown in the figure above.

  • Page 53: Device Startup

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Start Device and Upgrade Software Device startup 4.1.1 Setting up a configuration environment 4.1.1.1 Connect the device to the terminal computer Connect one end of the configuration port cable (RJ45 end) to the Console port of your device and the other end (DB9 end) to the serial port of your terminal computer as shown in Figure 4- 1.Figure 4-1...
  • Page 54 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 4-2 Hyperterminal Connection Description screen Type the name of the new connection in the "Connection Description" interface, click the < OK > button, the system will pop up the interface diagram as shown in Figure 4-3, and select the serial port used for the connection in the "Use when Connecting"...
  • Page 55 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 4, as shown in Table 1-3.Figure 4-4 Table 4-1 Table 4-1 Set the serial interface properties Property Set value Baud rate 9600bps(default) Data bits Parity bits None Stop bit Data Flow control None Default properties can be restored by clicking the <...
  • Page 56 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 4-4 Serial port parameter Settings After the serial port parameters are set, click the < OK > button and the system will enter the super terminal window as shown in Figure 4-5.Figure 4-5...
  • Page 57 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 4-5 Hyperterminal window In configuring the Hyperterminal properties. Select the [File/Properties/Settings] item in the Hyperterminal and go to the Property Settings window shown in Figure 4-6. Figure 4-6 Select the terminal emulation type as VT100 or Auto-Detect and click the < OK > button to return to the Hyperterminal window.

  • Page 58: Power On The Device

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Figure 4-6 Terminal type settings 4.1.2 Power on the device 4.1.2.1 Check before power on The following checks should be performed before the device is powered on:  The power and ground cables are connected correctly.

  • Page 59: Boot Process

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx 4.1.2.2 Power on the device Turn on the device power switch. 4.1.2.3 Check after power on Once the device is powered on, check as follows:  Whether the ventilation system is working properly.
  • Page 60 DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx System start booting... The system is going down NOW! Sent SIGTERM to all processes Sent SIGKILL to all processes Requesting system reboot Reboot by cpld * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * *...

  • Page 61: Web Default Login Method

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Slot 0 board_type 0x1f insert finish Remounting root filesystem in read-write mode: Checking filesystems Initializing File System: Initializing Remote Board: Initializing Sqlite Database: Initializing Database Update: Initializing Route Mode: Initializing System Control:...
  • Page 62 Not recommended for users on the same PC using two different login (HTTP, HTTPS) login Web net tube, respectively. The latest branch system default login user name admin, password DPtech @ 300768, user after logging in for the first time, will prompt the user to modify the default password.

  • Page 63: Faq

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Power system problems troubleshooting  Fault phenomenon The PWR light on the front panel does not light up.  Failure handling The power indicator on the front panel is used to indicate the operating status of the power module, and the light is not lit to indicate that there may be a problem with the power supply.

  • Page 64: Swith Failure Treatment

    DPtech LSW5662 Series Layer 3 Switches Installation Manualv1.3.docx Please do not plug or unplug the power cord live. Such as after completion of the inspection work, the power LED is not LED, please contact the agent. Switch failure treatment Devices, if the system is normal, will be displayed on the terminal computer startup information;...
