- Page 1 DPtech LSW5602 Ethernet Switch Installation Manual DPtech LSW5602 Ethernet Switch Installation Manual...
- Page 2 DPtech LSW5602 Ethernet Switch Installation Manual Hangzhou DPtech Technologies Co., Ltd. provides full- range technical support. If you need any help, please contact Hangzhou DPtech Technologies Co., Ltd. and its sale agent, according to where you purchase their products. Hangzhou DPtech Technologies Co., Ltd.
- Page 3 Owing to product upgrading or other reasons, information in this manual is subject to change. Hangzhou DPtech Technology Co., Ltd has the right to modify the content in this manual, as it is a user guides, Hangzhou DPtech Technology Co., Ltd made every effort in the preparation of this document to ensure accuracy of the contents, but all statements, information, and recommendations in this document do not constitute the warranty of any kind express or implied.
-
Page 4: Table Of Contents
DPtech LSW5602 Ethernet Switch Installation Manual Table of Contents CHAPTER 1 PRODUCT INTRODUCTION ..................1-2 1.1 P ........................1-2 RODUCT VERVIEW 1.2 P ..................... 1-2 RODUCT ODEL AND PECIFICATION 1.3 F ................1-5 RONT ANEL AND ANEL OF THE WITCH 1.3.1 P... - Page 5 DPtech LSW5602 Ethernet Switch Installation Manual CHAPTER 3 DEVICE INSTALLATION ..................... 3-1 3.1 I ......................3-1 NSTALLATION REPARATION 3.2 I ......................3-2 NSTALLATION ROCEDURE 3.3 M ................... 3-4 OUNTING THE WITCH TO A PECIFIC 3.3.1 M ....................3-4 OUNTING WITCH ON ORKBENCH 3.3.2 M...
- Page 6 Figure1-20 Optical module diagram .......................... 1-24 Figure1-21 Front View of the DPtech LSW-1XGES ....................1-25 Figure1-22 Front view of the DPtech LSW-2XGES switch ..................1-27 Figure1-23 DPtech LSW-2XGES operation status indicator ................... 1-28 Figure1-24 Front view of the DPtech LSW-2GEP switch ..................1-29 Figure1-25 DPtech LSW-2GEP operation status indicator light ................
- Page 7 DPtech LSW5602 Ethernet Switch Installation Manual Figure4-7 Web management interface ......................... 4-8...
- Page 8 DPtech LSW5602 Ethernet Switch Installation Manual List of Tables Table1-1 Console port properties 1-19 Table1-2 Gigabit Ethernet electrical interface properties 1-20 Table1-3 Attributes of the GbE optical interface 1-21 Table1-4 Relationship between two ports 1-24 Table1-5 10GE Ethernet optical interface attributes...
-
Page 9: Chapter 1 Product Introduction
Chapter 1 Product Introduction 1.1 Product Overview DPtech LSW5600 series switches are DPtech self-owned products aiming at enterprise network and metropolitan area network of convergence layer or access layer’s devices, providing users with rich service and routing features. Meanwhile, they also can be used to connect to data center’s server farm. - Page 10 DPtech LSW5602 Ethernet Switch Installation Manual Item LSW5602-44GT4GC LSW5602-16GT8GC LSW5602-16GP8GC corresponding form Combo port. Note: only one port can be used when two Combo ports form at the same time. supporting interface module There are two interface module at rear panel, you can select: supported Dual ports GE SFP interface module expansion card: LSW-2GEP.
- Page 11 DPtech LSW5602 Ethernet Switch Installation Manual Item LSW5602-44GT4GC-PWR LSW5602-16GT8GC-PWR Dimension（W×D×H） 440mm*383mm*44mm 440mm*383mm*44mm Weight 7.5kg 7.1kg Management port 1 console port, on front panel GE port on front panel 44 10/100/1000Base-T Ethernet 24 10/100/1000Base-T Ethernet electrical electrical interface (RJ45) interface (RJ45)
-
Page 12: Front Panel And Rear Panel Of The Switch
DPtech LSW5602 Ethernet Switch Installation Manual Item LSW5602-44GT4GC-PWR LSW5602-16GT8GC-PWR Power input interface type and 1 AC input interface number 1 RPS input interface Maximum power 370W Heat dissipation Adopts 2 fans to dissipate heat for Adopts 2 fans to dissipate heat for the... -
Page 13: Figure1-1 Lsw5602-44Gt4Gc Front Panel
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-1 LSW5602-44GT4GC front panel (1) (3) (5) (7) (11) (10) Status Description (1)10/100/1000M ethernet Means electrical interface 0 is in connection status. electrical interface Blinking Means electrical interface 0 is sending and receiving data packet. - Page 14 DPtech LSW5602 Ethernet Switch Installation Manual Status Description (8)Redundancy power supply Means power supply is absent. LED (RPS) Means the inserted module in slot 1 is failure. Slow Means the module in slot 1 is running, which is in normal working Flashing status.
-
Page 15: Product Appearance Of The Lsw5602-44Gt4Gc-Pwr Switch
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-2 LSW5602-44GT4GC front panel LED 1.3.1.2 Rear view （3） （4） （6） （5） (1)AC power socket (2) Redundancy power teminal (3) Slot (SLOT 0) (4) Slot (SLOT 1) (5) Bar code area of the device... -
Page 16: Figure1-4 Lsw5602-44Gt4Gc-Pwr Front View
DPtech LSW5602 Ethernet Switch Installation Manual (11) 1000M ethernet optical interfce LED (44) (12) 1000M ethernet optical interface (44) (13) 10/100/1000M ethernet electrical interface (1) Figure1-4 LSW5602-44GT4GC-PWR front view (1) (3) (5) (7) (11) (10) Status Description (1)10/100/1000M Ethernet Means electrical interface 0 is in connection status. - Page 17 DPtech LSW5602 Ethernet Switch Installation Manual Status Description Means the power supply is working normally. (7)Virtual switch matrix LED Flashing Means the power supply is fault. (VSM) (8Hz) (8)Redundancy power supply Means power supply is absent. LED (RPS) Means the inserted module in slot 1 is failure.
-
Page 18: Product Appearance Of The Lsw5602-16Gt8Gc Switch
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-5 LSW5602-44GT4GC-PWR front panel LED 1.3.2.2 Rear panel (7)(6) (1) Redundancy power terminal (2) AC power socket (3) ESD label (4) Slot (SLOT 0) (5) Slot (SLOT 1) (6) Grounding terminal (7) Grounding indentification... -
Page 19: Figure1-7 Lsw5602-16Gt8Gc Front View
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-7 LSW5602-16GT8GC front view (1) ( 2) (3) (12) (11) (10) (13) Status Description (1)10/100/1000M Ethernet Means electrical interface 0 is in connection status. electrical interface Flashing Means electrical interface 0 is transmitting data LED(0)(Green) Means electrical interface 0 is in disconnection status. -
Page 20: Figure1-8 Lsw5602-16Gt8Gc Front Panel Led
DPtech LSW5602 Ethernet Switch Installation Manual Status Description (10) Slot LED(SLOT 1) Means the module inserted in slot 1 has failed. Slow Means the module inserted in slot 1 is working as your flashing(1Hz) configuration, which is in normal status. -
Page 21: Product Appearance Of The Lsw5602-16Gt8Gc-Pwr Switch
DPtech LSW5602 Ethernet Switch Installation Manual (3) Slot(SLOT 0) (4) Slot(SLOT 1) (5) Bar code area for the device (6) Grounding identification (7) Grouding terminal Figure1-9 LSW5602-16GT8GC rear view 1.3.4 Product appearance of the LSW5602-16GT8GC-PWR switch 1.3.4.1 Front view (1) ( 2) (3) - Page 22 DPtech LSW5602 Ethernet Switch Installation Manual Status Description LED(0)(Green) Means electrical interface 0 is in disconnection status. (3)10/100/1000M Ethernet Means electrical interface 1 is in connection status. electrical interface Flashing Means electrical interface 1 is transmitting data (1)( Green) Means electrical interface 1 is in disconnection status.
-
Page 23: Figure1-11 Lsw5602-16Gt8Gc-Pwr Front Panel Led
DPtech LSW5602 Ethernet Switch Installation Manual Status Description LED(RUN)(Green) flashing(1Hz) normal status. Fast Means system is loading software or the board is starting. flashing(8Hz) Means no power has inputted or the board isn’t working. (12)1000M Ethernet optical Means GE optical port 17 is in connection status. -
Page 24: Product Appearance Of The Lsw5602-16Gp8Gc Switch
DPtech LSW5602 Ethernet Switch Installation Manual 1.3.5 Product appearance of the LSW5602-16GP8GC switch 1.3.5.1 Front view (2) (4) (6) (7) (8) (11) (10) (9) (13)(12) (1) 1000M Ethernet optical interface(0) (2) 10/100/1000M Ethernet electrical interface LED(16) (3) 10/100/1000M Ethernet electrical interface (16) - Page 25 DPtech LSW5602 Ethernet Switch Installation Manual Status Description Fast Means the power supply 0 has failed. flashing(8Hz) Means the power supply 0 is absent. (7)Slot LED (SLOT 0) Means the module inserted in slot 0 has failed. Slow Means the module in slot 0 is working as your configuration, which flashing(1Hz) is in normal status.
-
Page 26: Port Introduction
1.4 Port Introduction 1.4.1 Console port On the front panel of LSW5602 series Ethernet switch, an RS232 port (CON) can be used to connect terminal PC to debug, configure, maintain, and manage system and to load software program on the host. -
Page 27: 10/100/1000Base-T Ethernet Electrical Interface
DPtech LSW5602 Ethernet Switch Installation Manual Properties Description Interface standard RS232 Baud rate 9600 bps (default) to 115200 bps ≤15m Transmission distance Services Connection to an ASCII terminal Connection to the serial interface of a local PC to run the terminal... -
Page 28: Sfp Interface
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-16 RJ45 pinout diagram 1.4.2.3 Ethernet cable Ethernet electric interface adopt 5 categories twisted pair cable to connect Ethernet, as shown in Figure1-17. Figure1-17 Ethernet cable diagram For different usage, Ethernet twisted pair cables can be divided into straight-through and crossover cables: Standard cable: is also called straight-through cable. - Page 29 DPtech LSW5602 Ethernet Switch Installation Manual Attribute Description Multi-mode Multi-mode Single mode Single mode Single mode short-haul short-haul short-haul Transmitter short-haul Type short-haul (1310 nm) (1310 nm) optical (850 nm) (1310 nm) (850 nm) power -9.5dBm -9dBm -2dBm -4dBm -4dBm...
-
Page 30: Figure1-18 Lc Connector Diagram
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-18 LC connector diagram Figure1-19 SC connector diagram Note: Before connecting an optical fiber, make sure that the connector and cable type match the hot swappable interface module. Before connecting a fiber, make sure that the optical power at the receivingend does not exceed the upper threshold of the optical receive power of the transceiver module. -
Page 31: Combo Port
DPtech LSW5602 Ethernet Switch Installation Manual Figure1-20 Optical module diagram 1.4.4 Combo Port A Combo port consist of one SFP port and the10/100/1000Base-T self-adaption Ethernet port. Only one port can be used when Combo port form at the same time. The relationship between two ports are:... -
Page 32: Insert Card Module
(2) 10GE optical interface data transceiving status indicator (ACT) 0 (3)10GE optical interface link status (4) Spring screw indicator light (LINK) 0 (5) Spring screw Figure1-21 Front View of the DPtech LSW-1XGES 1.5.1.2 Specification Table1-5 Interface board specification list Item Description... - Page 33 DPtech LSW5602 Ethernet Switch Installation Manual Table1-6 DPtech LSW-1XGES operation LED Indicator light Status Description (3) 10GE XFP optical interface Means port 0 has established connection link status indicator light (LINK) 0 Means port 0 is not established connection (2) 10GE XFP optical interface...
-
Page 34: Interface Board（Lsw-2Xges
0 (5) 10GE optical interface transceiving data indicator (6) 10GE optical interface link status indicator light (LINK) 1 light (ACT) 1 (7) Spring screw Figure1-22 Front view of the DPtech LSW-2XGES switch 1.5.2.2 Specification Interface board specification list Item Specification... -
Page 35: Figure1-23 Dptech Lsw-2Xges Operation Status Indicator
DPtech LSW5602 Ethernet Switch Installation Manual 1.5.2.3 Indicator Light Figure1-23 DPtech LSW-2XGES operation status indicator Status Description (3)10GE SFP+ optical interface Means port 0 has created connection. link status indicator light （ LINK） Means port 0 hasn’t created connection. (2) 10GE SFP+optical interface... -
Page 36: Interface Board（Lsw-2Gep
(LINK) 0 (5) 1000M optical interface data transceiving status (6) 1000M opticla interface link status indicator light(LINK) 1 indicaotr light (ACT) 1. (7) Spring screw Figure1-24 Front view of the DPtech LSW-2GEP switch 1.5.3.2 Specification Interface board specification list Item Specification... -
Page 37: Figure1-25 Dptech Lsw-2Gep Operation Status Indicator Light
DPtech LSW5602 Ethernet Switch Installation Manual 1.5.3.3 Indicator light Figure1-25 DPtech LSW-2GEP operation status indicator light Status Description (3)1000M SFP optical interface Means port 0 has created connection. link status indicator light (LINK)0 Means port 0 hasn’t created connection. (2) 1000M SFP optical interface Blinking Means port 0 is transceiving data. -
Page 38: Interface Board（Lsw- 2Xcx4
DPtech LSW5602 Ethernet Switch Installation Manual Attributes Description optical -9.5dBm -9dBm -2dBm -4dBm -4dBm power 0dBm -3dBm 5dBm 1dBm 2dBm Receiver sensitivity -17dBm -20dBm -23dBm -21dBm -22dBm Central wavelength 850nm 1310nm 1310nm 1550nm 1550nm 62.5/125 μm 9/125μm 9/125μm single 9/125μm single 9/125μm... -
Page 39: Figure1-26 Front View Of The Lsw- 2Xcx4 Switch
1.5.4.2 Specification Interface board specification list Item Specification Optical interface (SFP) 2x1 1000M Ethernet optical interface 1.5.4.3 Indicator light Table1-9 DPtech LSW- 2XCX4 operation status indicator light Status Description (3)1000M SFP optical interface Means port 0 has created connection. link status... -
Page 40: Product Assembly
DPtech LSW5602 Ethernet Switch Installation Manual Attributes Description Connector type SFP/LC Interface standard 802.3 802.3u and 802.3ab Multi- mode Single mode Single mode Single mode Single mode short-haul medium-haul long-haul long-haul ultra-long haul (1550 nm) Transmitter Type (850 nm) (1310 nm) -
Page 41: Interfaces
DPtech LSW5602 Ethernet Switch Installation Manual 1.6.2 Interfaces 1.6.2.1 Console port LSW provides a RS232 asynchronous serial configuration port（Console）which can be used to connect terminal computer to debug, configure, maintain and manage and load host software program for the system. -
Page 42: Figure1-27 Ethernet Interface
DPtech LSW5602 Ethernet Switch Installation Manual (31) 10/100/1000M Ethernet Electrical (32) 10/100/1000M Ethernet Electrical (33) 10/100/1000M Ethernet Electrical Interface 13 Interface 15 Interface 17 (34) 10/100/1000M Ethernet Electrical (35) 10/100/1000M Ethernet Electrical (36) 10/100/1000M Ethernet Electrical Interface 19 Interface 21... -
Page 43: Chapter 2 Installation Preparation
DPtech LSW5602 Ethernet Switch Installation Manual Chapter 2 Installation Preparation To avoid possible bodily injury and equipment damage, read all safety recommendations carefully before installation. Note that the recommendations do not cover every possible hazardous condition 2.1 General Safety Recommendations ... -
Page 44: Cleanliness
DPtech LSW5602 Ethernet Switch Installation Manual Table2-1 describes the requirement for the equipment room temperature and humidity. Table2-1 Temperature/humidity requirement Temperature Relative Humidity 5℃～40℃ 20%～80%（non- condensation） 2.2.2 Cleanliness Dust is a hazard to the operating safety of your device. The dust accumulated on the chassis can cause electrostatic adsorption, one of the sources that cause the poor contact of connectors or metal contact points. -
Page 45: Esd Requirement
DPtech LSW5602 Ethernet Switch Installation Manual 2.2.3 ESD Requirement Although the switch is designed to be electrostatic discharge (ESD) preventive, the card circuits and even the device can be badly damaged when excessive static electricity is present. To get much better ESD effect, you should: ... -
Page 46: Grounding Requirement
DPtech LSW5602 Ethernet Switch Installation Manual 2.2.6 Grounding Requirement Using a good grounding system to protect your switch against lightning shocks, interferences, and ESD is essential to the operating reliability of your switch. 2.2.7 Wiring Cable Requirement Cables connect the device should be indoors, not wiring outdoors. When you wiring indoors, you should... -
Page 47: Chapter 3 Device Installation
DPtech LSW5602 Ethernet Switch Installation Manual Chapter 3 Device Installation 3.1 Installation Preparation You have read Chapter 2 “Preparation for Installation” carefully. The requirements in Chapter 2 are satisfied Before install you should power off your device. Chapter 3 Device Installation... -
Page 48: Installation Procedure
DPtech LSW5602 Ethernet Switch Installation Manual 3.2 Installation Procedure Chapter 3 Device Installation... - Page 49 DPtech LSW5602 Ethernet Switch Installation Manual Start Mount the switch on a Install switch to a 19-inch workbench rack Connect ground wire Connect power cable Connect the switch to a configuration terminal Verify the installation Power-on your switch Toubleshooting Power-off the switch Normal？...
-
Page 50: Mounting The Switch To A Specific Site
DPtech LSW5602 Ethernet Switch Installation Manual Figure3-1 Switch installation procedure 3.3 Mounting the Switch to a Specific Site Adopt the following method to the install your switch: Install your switch to the working bench Install your switch to the 19 inch equipment cabinet 3.3.1 Mounting Switch on Workbench... -
Page 51: Mounting Switch In A 19-Inch Rack
DPtech LSW5602 Ethernet Switch Installation Manual Figure3-2 Mounting device on the workbench 3.3.2 Mounting Switch in a 19-inch Rack 3.3.2.1 Mounting Ear Figure3-3 Mounting ear 3.3.2.2 Mounting the Switch in a Rack Figure3-4 Mounting the device to a rack (To see the image clearly, we only snapshot the device) 3.3.2.3 Fastening the Switch... -
Page 52: Connecting Grounding Wires
DPtech LSW5602 Ethernet Switch Installation Manual Figure3-5 Fasten the switch 3.4 Connecting Grounding Wires Caution： When installing or using your switch, properly connect the grounding wire for lightning protection and anti-interference. The grounding resistance must be smaller than 5 ohm. -
Page 53: Connecting Interface Cable
DPtech LSW5602 Ethernet Switch Installation Manual the grounding screw hole with a screwdriver. Connect the other end of the cable to the ground. To connect the ground cable, you should strip the ground wire insulation rubber about 15mm and hook the wire on a grounding pole clockwise and fasten the ground pole on the switch by hexagonal screw. -
Page 54: Connecting Ethernet Management Port
DPtech LSW5602 Ethernet Switch Installation Manual switch, you should connect DB9 terminal configuration cable to PC and then RJ45 terminal. And when you disconnect the cable, first disconnect the RJ45 terminal and then the DB9 terminal. 3.5.2 Connecting Ethernet Management Port The switch provides self-adaption network management port adopts 5-categories or above 5-categories twisted pair cable. -
Page 55: Connecting Redundancy Power Cable
DPtech LSW5602 Ethernet Switch Installation Manual Figure3-8 Diagram for the power cord connection（take LSW5602-44GTGGC as example） 3.6.2 Connecting Redundancy Power Cable （1） （2） （3） (1) Power positive (+) (2) Power NC (3) Power negative (-) The input power of the switch is direct current 12V. Lead foot of the device as shown in the above image. -
Page 56: Chapter 4 Starting Up The Switch And Upgrading Software
DPtech LSW5602 Ethernet Switch Installation Manual Chapter 4 Starting up the Switch and Upgrading Software 4.1 Starting up the Switch at the Initial Boot 4.1.1 Setting up a Configuration Environment 4.1.1.1 Connecting the Switch to the Terminal PC Connect the RJ-45 connector of the console cable to the console port on the switch, and connect the DB-9 female connector of the console cable to the serial port on the PC that is used for configuring the switch, as shown in Figure4-1. -
Page 57: Figure4-2 Setting Up A New Connection
DPtech LSW5602 Ethernet Switch Installation Manual Figure4-2 Setting up a new connection Enter the name of the new connection in the Name field and click <OK>. The dialog box, as shown in Figure 4-3 displays. Select the serial port to be used from the Connect Using dropdown menu. The serial port must be the same port connected by the console cable. -
Page 58: Figure4-4 Setting Communications Parameters
DPtech LSW5602 Ethernet Switch Installation Manual Table4-1 Configure serial port properties Properties Value Baud rate 9600 bps (the default) Data bits Parity check None Stop bits Flow control None Note： To restore the default settings, click Restore Defaults . ... -
Page 59: Figure4-5 Hyper Terminal
DPtech LSW5602 Ethernet Switch Installation Manual Figure4-5 Hyper Terminal Select File/Properties/Settings. In the Properties dialog box, select the Settings tab, as shown in Figure 4-6. Select VT100 or Auto detect in the Emulation dropdown menu. Click <OK>. Chapter 5 Maintenance and Troubleshooting... -
Page 60: Booting The Switch
DPtech LSW5602 Ethernet Switch Installation Manual Figure4-6 Settings tab 4.1.2 Booting the Switch 4.1.2.1 Verifying Installation before Power-up Before powering up the switch, check that: Both the power cord and the grounding wire are correctly connected. Proper power supply is used. -
Page 61: Starting Procedure
Verify whether terminal PC display normally. Method: start up your device and on the terminal PC you can view the device initialization information. Enter password at the command line and then you can configure <DPtech> command line. 4.1.3 Starting Procedure Power up your device, you can view the initialization information on the terminal PC display. -
Page 62: Default Login Method For Web
Password: Note： By default, the syetem password is DPTECH. 4.2 Default Login Method for Web LSW device support Web management function, the default IP address of network management interface 0 is: 192.168.0.1.Administrator can use web interface to manage and maintain the LSW device. - Page 63 DPtech LSW5602 Ethernet Switch Installation Manual Figure4-7 Web management interface Caution： You should not login to the web management interface by using of http or https protocol on the same After first time you login to the web management interface, modify the default login password.
-
Page 64: Chapter 5 Maintenance And Troubleshooting
DPtech LSW5602 Ethernet Switch Installation Manual Chapter 5 Maintenance and Troubleshooting 5.1 Dealing with Power System Failures Trouble phenomenon PWR LED on the front panel isn’t on. Troubleshooting You can know whether the power system has failed by reading the PWR LED on the front panel. If the power system is operating normally, the PWR LED is ON. -
Page 65: Garbled Characters On The Terminal
DPtech LSW5602 Ethernet Switch Installation Manual If no problem is found, examine the console cable or terminal PC(HyperTerminal) settings: please exam the followings: Bits per second is 9600, Data bits is 8 , Parity is None, Stop bits is 1 , Flow control is None, and Terminal Emulation is VT100.
