- Page 1 Compact Electric Valve Actuators SY05-C001A-TC...
-
Page 2: Table Of Contents
【T Series】Compact Electric Valve Actuator Contents General Information ..........................1 Safety Instructions ........................1 Installation Notices ........................1 Inspection, Storage, Transport ....................2 Product Overview ........................... 3 Product Features ........................3 3. Product Mechanical Data ........................4 Parts Identification ........................4 Technical Information ........................ -
Page 3: General Information
【T Series】Compact Electric Valve Actuator 1 General Information Failure to follow safety instructions may cause serious injury, equipment damage, or voided warranty. 1.1 Safety Instructions Installation, maintenance and repair works must be performed by trained personnel. The handling shall follow the safety and warning instruction contained in this manual. ... -
Page 4: Inspection, Storage, Transport
【T Series】Compact Electric Valve Actuator 1.3 Inspection, Storage, Transport 1.3.1 Receiving / Inspection Carefully inspect the package for any damages resulting from shipping and report all damages to the freight carrier and seller. After unpacking the product and information packet, please keep the cartons and any packing materials in case of product return or replacement. -
Page 5: Product Overview
【T Series】Compact Electric Valve Actuator 2 Product Overview The compact size T series comes with 6 Nm (53 in-lb) and 15 Nm (132 in-lb) output torque. The compact actuators are designed for limited space and suitable for small valve or damper application. -
Page 6: Product Mechanical Data
【T Series】Compact Electric Valve Actuator 3. Product Mechanical Data 3.1 Parts Identification Actuator Top Cover Motor Gear Clutch Base Hole for Open & Close Operation Handle 3.2 Technical Information Torque Weight Motor Power Flange Type Model Manual Override Nm in-lb ISO 5211 1.5 3.3 F03 / F05... -
Page 7: Sizing
【T Series】Compact Electric Valve Actuator 3.4 Sizing The actuator shall be sized to ensure that its torque output meets the load requirements of valve and its ability to overcome the required duty cycle of application (As a MINIMUM, a 30% safety factor is suggested for the calculation of torque requirement). If the maximum torque of 10”... -
Page 8: Valve Mounting Instructions
【T Series】Compact Electric Valve Actuator 3.6 Valve Mounting Instructions Make sure both the valve and actuator are in the same position before mounting, either fully-open or fully-closed. If not, refer to 4 (P.8) Manual Operation to adjust the actuator position to be the same as the valve. For example, the valve is at the open position, the actuator must be at the open position as well. -
Page 9: Wiring Instructions
【T Series】Compact Electric Valve Actuator 3.7 Wiring Instructions Turn power off before making the electrical connection! Connect the ground wire to PE point placed inside the electric actuator (a green screw) and wiring according to the wiring diagram inside the top cover. ... -
Page 10: Manual Operation
【T Series】Compact Electric Valve Actuator 4. Manual Operation Switch the clutch from electrical operation (E) to manual operation (H) with attached handle. Hole for Open & Close Operation Clutch b. Insert the handle into the hole for open & close operation. ( O : Open direction ; C : Close direction) Switch the clutch back to electrical operation (E) mode after the manual operation (H) is completed. -
Page 11: Actuator Set-Up
【T Series】Compact Electric Valve Actuator 5. Actuator Set-up The power must be off during this procedure so as to avoid damage to the actuator. All steps below must be completed before normal operation. The cam angle is the factory default value. After installation with the valve, if adjustment is needed, please adjust it in sequence. - Page 12 【T Series】Compact Electric Valve Actuator c. Adjust the fully- closed position 1. Switch the clutch from electrical operation (E) to manual operation (H) with attached handle. 2. Insert the handle into the hole for open & close position and manually operate the actuator to the fully-closed position.
-
Page 13: Control Board
【T Series】Compact Electric Valve Actuator 6. Control Board Surface Rated Voltage: 12V DC Rated Voltage: 24V DC LED 1 (OPEN) Terminal Block LED 2 (CLOSE) 2024.06... -
Page 14: Lamp Status
【T Series】Compact Electric Valve Actuator Lamp Status Lamp Code Actuator Status LED1 Fully-Open LED2 Fully-Closed Warning Messages Error Lamp Status Warning Message Solution Refer to the wiring diagram and LED 1 (green) and LED 2 Simultaneously input open confirm whether the wiring is correct (red) are lit simultaneously. -
Page 15: Troubleshooting
【T Series】Compact Electric Valve Actuator 7. Troubleshooting Floating Control Motor can not operate or overheats. Possible problems Solution a. The limit switch does not trip. a. Operate the actuator manually to fully-closed position and confirm if the limit switch trips. b. - Page 16 【T Series】Compact Electric Valve Actuator The valve cannot operate either electrical operation or manual operation. Possible problems Solution a. The actuator was mounted to the valve Please refer to 3.6 (P.6) Valve Mounting improperly. Instructions. b. The set screw of the cam loosened and Readjust the mechanical end stops and resulted in that the travel end positions limit switches, please refer to 5 (P.9 to...
-
Page 17: Warranty
【T Series】Compact Electric Valve Actuator 8. Warranty Sun Yeh Ele. Co. Ltd warrants that for a period of twelve months from the date of manufacture it will either repair or replace, at its option, any of its products which prove to be defective in material or workmanship.
