Zero Latency Wireless Video Transmission System
USER MANUAL
This user manual applies to:
Transmitter: 7118
Receiver: 3118
PRO Z
Version: 1.0
2021.09.16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO Z and is the answer not in the manual?

Questions and answers

Summary of Contents for CVW PRO Z

  • Page 1 PRO Z Zero Latency 800m+ Channel Scan HDMI & SDI Smart Cooling Multicast Mode 1080P60Hz Zero Latency Wireless Video Transmission System SHENZHEN CRYSTAL VIDEO TECHNOLOGY CO.,LTD USER MANUAL ADD: Unit 05-06, Floor 24, Changhong Science & Technology Mansion, Keji 12th Road South, High-tech Industrial Park, Nanshan District, Shenzhen, P.R.
  • Page 2 Handle with care! Fragile...
  • Page 3: Table Of Contents

    Overview Features Packing List The PRO Z is a zero latency wireless video transmission system designed for the most demanding cinema, broadcast applications. At less than 1 ms latency, the PRO Z Specification Wireless Video Transmission System can transmit 1080P60 4:2:2 video at up to Structure &...
  • Page 4: Packing List

    Packing List Specification Item Specification Please check the following items carefully after unpacking. If any of them is missing, please contact your seller. Frequency 5.1~5.9 GHz Bandwidth 40MHz 1080P 23.98/24/25/30/50/60 1080psf 23.98/24/25 1080i 50/59.94/60 Video Resolution 720P 50/59.94/60 576P 576i 480p 480i Audio Format Time Code ATC-VITC ATC-LTC...
  • Page 5: Structure & Interface

    Structure & Interface Transmitter Interface Description Transmitter: 7118 Name Function Antenna Connectors Displays channel info, video format, battery capacity, OLED Screen fan status, and other information. OLED Screen MENU Button UP Button Channel switching (+) UP Button DOWN Button MENU Button Menu interface V-MOUNT HDMI IN...
  • Page 6: Receiver: 3118

    Structure & Interface Receiver: 3118 Receiver Interface Description Antenna Connectors Name Function Displays channel info, video format, battery capacity, OLED Screen fan status, and other information. Antenna Connectors OLED Screen UP Button Channel switching (+) EJECT EJECT UP Button MENU Button Menu interface DOWN Button MENU Button...
  • Page 7: Mounting

    Mounting 2. Powered by the V-mount battery or power adapter. See below: For transmitter 7118 1. Install the antennas and make sure they are tightened. The angle between Battery Installation the transmitter’s two antennas should be perpendicular to achieve the best wireless transmission performance.
  • Page 8 For receiver 3118 3. The transmitter can be mounted on a camera with 1. Install the antennas and make sure they are tightened. The angle between the V-mount slot or 1/4-inch the receiver’s two antennas should be arranged to a 45° angle to achieve the screw thread.
  • Page 9: Receiver: 3118 1

    3. The receiver can be mounted 2. Powered by the V-mount battery or power adapter. See below: on the tripod using 1/4-inch or 3/8-inch screw thread, or on the monitor using the magic arm. Battery Installation L i- io n B a t t e r V-mount battery Receiver...
  • Page 10: Power Supply And Start-Up

    Power Supply and Start-Up b. Powered by the V-mount battery or other power sources with D-Tap 1. The transmitter can be powered by the following power sources: to 2-pin LEMO cable. a. Install the V-mount battery on the back of the transmitter. Both the camera and the transmitter can be powered by the V-mount battery.
  • Page 11 2. The receiver can be powered by the following power sources: b. Powered by the V-mount battery or other power sources with D-Tap a. Powered by V-mount battery. to 2-pin LEMO cable. L i- io n B a tt e ry p o w e r so u rc e s D-Tap to 2-pin LEMO cable...
  • Page 12: Oled Display Description

    OLED Display Description 7118 OLED Status 3118 OLED Status Fan Status Fan Status Battery Voltage Signal Strength 16.5V Video Signal NO VIDEO Signal Strength Battery Voltage 16.5V Operating Channel CH 1 Video Signal NO VIDEO Operating Channel CH 1 Item Status Item Status...
  • Page 13: Channel Switching Operation

    Channel Switching Operation Receiver’s Menu Button: 1. Press the Up or Down Button Long-press the Menu button for 3 seconds to enter the menu interface. The configurable settings are: channel scan, video colour, languages, 2. Then press the Menu button to confirm. firmware version number check.
  • Page 14: Precautions

    Precautions Installation Height and Distance c. When this system and other wireless devices are operating simultaneously, please keep at least 2 meters distance between them in order to prevent a. The transmission range is up to 800m in wide-open, unobstructed, and optimal the possible interference.
  • Page 15: Battery Endurance

    Examine whether there are other wireless devices or not, such as a wireless intercom system. It is recommended that the CVW product should be away at least 2 meters apart from other wireless devices.
