2
Range
IP
Channel
1km
Video
Ultra Low
Streaming
Latency
SHENZHEN CRYSTAL VIDEO TECHNOLOGY CO.,LTD
ADD: Unit 05-06, Floor 24, Changhong Science & Technology Mansion, Keji 12th Road South,
High-tech Industrial Park, Nanshan District, Shenzhen, P.R. China
Post code：518057
Tel: +86-755-29977913
Facebook:@crystalvideowireless Instagram: cvwtechnology
Full HD
5GHz
Band
High Definition
www.cv-hd.com
E-mail: Sales@cv-hd.com
BeamLink-Duo Plus
2-Channel Wireless Video Transmission System
USER MANUAL
This user manual applies to:
Transmitter:
7060*2
Receiver:
3062*1
Version: 1.0
2021.12.01
Advertisement
Table of Contents
Related Manuals for CVW BeamLink-Duo Plus
Summary of Contents for CVW BeamLink-Duo Plus
- Page 1 Ultra Low Streaming Band High Definition Latency BeamLink-Duo Plus 2-Channel Wireless Video Transmission System SHENZHEN CRYSTAL VIDEO TECHNOLOGY CO.,LTD USER MANUAL ADD: Unit 05-06, Floor 24, Changhong Science & Technology Mansion, Keji 12th Road South, High-tech Industrial Park, Nanshan District, Shenzhen, P.R. China This user manual applies to: Post code：518057...
-
Page 2: Table Of Contents
Contents Channel Switch Paring Caution Channel Scanning Function About the User Manual Low Gain Mode and High Gain Mode Product Overview Tally Function Instructions Product Highlights Tally Light Output Interface RS232/RS422 Transparent Transmission System Connectivity Diagram RTSP Streaming Mode Operation Packing List Interfaces and Buttons Extend the Transmission... -
Page 3: Caution
Product Overview BeamLink-Duo Plus is a multi-channel wireless video transmission system based on a * You must use this product within its temperature and humidity range. 5GHz band that supports 2-channel wireless video and audio transmission, Tally, and pan-tilt-zoom (PTZ) camera control, with video resolution up to 1080p/60Hz. -
Page 4: System Connectivity Diagram
Magic Arm * 2 RS232 Cable * 3 BeamLink-Duo Plus consists of 2 transmitters and 1 receiver. All transmitters support one HDMI and one SDI input. The receiver support 2 HDMI and 2 SDI outputs. It not * All the transmitters come with an NP-F battery holder and are preinstalled with a only can control Tally, RS232/RS422-enabled functions like camera control, but also V-mount connector;... -
Page 5: Interfaces And Buttons
Interfaces and Buttons Introduction to Transmitter’s Interfaces and Buttons TX: 7060 Name Function OLED display LNA ON/OFF button: High-gain and Low-gain mode switching WPS button: pairing Reset button Network status warning light, yellow light flickers slowly: network connecting; yellow light is on : network connected; red light flicker quickly: low battery. - Page 6 Function OLED display LNA ON/OFF button, screen display direction switching, High-gain and Low-gain mode switching CH/WPS button, channel switching, pairing Reset button Power button BeamLink-Duo Plus RS232/422 interface Tally input LAN port, Rj45 HDMI output SDI output DC input V-mount slot...
- Page 7 OLED Display Screen RX:3062 TX:7060 CH2 WPS L VIDEO VIDEO RESET VIDEO CH 2 Name Function Name Function Transmitter ID: two transmitters are numbered Channel: display current channel 1 and 2 respectively WPS: in pairing status Gain mode: low gain mode (the screen displays “L”) and high gain mode (the screen does not display “L”) Gain mode: low gain mode (the screen displays “L”) and high gain mode (the screen does not display “L”)
-
Page 8: Transmission Distance
Transmission Distance Short press the LNA ON/OFF button, the "SCAN..." will be displayed on the OLED screen. It means that the receiver is based on the current wireless environment to Factors to Influence Distance scan all the available channels. Once the scanning is completed, the channel quality Place the transmitter and receiver in a higher position to avoid the signal blocking. -
Page 9: Product Installation
Product Installation Installation of Transmitter 1. Attach the antennas to the transmitter’s antenna connectors. To achieve even better Distance ≥ 1m range performance, all antennas should be arranged in a fan shape. (as depicted in the diagram) 3. Please connect the transmitter to the camera with an SDI or HDMI cable. (as depicted in the diagram) SDI input HDMI input... -
Page 10: Installation Of Receiver
Installation of Receiver B: Vertical placement 1. Attach the antennas to the receiver’s antenna connectors . To achieve even better range A: Horizontal placement performance, all antennas should be arranged in a fan shape. (as depicted in the diagram) Place the receiver at a height of around 1.5 to 2 meters above the ground. -
Page 11: Product Operation
Product Operation Power Supply and Start-Up The transmitter can be powered by any of the following methods. Then switch the Connection transmitter on. 1. Connect the transmitter to the camera with an SDI or HDMI cable. a) Attach the NP-F battery to the NP-F battery slot in the back of the transmitter. SDI input HDMI input Transmitter... -
Page 12: Channel Switch
The receiver can be powered by any of the following methods. Then short press the Pairing power button to start up. Enable pairing on transmitters and receivers. a) Use the stock power adapter to supply power to the receiver. Transmitter: Long press the WPS button for 3 seconds. Once pairing is enabled, b) Use the V-mount battery to supply power to the receiver. -
Page 13: Channel Scanning Function
Channel Scanning Function Low Gain and High Gain Mode BeamLink-Duo Plus channel scanning function can analyze interference of each Supports two options of gain modes: low gain mode (the screen displays “L”) and channel, so you can select the one with least interference. -
Page 14: Tally Function Instructions
Tally Function Instructions RS232/RS422 Transparent Transmission Important Reminders: Important reminder: The follwing connector is RS232 by default. This system’s Tally function interface is factory customized. If you need this function, please contact our sales staff to confirm the pinout definition of its docking device Since there are different RS232/422 interfaces for each switch console on the market, and the type of device's interface. -
Page 15: Rtsp Streaming Mode Operation
RTSP Streaming Mode Operation Using RTSP streaming mode needs software decoding, which means images are transmitted through the receiver’s LAN port to streaming media software to decode and display. Moreover, there are many kinds of streaming media existing. The following description takes VLC media player for example. -
Page 16: Video Parameters Settings
Video Parameter Settings 1. Please make sure that the computer and the receiver remain connected. 2. Fix the bracket on the 2. Set a fixed IP address for the computer and keep it with the system’s IP address tripod with screws. on the same network segment. -
Page 17: Upgrade
Upgrade Connect the computer to the receiver's LAN port. Open the browser and input the WiFi IP address into the address box to enter the login page. 1. The steps of firmware update are the same for both the transmitter and the receiver. 2. -
Page 18: Product Specification
Select the “Upgrade” option in the “System” box. Product Specifications Item Transmitter: 7060 Receiver: 3062 Operating Frequency 5.1~5.8 GHz Antenna Mode 4*4 MIMO, 5dBi External Antenna Modulation Mode OFDM Transmission Power 17dbm (per antenna) Receiving Sensitivity： ≤-70dBm ≤-28dB 40 MHz Channel Bandwidth Wireless Standard 802.11n... -
Page 19: Important Reminders
Important Reminders Channel Settings 1) When one system is in use, it is recommended to set the channel at CH5-CH9. Installation height and interval distance Because in most Wi-Fi coverage environments, the high and low frequency is 1) Two conditions need to be met for a transmission distance of 1000 meters. mostly used, while somewhere between is rarely used. -
Page 20: Environmental Interference
Environmental Interference Installation of Product and Antenna The following environments will downgrade wireless transmission quality, resulting in 1) When installing the magic arm, please fix the transmitter in a direction you want, image and audio misalignment (such as image freeze, noise). then twist the magic arm to fix it on the camera. -
Page 21: Battery Duration
Battery Duration Troubleshooting 1) Take the NPF-970 battery for example, a transmitter with 12W of power Problems Solutions consumption, it will last about 3-4.5 hours. 1) In short-distance situations, please ensure that the transmitter and receiver’s antennas are already fully installed, then you must 2) Take the V-mount 95WH battery for example, a receiver with 20W of power place them 5 meters apart. - Page 22 HDMI port. Please unplug and plug the HDMI cable or change it to outputs video signal another HDMI cable. 7) If a wireless broadcasting and communication system is used on to the monitor set, please keep the broadcast and communication host and the CVW receiver at least 2 meters apart.
