BeamLink-Quad Plus 1U Rack
4-Channel Wireless Video Transmission System
USER MANUAL
This user manual applies to:
Transmitter:
7060*4
Receiver:
6689+3066*1
Version: 1.0
2023.2.8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CVW BeamLink-Quad Plus 1U Rack
Summary of Contents for CVW BeamLink-Quad Plus 1U Rack
- Page 1 Band Video Streaming High Definition Latency BeamLink-Quad Plus 1U Rack 4-Channel Wireless Video Transmission System SHENZHEN CRYSTAL VIDEO TECHNOLOGY CO.,LTD USER MANUAL ADD: Unit 05-06, Floor 24, Changhong Science & Technology Mansion, Keji 12th Road South, High-tech Industrial Park, Nanshan District, Shenzhen, P.R. China This user manual applies to: Post code：518057...
-
Page 2: Table Of Contents
Caution Contents Thank you for purchasing CVW’s wireless HD video transmission system. Caution carefully Before using this product, please read the following reminders. About the User Manual Product Overview * Avoid exposing this product to direct sunlight for long time or using it in dusted... -
Page 3: About The User Manual
RS232/422 Transparent Transmission Product Overview The RS232/422 port can support the pan-tilt-zoom (PTZ) camera control. BeamLink-Quad Plus 1U Rack is a multi-channel wireless video transmission system based on a 5GHz band that supports 4-channel wireless video and audio transmission, Packing List Tally, and pan-tilt-zoom (PTZ) camera control, with video resolution up to 1080p/60Hz. -
Page 4: Interfaces And Buttons
Interfaces and Buttons Introduction to Transmitter’s Interfaces and Buttons TX: 7060 Name Function OLED display LNA ON/OFF button: High-gain and Low-gain mode switching WPS button: pairing Reset button Network status warning light, yellow light flickers slowly: network connecting; yellow light is on : network connected; red light flicker quickly: low battery. - Page 5 RX: 6689 Introduction to Receiver’s Interfaces and Buttons Name Function Reset button WPS button, pairing DC input Power switch Power indicator: light on: operating normally; light off: power off or abnormal Network status indicator light: flash: fail to connect the network; solid: network connected Mode indicator light LAN port...
-
Page 6: Receiver
RX: 3066 Introduction to Receiver’s Interfaces and Buttons Operation Function Instruction Power Button OLED Display RESET Once the channel is switched to a different Short press channel on the receiver, the transmitter also Channel switch the CH or WPS will go with it. And the channel will be displayed on the screen of the transmitter button LNA ON/OFF... -
Page 7: Product Installation
Product Installation Installation of Transmitter 1. Attach the antennas to the transmitter’s antenna connectors. To achieve even better range performance, all antennas should be arranged in a fan shape. (as depicted in Distance ≥ 1m Distance ≥ 1m Distance ≥ 1m the diagram) 3. -
Page 8: Installation Of Receiver
Installation of Receiver 2. Please connect the receiver to the switch console or monitor with the SDI or 1. Mount the WiFi adapter on a tripod, then connect it to the receiver with HDMI cable(s). (The receiver supports 4 SDI outputs and 4 HDMI outputs) a network cable. -
Page 9: Oled Display Screen
OLED Display Screen RX:3066 TX:7060 CH 1 VIDEO VIDEO VIDEO RESET VIDEO VIDEO CH 2 Name Function Name Function Transmitter ID: four transmitters are numbered The corresponding transmitter ID: numbered 1, 2, 3, 4 respectively 1, 2, 3 and 4 respectively Video: video signal input connected Gain mode: low gain mode (the screen displays “L”) and high gain mode (the screen does not display “L”) - Page 10 Tally Function Instructions DB9_FEMALE Important Reminders: This system’s Tally function interface is factory customized. If you need this function, please contact our sales staff to confirm the pinout definition of its docking device and the type of device's interface. Plug the Tally light into the transmitter's Tally output port, and then connect the switch console to the receiver's Tally input interface with the customized Tally light RS232/RS422 Transparent Transmission cables.
-
Page 11: Rtsp Streaming Mode Operation
RTSP Streaming Mode Operation Using RTSP streaming mode needs software decoding, which means images are transmitted through the receiver’s LAN port to streaming media software to decode and display. Moreover, there are many kinds of streaming media existing. The following description takes VLC media player for example. -
Page 12: Video Parameter Settings
Video Parameter Settings 1. Please make sure that the computer and the receiver remain connected. 2. Fix the bracket on the 2. Set a fixed IP address for the computer and keep it with the system’s IP address tripod with screws. on the same network segment. -
Page 13: Upgrade
Upgrade Connect the computer to the receiver's LAN port. Open the browser and input the WiFi IP address into the address box to enter the login page. 1. The steps of firmware update are the same for both the transmitter and the receiver. 2. -
Page 14: System Connectivity Diagram
Select the “Upgrade” option in the “System” box. System Connectivity Diagram In a point-to-point mode or RTSP mode, four video resources are sent to the four transmitters via HDMI or SDI port. Then they were received and sent by the receiver to the other monitoring devices. -
Page 15: Product Specifications
Important Reminders Product Specifications Item Transmitter: 7060 Receiver: 3066 Installation height and interval distance Operating Frequency 5.1~5.8 GHz Antenna Mode 4*4 MIMO, 5dBi External Antenna 1) Two conditions need to be met for a transmission distance of 800 meters. Modulation Mode OFDM First, orient each antenna to have a clear line of sight. - Page 16 Environmental Interference Channel Settings The following environments will downgrade wireless transmission quality, resulting in 1) When one system is in use, it is recommended to set the channel at CH5-CH9. image and audio misalignment (such as image freeze, noise). Because in most Wi-Fi coverage environments, the high and low frequency is mostly used, while somewhere between is rarely used.
-
Page 17: Troubleshooting
Installation of Product and Antenna Troubleshooting 1) When installing the magic arm, please fix the transmitter in a direction you want, Problems Solutions then twist the magic arm to fix it on the camera. If you rotate the transmitter to fix it, the magic arm will not be easily demounted from the transmitter. - Page 18 HDMI port. Please unplug and plug the HDMI cable or change it to outputs video signal another HDMI cable. to the monitor 7) If a wireless broadcasting and communication system is used on set, please keep the broadcast and communication host and the CVW receiver at least 2 meters apart.
