Sealey AK44.V3 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this
‰
equipment.
Familiarise yourself with the application and the limitations of the grease gun, as well as the potential hazards.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Keep the grease gun clean for best and safest performance.
9
Check moving parts alignment on a regular basis.
9
DO NOT use the grease gun for any purpose other than that it was designed for.
8
DO NOT operate the grease gun if any parts are damaged or missing, as this may cause failure and/or personal injury.
8
When not in use store in a safe, dry, childproof location.
9
WARNING! Always wear approved eye protection when operating the grease gun.
‰
2. INTRODUCTION
Die-cast pump head with air-bleed valve. 3-Way fill with cartridge, bulk or manual capability. Supplied with rigid delivery tube and push-
on hydraulic 4-jaw coupling. Contoured pump handle. Accepts standard 400g cartridges.
3. SPECIFICATION
Model No:
Capacity:
Delivery per Stroke:
Delivery Pressure:
Nett Weight:
Optional Accessories:
4. OPERATION
1 Coupler
2 Outlet nozzle
3 Air vent valve
4 Handle
5 Plunger rod
handle
6 Lock lever
7 Barrel
8 Grease loader
fitting
© Jack Sealey Limited
3-WAY FILL MANUAL GREASE GUN
MODEL NO:
Wear protective
gloves
AK44.V3
500cm³
1.2cm³
10000psi
1.31kg
GGHE300 - Rubber Delivery Hose with 4-Jaw Connector Flexible 300mm 1/8"BSP Gas
1
2
3
7
6
fig.1
Original Language Version
AK44.V3
8
4
fig.2
5
AK44.V3 Issue 1 28/05/24
