Canon imageFORMULA ScanFront 400 Service Manual page 10

CHAPTER 1 GENERAL DESCRIPTION
2. Main Specifications
No. Item
Appearance/Installation
1 Type
2 Dimensions
3 Weight
4 Power supply
5 Power consumption
6 External interface
7 Expected product life
(In-house information)
8 Installation
9 Consumable parts
(Commercial goods)
Controller/Network
10 OS
11 CPU
12 Memory
13 Operation/Display
1-2
Desktop type sheet-fed network scanner
1) With the pickup tray and eject tray closed:
305 (W) x 282 (D) x 230 (H) mm
2) With the pickup tray and eject tray open:
305 (W) x 629 (D) x 366 (H) mm
4.5 kg (Main body only)
AC adaptor
1) Input: AC100V - 240V, 50/60Hz
2) Output: DC24V, 2.0A
1) Operating: 36 W or less
2) Low power mode: 2.0 W or less
3) Power switch OFF: 0.2 W or less
1) USB 2.0 (Hi-speed) x 3
2) LAN (10, 100 Base-TX, 1000 Base-T)
One of the following two items, whichever comes first.
1) 5 years
2) 2,500,000 sheets (A4)
*Replace parts if necessary.
By user
1) Exchange roller kit
Feed roller and retard roller
Replacement by users, recommended replacement
cycle: each 200,000 sheets
2) Carrier sheet
3) Lithium button battery (use market products)
Linux
Intel Celeron J1900 2.0GHz x 4Core
1) DDR3 SO-DIMM for program area/image area:
2GBytes
2) MicroSD Card for OS/set-up variables/address book:
8GBytes
1) 10.1-inch TFT WSVGA (1024x600 pixels) 260,000-color
liquid-crystal display
2) Capacitance touch panel
Table 1-101a
COPYRIGHT © CANON ELECTRONICS INC. 2016
Specifications
CANON SF-400 FIRST EDITION
