Page 1 User manual for poly-phase meter User Manual Three Phase Smart CT/CTPT Meter HXF300...
Page 2: Revision History
User manual for poly-phase meter Revision history Index Date Name Remarks First edition Feb.16th.2019 lvzhen Release version Jul.31th.2019 Chensha Modify the Dimension and Connection Jan.6th.2020 Zhiwei Mo Diagram, Certification Modify the Dimension of LCD, May.16th.2020 Zhiwei Mo Certification Modify the description of corresponding Jul.8 th.
Page 3: Document Description
Copyright © 2013 Hexing Electrical Co., Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Hexing Electrical Co., Ltd.
Page 4: Table Of Contents
User manual for poly-phase meter Content ................................1 1 Overview ............................1 2 Appearance ............................. 2 3 Standard ............................3 4 Working Principle .......................... 5 5 Measurement ..........................6 5.1 Active energy Measurement ................... 6 5.2 Reactive energy Measurement ..................6 5.3 Apparent energy Measurement ..................
Page 5 User manual for poly-phase meter 12.1.3 External battery replacement ................25 13 RTC ............................27 13.1 DST ..........................27 13.1.1 DST configurable ....................27 13.2 TOU ..........................28 13.2.1 Active and passive tariff ..................29 14 LED Indication ........................... 30 14.1 Active LED indication ....................
Page 6 User manual for poly-phase meter 23 Parameters ..........................51 24 Certification ..........................53 Annex A Communication and Display OBIS .................. 55 Annex B Demand content OBIS list ....................59...
Page 7: Overview
User manual for poly-phase meter 1 Overview The HXF300 three phase smart CT/CTPT meter is designed for measuring the import and export active energy, import and export reactive energy, maximum demand and instantaneous parameters. It supports contract management, multi-tariff, monthly billing, daily billing, load profile, event detection, neutral measurement (optional) and supply control etc.
Page 8: Appearance
User manual for poly-phase meter 2 Appearance 1. Communication module 6. LCD window 11. Display button 2. Communication module seal 7. Terminal cover 12. Sealable button 3. Active pulse LED 8. Terminal Block 13. Optical port 4. Reactive pulse LED 9.
Page 9: Standard
User manual for poly-phase meter 3 Standard Standard Description Electricity metering equipment (a.c.) IEC 62052-11 – General requirements, tests and test conditions – Part 11: Metering equipment Electricity metering equipment (a.c.) IEC 62053-22 –Particular requirements –Part 22:Static meters for active energy(classes 0.5S and 0.2S) Electricity metering equipment (AC) IEC 62053-23 –...
Page 10 User manual for poly-phase meter Electricity metering IEC62056-61 – Data exchange for meter reading, tariff and load control – Part 61:OBIS Object identification system Electricity metering IEC62056-62 – Data exchange for meter reading, tariff and load control – Part 62:Interface classes...
Page 11: Working Principle
User manual for poly-phase meter 4 Working Principle Relay LED Diode Micro Controler Button Load profile LCD Display Measuring System Calibration Optical Interface Data process EEPROM Memory Signal processing Time of use RS-485 Interface Event record Power Supply Non-volatile Memory Barrery Supply...
Page 12: Measurement
User manual for poly-phase meter 5 Measurement 5.1 Active energy Measurement ◼ Import active energy total and per tariff ◼ Export active energy total and per tariff ◼ Sum active energy total and per tariff ◼ Net active energy total and per tariff ◼...
Page 13: Instantaneous Measurement
User manual for poly-phase meter ◼ Export apparent energy in L1 ◼ Import apparent energy in L2 ◼ Export apparent energy in L2 ◼ Import apparent energy in L3 ◼ Export apparent energy in L3 5.4 Instantaneous Measurement ◼ Voltage ◼...
Page 14: Lcd Display
User manual for poly-phase meter 6 LCD display 6.1 LCD with full segments Below is LCD with full-segment display. Data display OBIS code LCD material is HTN/FSTN type, and its working temperature range is -40 ~＋ ➢ ℃ ℃ LCD shall be high contrast ratio. ➢...
Page 15: Display Segments
User manual for poly-phase meter 6.2 Display segments LCD display information Description Data display, 4.5mm*8.4 mm Maximum 8 digits, Energy display format: 6+2 Others: decimal 0～3 OBIS code display， 5mm*2.6mm Unit The meter is under communication Power direction indicator Battery status Disconnect status GPRS signal strength Current tariff...
Page 16: Display Mode
User manual for poly-phase meter is during DST period S3 on: tamper indicate(real time indication) S1, S2, S3 blink: indicate that the meter is not calibrated Reserved Reserved Reserved Reserved Fraud indicator(history indication) Over load indicator, such as overload 6.3 Display mode This meter is designed with three display modes: ⚫...
Page 17 User manual for poly-phase meter detailed display information please see display list. ⚫ Power off display The meter will switch off the LCD when power is off. When customer press the push button, the meter can display without backlight. In the power off state, The meter only supports push button display mode (not support auto scroll display mode).
Page 18: Demand
User manual for poly-phase meter 7 Demand 7.1 Calculation method of MD Support two types of MD calculation methods: sliding window time and block. MD sliding time can be set between 1 to 60 minutes, and MD sliding number can be set between 1~15, and the sliding time and number shall not be more than 60 by multiplication.
Page 19: Md Reset
User manual for poly-phase meter 7.3 MD reset There are two kinds of reset： Auto reset: reset according to the time preset，usually the same with billing time. Manual reset: 1. Push the seal button and hold for preset time. 2. Send command for MD reset.
Page 20: Load Profile
User manual for poly-phase meter 8 Load profile 8.1 load profile capacity Max. capture Load Profile Default application items Load Profile 1 Hourly Data(energy) Load Profile 2 Hourly Data(Instantaneous) Load Profile 9 Daily Billing Data The period can be 0,60,300,600,900,1800,3600,86400s, when you choose 0, •...
Page 21 User manual for poly-phase meter Reactive energy in QIII Reactive energy in QIV Reactive energy in QI in L1 Reactive energy in QII in L1 Reactive energy in QIII in L1 Reactive energy in QIV in L1 Reactive energy in QI in L2 Reactive energy in QII in L2 Reactive energy in QIII in L2 Reactive energy in QIV in L2...
Page 22 User manual for poly-phase meter Total instantaneous active power Instantaneous import active power Instantaneous export active power Instantaneous import reactive power Instantaneous export reactive power Instantaneous import apparent power Instantaneous export apparent power Instantaneous import active power in L1 Instantaneous export active power in L1 Instantaneous import active power in L2 Instantaneous export active power in L2 Instantaneous import active power in L3...
Page 23 User manual for poly-phase meter Last Maximum value of voltage L1 Last Maximum value of voltage L2 Last Maximum value of voltage L3 Last Maximum value of current L1 Last Maximum value of voltage L2 Last Maximum value of voltage L3 Last Maximum value of power factor L1 Last Maximum value of power factor L2 Last Maximum value of power factor L3...
Page 24: Billing
User manual for poly-phase meter 9 Billing 9.1 Daily freezing ➢ At least store 62 days data ➢ Freezing time: 00:00 at everyday midnight ➢ Freezing content: Can configurable, same as load profile list(item 8.2) ➢ Daily freezing profile is the load profile which set period into 1440min. 9.2 Monthly billing ➢...
Page 25 User manual for poly-phase meter ◼ Reactive energy in QII in L1 ◼ Reactive energy in QIII in L1 ◼ Reactive energy in QIV in L1 ◼ Reactive energy in QI in L2 ◼ Reactive energy in QII in L2 ◼...
Page 26 User manual for poly-phase meter ◼ Import active energy (interval) ◼ Export active energy (interval) ◼ Import reactive energy (interval) ◼ Export reactive energy (interval) ◼ Import active MD with time stamp ◼ Import active MD with time stamp tariff[X] ◼...
Page 27: Firmware Upgrade
User manual for poly-phase meter 10 Firmware Upgrade The meter and communication module support to update firmware remotely and locally. Update firmware will not do in meter and module until the new version of firmware is downloaded into the meter completely. The meter records the event log as the firmware update.
Page 28: Event Record
User manual for poly-phase meter 11 Event record 11.1 Event classification ➢ Standard event ➢ Tamper event ➢ Relay control event ➢ Power quality event ➢ Communication event 11.2 Event list Standard Event Switch to summer Clock adjusted(old date/time) Clock adjusted(new date/time) RTC error Low Battery Voltage Error register cleared...
Page 29 User manual for poly-phase meter Tamper Event Terminal Cover Open Terminal cover close Magnetic Influence Detection start Magnetic Influence Detection end Meter Cover Open Meter Cover close Association authentication failure (n time failed authentication) Module Cover Open Module cover close Current reversal(any phase current reversal happen ) Power Quality Event...
Page 30 User manual for poly-phase meter Power Quality Event Under voltage L2 end Under voltage L3 start Under voltage L3 end Over voltage L1 start Over voltage L1 end Over voltage L2 start Over voltage L2 end Over voltage L3 start Over voltage L3 end Reverse Energy L1 start Reverse Energy L1 end...
Page 31: Battery
User manual for poly-phase meter 12 Battery The meter has a 1200mA internal lithium battery and 220mA external changeable lithium battery（optional）. When the meter is powered off, the battery supplies for RTC, LCD display. 12.1 Back-up power Low battery detection 12.1.1 ⚫...
Page 32 User manual for poly-phase meter to avoid electrical shock accidentally! Before battery replacement, must power off the meter firstly, otherwise it may threat life. Make sure in replacement process, power grid will not be powered on by mis operation of others. 2）...
Page 33: Rtc
User manual for poly-phase meter 13 RTC ⚫ Supports calendar, time and leap year automatic switch function. ⚫ The accuracy is less than 0.5s/day at 23℃, fully comply with IEC 62054-21 ⚫ Content of clock and range ➢ year (2000~2099) ➢...
Page 34: Tou
User manual for poly-phase meter When DST function is enable or disable, or DST table configuring, or meter’s clock writing, all is need to wait till the hour, then it will execute DST switch judgment. When executing DST function is disabled, to ensure that meter’s clock can switch back to normal time, please to execute one command of wring meter clock.
Page 35: Active And Passive Tariff
User manual for poly-phase meter Season table Week table Calendar clock Name Valid date Week name Time/date Name Day table ID Up to 6 entries Up to 8 entries Exception days table Item Date Day table ID Script table Day table IDn(n=8) Script ident parmeter Day table ID3...
Page 36: Led Indication
User manual for poly-phase meter 14 LED Indication 14.1 Active LED indication When LED flash, it means active energy consumption. When meter power on, the LED support configurable into always on or off, default is always off. 14.2 Reactive LED indication When LED flash, it means reactive energy consumption.
Page 37: Communication Interface
User manual for poly-phase meter 15 Communication interface 15.1 Optical communication Comply with IEC62056-21 optical communication physical interface standard. Front view of optical port Signal wavelengths: 900nm~1000nm(infrared). The optical port of the meter has iron absorbing plate in order to well fix the optical head(have magnetic), to ensure the communication accuracy and to avoid the drop of optical head by force.
Page 38: Gprs Communication
User manual for poly-phase meter DLMS HDLC. Baud rate: 300~9600 bps (configurable), default is 9600bps. Data bits is 8, none parity 15.3 GPRS communication Communication standards: DLMS/COSEM, TCP/IP GPRS module online mode: ➢ Always online mode: module will online all time ➢...
Page 39: Client Management
User manual for poly-phase meter 16 Client management The meter shall fully support DLMS Security as described in the DLMS/COSEM Green Book, 8th. And it can transmit the data with/without encryption and authentication. Several authentication mechanisms are used to authenticate communication entities during AA establishment.
Page 40: Overall Dimensions And Installation
User manual for poly-phase meter 17 Overall dimensions and installation 17.1 Meter Connection Please follow the instruction to arrange the wire connection: a) Use copper cable as the lead-in wire to terminal block. b) Screw out the wire-fasten screw so that the connection wires can be inserted into. c) Remove the plastic cover of the connection wire long enough so that the wire-fasten screws can contact each connected wire.
Page 41 User manual for poly-phase meter 3P4W Asymmetric Connection with CT 3P3W Asymmetric Connection with CTPT ⚫ Auxiliary terminal wiring diagram ◼ 13-14: Auxiliary relay/no need ◼ 15-16 : Auxiliary relay/no need ◼ 17-18 : Reactive Energy pulse output/no need ◼ 19-20 : Active Energy pulse output/no need ◼...
Page 42: Meter Dimension
User manual for poly-phase meter 17.2 Meter Dimension Dimension of smart meter(long terminal cover) Width------------------------175.0 mm Height -----------------------245mm Depth ------------------------88.5mm 1.28 Weight-----------------------...
Page 43 User manual for poly-phase meter Dimension of smart meter(short terminal cover) Width------------------------175.0 mm Height -----------------------218.8mm Depth ------------------------88.5mm 1.28 Weight-----------------------...
Page 44 User manual for poly-phase meter Dimension of smart meter(Extra long terminal cover) Width------------------------175.0 mm Height -----------------------284.9mm Depth ------------------------88.5mm 1.28 Weight----------------------- ⚫ Installation dimension drawing...
Page 45 User manual for poly-phase meter Installation Dimension...
Page 46 User manual for poly-phase meter ⚫ Terminal drawing Dimension of Terminal Block...
Page 47: Installation And Un-Installation
User manual for poly-phase meter 18 Installation and un-installation 18.1 Installation tools Cross screwdriver Electric drill Wire stripper Lead sealing pliers Hairsprings...
Page 48: Preparation Before Installation
User manual for poly-phase meter Screw 18.2 Preparation before installation ◆ The meter should be installed in ventilated and dry place to ensure the meter’s safety and reliability. In dirty or risky areas, the meter should be installed in a protection box.
Page 49 User manual for poly-phase meter 3、Open the meter terminal cover and adjust the height of hanger. 4、Using the vertical installation method, the meter is hanging on the hanger screw, and fixed on the bottom by two screws. Need to ensure that the 3 screws are completely banned, and the meter is installed firmly, without shaking.
Page 50: Testing After Installation
User manual for poly-phase meter 7、The cables should be connected correctly according to the wiring diagram and the terminals should be tightened during the installation in order to avoid any damage caused by bad connection. The bad fixing of connection screws will lead to the raise of resistance, which can lead to electrical energy loss and heating of terminals.
Page 51: Un-Installation
User manual for poly-phase meter open, or strong magnetic field, no current indictor. ◼ Press button to display voltage value, double confirm the voltage. ◼ Check the relay is on the right position (if the symbol ‘ ’ is shown on the LCD).
Page 52: Service
(METER model can be obtained from the METER nameplate) 3. Package the METER, ensure the METER will not be damaged during transport. Try to use the original package. Don’t put in a METER with missing part. 4. Send the electric METER to a certified Hexing service center...
Page 53: Maintenance
User manual for poly-phase meter 20 Maintenance There is no need to verify the METER within the life cycle. METER maintenance can be executed based on local regulations. Recommended every 5~10 years. 20.1 Clean Use dry cloth to clean the surface of the METER and wipe the stains and insects. Warning: Flowing water and high pressure water equipment is not allowed to clean the METER, which may lead to short circuit.
Page 54: Reinstall
User manual for poly-phase meter 20.3 Reinstall In order to avoid the change of asset management, it’s recommended to reinstall the METER at the former position. The installation process detailed in chapter 20 "install and uninstall".
Page 55: Scarp Processing
User manual for poly-phase meter 21 Scarp Processing This chapter describes the right method of meter scarp processing. Compliant ISO 14001 environmental certification specification, the components of the meter is maximum extent separable, thus to provide corresponding abandoned and recycling station after disassembled. Attention: meter scarp processing reference to local waste and environmental protection laws and regulations.
Page 56: Transportation And Storage
User manual for poly-phase meter 22 Transportation and Storage The meters should be placed on pallet and the height should not exceed 5 layers. The storage condition should be clean, with an environmental temperature of between -40°C and +70°C, relative humidity of less than 98% and with an absence of rusty matter in the air.
Page 57: Parameters
User manual for poly-phase meter 23 Parameters Electrical Reference Voltage 3P4W: 3×57.7/100…3×240/415V 3×57.7/100V, 3×63.5/110V, 3×220/380V, 3×230/400V,3×240/415V 3P3W: 3×100V, 3×110V Basic current 1A ,5A Maximum current 6A,10A Starting current ≤1‰In Frequency 50Hz±2% Burden in current circuit ≤2VA Burden in voltage circuit ≤2W/10VA without communication ≤5W/25VA with communication Battery life...
Page 58 User manual for poly-phase meter Standard Compliance IEC62052-11, IEC62053-22, IEC62053-23 or IEC62053-24, EN50470-1, EN50470-3, Mechanical parameters Connection type Indirect connection Network type 3P4W or 3P3W Terminal configuration L1L1L2L2L3L3NN (3P4W) L1L1L2L2L3L3 (3P3W) Weight of Meter 1.28 kg Dimension(H x W x D) Long terminal cover: 245mm×175mm×88.5mm Or Extra Long terminal cover:...
Page 59: Certification
User manual for poly-phase meter 24 Certification...
Page 60 User manual for poly-phase meter...
Page 61: Annex A Communication And Display Obis
User manual for poly-phase meter Annex A Communication and Display OBIS Display Display items Display format OBIS code Energy Active energy import (+A) 1.8.0 xxxxxx.xx kWh Active energy import (+A) rate X 1.8.X xxxxxx.xx kWh Active energy export (-A) 2.8.0 xxxxxx.xx kWh Active energy export (-A) rate X 2.8.X...
Page 62 User manual for poly-phase meter Display Display items Display format OBIS code Instantaneous reactive import power (+R) 3.7.0 xx.xx kvar Instantaneous reactive export power (-R) 4.7.0 xx.xx kvar Instantaneous active import power (+A) in 21.7.0 xx.xx kW Instantaneous active export power (-A) in 22.7.0 xx.xx kW Instantaneous reactive import power (+R) in...
Page 63 User manual for poly-phase meter Display Display items Display format OBIS code Import active MD rate X occurrence date 1.6.X yy-mm-dd Import active MD rate X occurrence time 1.6.X hh:mm:ss Export active M.D 2.6.0 xxxxx.xxx kW Export active MD occurrence date 2.6.0 yy-mm-dd Export active MD occurrence time...
Page 64 User manual for poly-phase meter Display Display items Display format OBIS code Number of long power failures on all phase C.7.5 xxxxxxx Reason of disconnected 146.A.18 Calendar name 13.0.0 xxxxxxxx Limiter 1 threshold 17.0.0 xxxxx.xxx kW Display all on LCD C.2.221 Battery voltage C.6.3...
Page 65: Annex B Demand Content Obis List
User manual for poly-phase meter Annex B Demand content OBIS list Description OBIS Active import demand 1.0.1.4.0.255 Reactive import demand 1.0.2.4.0.255 Active export demand 1.0.3.4.0.255 Reactive export demand 1.0.4.4.0.255 Reactive demand in QI 1.0.5.4.0.255 Reactive demand in QII 1.0.6.4.0.255 Reactive demand in QIII 1.0.7.4.0.255 Reactive demand in QIV 1.0.8.4.0.255...
Page 66 User manual for poly-phase meter Hexing Electrical Co., Ltd. www.hxgroup.co Add: shangchen Industrial Zone; 1418 Moganshan Road, Hangzhou, China...
