- Page 1 User manual for single-phase meter User Manual Single Phase Smart AMI Meter HXE110...
- Page 2 User manual for single-phase meter Revision history Index Date Name Remarks First Release Nov. 20th. 2020 HXEING Update Apr. 21th. 2021 HXEING Update Jun. 28th. 2021 HXEING Update Nov. 26th. 2021 HXEING Update Dec. 9th. 2021 HXEING Update June. 6th. 2022 HXEING Add 1P2W Connection Diagram, June.
- Page 3 Copyright © 2013 Hexing Electrical Co., Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Hexing Electrical Co., Ltd.
-
Page 4: Table Of Contents
User manual for single-phase meter Content 1 Overview ............................1 2 Appearance ............................. 2 3 Standards Compliance ........................3 4 Working Principle .......................... 4 5 Measurement ..........................6 5.1 Active energy Measurement ................... 6 5.2 Reactive energy Measurement ..................6 5.3 Apparent energy Measurement .................. - Page 5 User manual for single-phase meter 12 Firmware Upgrade ........................23 13 Event record ..........................24 13.1 Standard event ......................24 13.2 Tamper event ......................25 13.3 Relay control event ...................... 25 13.4 Power quality event ....................26 13.5 Communication event ....................27 14 Back-up power ...........................
- Page 6 User manual for single-phase meter 18.3 PLC Communication (optional) ..................45 18.4 Wisun Communication (optional) ................45 18.5 4G communication ...................... 45 19 Client management ........................46 20 Overall dimensions and installation ................... 48 20.1 Meter Connection ....................... 48 20.2 Meter Dimension ......................50 21 Installation and un-installation ....................
-
Page 7: Overview
User manual for single-phase meter 1 Overview The HXE110 single-phase smart meter is design for measuring the import and export active energy, import and export reactive energy, maximum demand and instantaneous parameters. It supports contract management, multi-tariff, monthly billing, daily billing, load profile, event detection, neutral measurement (optional) and supply control etc. -
Page 8: Appearance
User manual for single-phase meter 2 Appearance 1. Communication module 6. LCD window 11. Display button 2. Communication module seal 7. Terminal cover 12. Sealable button 3. Active pulse LED 8. Terminal Block 13. Optical port 4. Alarm LED 9. Terminal cover seal 14. -
Page 9: Standards Compliance
User manual for single-phase meter 3 Standards Compliance Standard Description Electricity metering equipment (AC.) – General requirements, tests and test conditions IEC 62052-11 – Part 11: Metering equipment Electricity metering equipment (AC.) IEC 62053-21 –Particular requirements –Part 21:Static meters for active energy(classes 1 and 2) Electricity metering equipment (AC) IEC 62053-23 –... -
Page 10: Working Principle
User manual for single-phase meter 4 Working Principle Relay LED Diode Micro Controler Button Measuring Load profile LCD Display System Calibration Optical Interface Data process Signal EEPROM Memory Time of use processing RS-485 Interface Event record Power Supply Non-volatile Memory Backup power Supply Input&Output Inputs:... - Page 11 User manual for single-phase meter The supply voltage for the meter is obtained from the power grid, ensuring the normal operation of internal parts of the meter. Battery: The battery supply connected in parallel with the normal supply ensures the operation of the meter free from outage.
-
Page 12: Measurement
User manual for single-phase meter 5 Measurement 5.1 Active energy Measurement The Energy accumulate mode is +A=A ;-A=A The support Energy registers as below: Import active energy Total & per tariff Export active energy Total & per tariff Combined active energy Total &... -
Page 13: Lcd Display
User manual for single-phase meter 6 LCD display 6.1 LCD with full segments LCD with full-segment display is as following: LCD material is HTN type, and its working temperature range is -40℃~＋80℃. LCD shall be high contrast ratio. LCD view angle 6 o'clock. -
Page 14: Display Mode
User manual for single-phase meter Unit The meter is in communication Four-quadrant indicator Indicate the direction of the power 1) Right arrow: Import 2) Left arrow: Export 3) Not displayed or displayed as input power: grid power on but no import 4) No display: when voltage indicator has no display Battery status... -
Page 15: Lcd Backlight
User manual for single-phase meter next screen display automatically. Auto-scrolling display item list is also configurable with 60 items, detailed display information please check the display list. Manual mode display I Manual display mode can be activated by pressing and holding display button for 3s, a short and repeated press of display button will change the screen display. - Page 16 User manual for single-phase meter presses the button, the LCD backlight will light. When after a certain time (default as 60s) not press the button, the LCD backlight will off.
-
Page 17: Demand
•Subinterval length - also specified in minutes and may be any value that is evenly divisible into the interval length Both of these values are configurable by Hexing meter support software. The demand is calculated at the end of each subinterval, resulting in overlapping demand intervals. -
Page 18: Md Registers
User manual for single-phase meter ②Block interval. Block demand interval is a special case of rolling interval demand in which the subinterval is the same size as the demand interval. The maximum demand(MD) calculation named period maximum demand. And the methods for demand calculation is the same as the normal one. - Page 19 User manual for single-phase meter ①Auto reset: Reset according to the time preset, usually the same with billing time. ②Manual reset(Button and Command): a) Button reset (optional): Press the seal button(up button) and hold on for 6 seconds to reset the MD. b) Command reset, reset according to command by communication.
-
Page 20: Load Profile
User manual for single-phase meter 8 Load profile 8.1 Load profile capacity Load Profile Default application Max. capture items Profile total bytes Load Profile 1 Hourly Data(energy) 228kbyte Load Profile 2 Hourly Data(Instantaneous) 892kbyte Load Profile 9 Daily Billing Data 32kbyte The period can be setting from 1-1440mins, when you choose 0, means no need for this ... - Page 21 User manual for single-phase meter Net active energy per tariff Import reactive energy per tariff Export reactive energy per tariff Reactive energy per tariff in QI Reactive energy per tariff in QII Reactive energy per tariff in QIII Reactive energy per tariff in QIV Import apparent energy per tariff Export apparent energy per tariff Import active energy (Interval)
-
Page 22: Arithmetic Of Load Profile Capacity
User manual for single-phase meter Last average value of power factor L1 Last average value of power factor Last average value of import active power Last average value of export active power Last average value of import reactive power Last average value of export reactive power Last Maximum value of voltage L1 Last Maximum value of current L1 Last Maximum value of power factor L1... -
Page 23: Billing
User manual for single-phase meter 9 Billing 9.1 Daily freezing At least keep 62 days data Freezing time: 00:00 at midnight everyday Freezing content: Can be configurable, same as load profile list(item 8.2) Daily freezing profile is the load profile whose period is set as 1440min(one day). ... - Page 24 User manual for single-phase meter Import reactive energy per tariff Export reactive energy per tariff Reactive energy per tariff in QI Reactive energy per tariff in QII Reactive energy per tariff in QIII Reactive energy per tariff in QIV ...
-
Page 25: Relay Control
User manual for single-phase meter 10 Relay control Relay control logic figure Remote control: means send command to disconnect/connect. Manual control: means press button to disconnect/connect. The relay symbol on the LCD will flash when the relay status is "Ready for Connection", then long press the display button 6S to reconnect the relay. -
Page 26: Relay Status
User manual for single-phase meter 10.1 Relay status Status Description Disconnected(0) In this status, relay is off, Any other operation is not allowed except that system or PC software send the cancel relay off command Connected(1) In this status, relay is on Ready for connected(2) In this status, relay is off 10.2 Relay control command... -
Page 27: Relay Control Mode
User manual for single-phase meter 10.3 Relay control mode The default mode is mode 6. Disconnection Reconnection Control Remote Manual Local Remote Manual Local mode × × × × × × × × √ √ × √ × √ √ ×... -
Page 28: Load Control
User manual for single-phase meter 11 Load control Load control monitor object can be total instantaneous active power(import + export), total instantaneous import active power, total instantaneous export active power, Maximum current in three phase, Maximum active power in three phase. Overload disconnect logic: When load is higher than the preset threshold A and duration the preset delay time B, relay ... -
Page 29: Firmware Upgrade
User manual for single-phase meter 12 Firmware Upgrade Meter and communication module firmware can be upgraded remotely and/or locally. Firmware upgrade will not work in meter and module until the new version of firmware is uploaded into the meter completely. The meter records the event log as the firmware update. The meter is fully compliant with the upgrade process defined in the DLMS standard: •... -
Page 30: Event Record
User manual for single-phase meter 13 Event record The meter is able to record a large quantity of events, which comprise many different types of events. The event type, corresponding record format, event code, judge method and record capacity could be seen in the later description 13.1 Standard event No special characteristics are declared in this kind of events. -
Page 31: Tamper Event
User manual for single-phase meter 13.2 Tamper event These events are all about electricity tampering, Record format: event code and occurring time. Up to 100 entries of events can be recorded Tab13.1.2 Tampering event Code Corresponding event Judgment Terminal cover open Terminal cover being open Terminal cover closed Terminal cover being closed... -
Page 32: Power Quality Event
User manual for single-phase meter Limiter threshold changed The value of Limiter threshold have changed Local reconnection Local reconnect is executed 13.4 Power quality event These events are about power grid. Record format: event code and occurring time. Up to 200 entries of power grid events can be recorded. Tab13.4.4 Power grid event Code Corresponding event... -
Page 33: Communication Event
User manual for single-phase meter 13.5 Communication event No special characteristics are declared in this kind of events. Record format: event code and occurring time. Up to 100 entries of standard events can be recorded. Tab13.4.5 communication event Code Corresponding event Judgment Signal quality restore Signal quality restore... -
Page 34: Back-Up Power
User manual for single-phase meter 14 Back-up power 14.1 Battery The meter has a 1200mA internal lithium battery or 1200mA external replacement lithium battery(optional). When the meter is power off, the battery supplies for RTC, LCD display and event will be recorded. 14.1.1 Low battery detection When the meter is power on, the voltage will be measured by AD sampling per second. - Page 35 User manual for single-phase meter it may threat life. Make sure in replacement process, power grid will not be powered on by misoperation. Open terminal cover. Remove the battery to be replaced. Plug in the new battery. If the display of meter works, it means currently new battery installation is correct. Close terminal cover.
-
Page 36: Rtc
User manual for single-phase meter 15 RTC Supports calendar, time and leap year automatic when switching function. The accuracy is less than 0.5s/day at 23℃, totally comply with IEC 62054-21 Content of clock and range Year (2000~2099) ... -
Page 37: Restrictive Conditions
User manual for single-phase meter under DST setted. 15.1.2 Restrictive conditions DST time span cannot exceed 10 months for a single DST. DST time span cannot be less than 1 day for a single DST. 15.2 TOU Support 4 tariffs. Support maximum 50 holidays. -
Page 38: Active And Passive Tariff
User manual for single-phase meter Season table Week table Calendar clock Name Valid date Week name Time/date Name Day table ID Up to 6 entries Up to 8 entries Exception days table Item Date Day table ID Script table Day table IDn(n=8) Script ident parmeter Day table ID3... -
Page 39: Sts Function (Optional)
User manual for single-phase meter 16 STS function (optional) 16.1 Recharging When the user goes to the existing vending point and buys electricity, he will get a standard 20-digit token. The user enters the 20-dight token using the keypad. Should the user have keyed in an ... -
Page 40: Management
User manual for single-phase meter TOKEN expired Key expired Recharge amount exceeds the maximum credit. Key type is wrong and recharge is not allowed 16.2 Management This type of token is encrypted by STA and can be used by relevant meter: ... - Page 41 User manual for single-phase meter Clear event status Prepaid mode switches to postpaid mode and Postpaid mode switches to prepaid mode Changing the meter key. In terms of the STS standard the meter requires 2 token codes to change the key. There is no sequence between two tokens but the user must enter the second token within 2 minutes after entering the first token otherwise the first token entered will be disregarded.
-
Page 42: Test
User manual for single-phase meter After input the first key change token, then input the 2rd one with wrong token, If the existing key type is not initiation key, then cannot change to initiation key. Key type cannot be changed to 3 ... -
Page 43: Cancellation Registration (Optional)
User manual for single-phase meter 1844-6744-0738-4377-2416 Display tariff index 3689-3488-1475-5332-2496 Display maximum power. 0000-0000-0012-0797-4400 Display meter status. 0000-0000-0022-8172-8512 Display power 0000-0000-0044-2920-8064 Display meter version 0000-0000-0087-2419-5840 16.4 Cancellation registration (optional) Should the Utility or the electricity consumers have a requirement to remove the meter or change the meter, the registration of the meter could be canceled in the following manners: ... - Page 44 User manual for single-phase meter The Electricity consumers can input three codes as a short cut key as follows Short code Function Short code Function Import active power Credit balance Current date Current time Meter number SGC number Reason for Relay operation Meter status Total power Tariff index...
- Page 45 User manual for single-phase meter 802 – Current date: 18/Aug/2012 803 – Current time: 20:35:35 804 – Meter number: In terms of STS standard, there are 11 digits in meter number. It is displayed in two screens, for example, should the meter number is 14203528142.
- Page 46 User manual for single-phase meter BIT7 … BIT0 BIT0: Meter cover open BIT1: Terminal cover open BIT2: Over voltage BIT3: Under voltage BIT4: Reverse BIT5: Bypass BIT6: Overload BIT7: Strong magnetic filed ...
- Page 47 User manual for single-phase meter 814 – Total import active power of current month: 1.10kWh 815 – The date of last recharging: 19/July/2012 816 – The time of last recharging: 21:35:15 817 – The credit of last recharging: 100.00kWh ...
- Page 48 User manual for single-phase meter 869 – Maximum power: 25.0000kWh 870 – Voltage: 220.8V The short code does not exist The inquiry record does not exist E.g. the user wants to check the last 5 recharging tokens but the meter only has 4 recharging records then it will indicate the inquiry record does not exist...
-
Page 49: Led Indication
User manual for single-phase meter 17 LED Indication 17.1 Active LED indication When LED flashes, it means active energy consumption. When meter powers on, the LED is available to configure in the status always on or off, default is always off. 17.2 Alarm LED indication When tamper events occur, alarm LED will light on all the time. -
Page 50: Communication Interface
User manual for single-phase meter 18 Communication interface The meter can be equipped with an optical port, RS485 or RF interface. The customer can choose one or more. 18.1 Optical communication Comply with IEC62056-21 optical communication physical interface standard. Front view of optical port Signal wavelengths: 900nm~1000nm(infrared). -
Page 51: Rs485 Interface(Optional)
User manual for single-phase meter 18.2 RS485 interface(optional) Communication protocol: DLMS HDLC or IEC62056-21 E mode, default is DLMS HDLC. Baud rate: 300~9600 bps (configurable), default is 9600bps. Data bits is 8, none parity. 18.3 PLC Communication (optional) Baud rate: 9600bps, 8 data bits, no check bit. ... -
Page 52: Client Management
User manual for single-phase meter 19 Client management The meter shall fully support DLMS Security as described in the 8 version DLMS/COSEM Green Book, And it can transmit the data with/without encryption and authentication. Several authentication mechanisms are used to authenticate communication entities during AA establishment. - Page 53 User manual for single-phase meter mechanism_id(5 CtoS: Random string StoC: Random SC II IC II GMAC (SC SC II IC II GMAC ) HLS GMAC 8-64 octets string 8-64 octets || AK || StoC) (SC || AK || CtoS) Optionally: Optionally: System-Title-C in System-Title-S in...
-
Page 54: Overall Dimensions And Installation
User manual for single-phase meter 20 Overall dimensions and installation 20.1 Meter Connection Please follow the instruction to arrange the wire connection: a) Use copper cable to connect terminal block. b) Screw out the wire-fasten screw so that the connection wires can be inserted into. c) Remove the plastic cover of the connection wire and make sure that the exposed wire is long enough, the recommended length is no less than 22 cm... - Page 55 User manual for single-phase meter 1P3W L1L1L2L2 Connection 1P3W CT I1L1I1I2L2I2 Connection Auxiliary terminal wiring diagram 20-21 : Null 22-23 : Active Energy pulse output/Reactive Energy pulse output /Null 24-25: Null 26-27 : RS485/ SI/ Null ...
-
Page 56: Meter Dimension
User manual for single-phase meter 20.2 Meter Dimension Dimension of smart meter Length——221mm(30mm terminal cover) Width——132mm Height——73mm Terminal space——30mm Installation dimension drawing... - Page 57 User manual for single-phase meter Installation Dimension Terminal drawing Dimension of Terminal Block(DC) Dimension of Terminal Block(CT)
-
Page 58: Installation And Un-Installation
User manual for single-phase meter 21 Installation and un-installation 21.1 Installation tools Cross screwdriver Electric drill Wire stripper Lead sealing pliers Hair springs Screw... -
Page 59: Preparation Before Installation
User manual for single-phase meter 21.2 Preparation before installation The meter should be installed in ventilated and dry place to ensure the meter’s safety and reliability. In dirty or risky area, the meter should be installed in a protection box. ... - Page 60 User manual for single-phase meter To ensure the installation stability, the diameter of hanger screw must be longer than 11mm, and the diameter of bottom fixed screws must be wider than 7mm. 5. Cut the cable to the required length and use the wire stripper to uncover the cable. The recommended bare metal length after stripping is at least 20mm for this series of products.
-
Page 61: Test After Installation
User manual for single-phase meter Please be careful and don’t connected the auxiliary terminal to the voltage or current line by mistake, to avoid damage to meter. 9. Check connecting wire carefully and avoid any error (such as the reverse wiring for the incoming and outgoing lines, the wrong connection of live and neutral, the bad fixing of screws). - Page 62 User manual for single-phase meter Use the voltage test equipment (such as multi-meter) to test meter connecting wire and confirm power-off before go to the next operation. Use the appropriate screwdriver to unscrew the meter auxiliary terminal screws and remove the connecting wires.
-
Page 63: Service
METER nameplate) 3. Package the METER, ensure the METER will not be damaged during the transport. Try to use the original package. Don’t put in a METER with missing part 4. Send the electric METER to a certified Hexing service center... -
Page 64: Maintenance
User manual for single-phase meter 23 Maintenance There is no need to change the METER within the life cycle. METER maintenance can be executed based on local regulations. Recommended every 5~10 years. 23.1 Clean Use dry cloth to clean the surface of the METER and wipe the stains and insects. Warning: Flowing water and high-pressure water equipment is not allowed to clean the METER, which may lead to short circuit. - Page 65 User manual for single-phase meter The installation process detailed refer to chapter "installation and uninstallation".
-
Page 66: Scrap Processing
User manual for single-phase meter 24 Scrap Processing This chapter describes the right method of meter scrap processing. According to ISO 14001 environmental certification specification, the components of the meter is separable, therefore you can send the corresponding abandoned and recycling station after disassembled. -
Page 67: Transportation And Storage
User manual for single-phase meter 25 Transportation and Storage The meters should be placed on pallet and the height should not exceed 5 layers. The storage condition should be clean, with an environmental temperature of between -40°C and +70°C, relative humidity of less than 95% and with an absence of rusty matter in the air. -
Page 68: Parameters
User manual for single-phase meter 26 Parameters Electrical 1P2W: 120V Reference Voltage 1P3W: 110-220V 5A,10A(DC) Basic current 1A,5A(CT) 60A,80A,100A(DC) Maximum current 10A(CT) Starting current ≤0.4%Ib(active) ≤0.5%Ib(reactive) Frequency 60Hz Consumption in current ≤2VA circuit Consumption in voltage ≤2W/10VA without communication circuit ≤5W/25VA with communication Battery life 10years... - Page 69 User manual for single-phase meter IEC62053-23 Mechanical parameters Connection type Direct or Indirect connection Network type 1P2W or 1P3W LLNN (1P2W DC), L1L1L2L2 (1P3W DC) Terminal configuration I1L1I1I2L2I2 (1P3W CT) Weight of Meter 1.08 kg Long terminal cover: Dimension(H x W x D) 221mm×132mm×73mm Mounting Front projection mounting...
-
Page 70: Annex A Communication And Display Obis
User manual for single-phase meter Annex A Communication and Display OBIS Display OBIS Display items Display format code Energy Active energy import (+A) 1.8.0 xxxxxx.xx kWh Active energy import (+A) rate X 1.8.X xxxxxx.xx kWh Active energy export (-A) 2.8.0 xxxxxx.xx kWh Active energy export (-A) rate X 2.8.X... - Page 71 User manual for single-phase meter Display OBIS Display items Display format code Instantaneous power factor (PF) 13.7.0 x.xxx Demand Import active MD 1.6.0 xxxxx.xxx kW Import active MD occurrence date 1.6.0 dd-mm-yy Import active MD occurrence time 1.6.0 hh:mm:ss Import active MD rate X 1.6.X xxxxx.xxx kW Import active MD rate X occurrence date...
- Page 72 User manual for single-phase meter Display OBIS Display items Display format code Others Local time 0.9.1 hh:mm:ss Local date 0.9.2 mm-dd-yy Error register F.F.0 xxxxxxxx Meter serial number 0.C.1.0 xxxxxxx Number of power failures on all phase C.7.0 xxxxxxx Number of long power failures on all phase C.7.5 xxxxxxx Reason of disconnected...
-
Page 73: Annex B Demand Content Obis List
User manual for single-phase meter Annex B Demand content OBIS list Description OBIS Active import demand 1.0.1.4.0.255 Active export demand 1.0.2.4.0.255 Reactive import demand 1.0.3.4.0.255 Reactive export demand 1.0.4.4.0.255 Reactive demand in QI 1.0.5.4.0.255 Reactive demand in QII 1.0.6.4.0.255 Reactive demand in QIII 1.0.7.4.0.255 Reactive demand in QIV 1.0.8.4.0.255... - Page 74 User manual for single-phase meter...
- Page 75 User manual for single-phase meter Hexing Electrical Co., Ltd. www.hxgroup.co Add: shangcheng Industrial Zone 1418 Moganshan Road, Hangzhou, China...
