- Page 1 User manual for G3 User manual G3 Smart Metering system HXCG3A-P HXP210 HXEC210 CIU EV500 CIU EV800...
- Page 2 User manual for G3 Revision History Version Date Name Remarks /May/2022 Jason, Initializing for new G3 Choiam /June/2022 Jason, Optimized contents Choiam installation /July/2022 Choinam Add contents about main circuit breaker and 18 spots cabinet /August/2023 Choinam Delete 150A,250A main circuit breaker /August/2023 Choinam Add information about CIU...
- Page 3 User manual for G3 Document description Effective coverage: This user manual only applies to Hexing meter type as mentioned in the document title. Objective: This user manual includes the relevant technical information of meter. User can consult this document for the use and maintenance of the meter.
-
Page 4: Table Of Contents
User manual for G3 Content Revision History ....................II Document description ..................III Content ....................... IV 1. General introduction ..................1 1.1 Product overview ..................... 1 1.2 Main Features ......................1 2. Solution Devices ....................3 2.1 Installation Layout ....................3 2.2 Main Devices ...................... - Page 5 User manual for G3 12. Event record ....................39 12.1 Door open detection .................... 39 12.2 Over temperature detection ................39 13. Parameter setting and query ................40 14. Overall dimensions ..................41 14.1 Dimension of all devices ..................41 15.
-
Page 6: General Introduction
General introduction Product overview Hexing all-in-one smart metering system G3 series devotes to provide high- level protection against electricity fraud, water, dust, flame, UV and corrosion. G3 has been working in Latin America countries for more than 8 years and helps power grid saving money in line loss. - Page 7 User manual for G3 ⚫ Product has firm structure and high level of protection (can reach IEC60529-IP54), that make sure the inside metering devices can work well and securely even under extreme environment. ⚫ Illegal door opening will be detected immediately and detection can last to at least 8 hours even out of power.
-
Page 8: Solution Devices
User manual for G3 Solution Devices Installation Layout 12pcs meters as standard version DC (Data collector) Plug and play meter Outlet antenna hole Inlet terminal Optional version for 12 spots with main circuit breaker Inlet wiring hole Outlet wiring hole... - Page 9 User manual for G3 Optional version for 18 spots with main circuit breaker...
- Page 10 User manual for G3 Optional version for 12 spots with junction box(used to cascade connection in power supply)
- Page 11 User manual for G3 Optional version for 12 spots with junction box(used to cascade connection in power supply)
- Page 12 User manual for G3...
-
Page 13: Main Devices
User manual for G3 Main Devices HXCG3A Cabinet Metal container for physical protection of meters, collectors, meter base and so on. Slight-and-handy design provides convenience for installation and maintenance. HXP200 Plug-and-play meter Responsible for basic measurement of single-phase and two-wire, single-phase and three-wire circuit. - Page 14 User manual for G3 HHU/APP Local readout and configuration for each meter. It interacts with data collector by using WIFI communication. Main circuit breaker It is optional in case of customer want to cut off power supply manually inside of the meter cabinet. Here provides three kinds of specification as 100A ,200A.
-
Page 15: Technical Parameter
User manual for G3 Technical Parameter Accuracy Class 1 Active Class 2 Reactive Current Sensor Shunt Measured quantities Active Energy Reactive Energy Measurement Topology 1P2W 1P3W Energy Measurement Type Bidirectional Constant 1000 pulse / kWh Calibration Output Voltage 120V, 240V Basic Current Maximum current 100A... - Page 16 User manual for G3 input and cascade connection hole) AWG 4/0 is available Maximum cable size in cabinet (output 20mm holes) AWG 4/0 is available Maximum cable size in cabinet (Antenna 15mm holes) AWG 4/0 is available Quantity of meters 12 / 18pcs Rated current for cabinet ≤400A(200A for single)
-
Page 17: Availability Introduction
User manual for G3 Availability introduction Picture 4.1.1 G3 availability introduction ⚫ The G3 new series of cluster metering product can be applied and centralized measurement solution, AMI collection solution, line loss analysis solution, installed on the load side of the distribution transformer, as data acquisition, power detection, remote relay control functional device;... - Page 18 User manual for G3 solution even in large data quantity scenario. ⚫ The G3 series centralized metering product supports pole installation, wall installation and indoor installation based on its’ highly-compatible installation design. High protection degree reaches to IP54 outdoor to keep working in hard environment.
-
Page 19: Main Circuit Breaker
User manual for G3 Main circuit breaker brief construction of main circuit breaker G3 meter cabinet provides three kinds of current level of main circuit breaker. 100A and 200A. 100A circuit breaker 200A circuit breaker Nameplate construction of main circuit breaker Mounting holes Test button Standard... -
Page 20: Specification Of Main Circuit Breaker
User manual for G3 Specification of main circuit breaker Main circuit breaker 100A 200A Frame Current CDMK-125 CDMK-250 Rated voltage Ue(V) 400/415 400/415 Rated insulation voltage Ui(V) Rated impulse withstand voltage Uimp(KV) 10/16/20/25/32/40/50/63/8 Rated current In(A) 100/125/140/160/180/200/225/250 0/100/125 Number of poles 50/60HZ AC 400/415V 50/60HZ AC 400/415V Ics / Icu... - Page 21 User manual for G3 Once the meter cabinet is configured with main circuit breaker, the power input cable shall be crimped with an OT terminal to connect with the breaker. The OT terminal type shall depends on the cable dimension. Here we use the 70mm2 cable and OT terminal as OT70-10.
- Page 22 User manual for G3...
-
Page 23: Lcd Display
User manual for G3 LCD display New G3 meter cabinet equips CIU EV500 and EV800 as remote display. CIU EV500 LCD with full segments Below is LCD with full-segment display on CIU. Features Description Number of digits 6-digits integer plus 2-digits decimal The size of digits 10mm x 5mm Operating temperature... - Page 24 User manual for G3 Display segments Display Item Description “6＋2”format to display credit/energy OBIS code Unit display space Energy unit Communication Phase indicator Forward energy Reverse energy Low voltage Relay connected Relay disconnected Token acceptance Token rejection Status indication Over load...
- Page 25 User manual for G3 Display mode ⚫ Automatic scroll display The default display mode of CIU is automatic scroll. After running for a while (certain cycle period), it turns to the next display. The display information including: Total energy consumption, Balance credit, Date, Time. ⚫...
- Page 26 User manual for G3 Backlight Both key button and LCD screen are equipped with white backlight, Press the keypad and the backlight will turn on for 60 sec. Short code Short code description Short Function Short Function code code Total energy consumption Credit balance Current date Current time...
-
Page 27: Ciu Ev800
User manual for G3 4th Last recharge mount 5th Last recharge mount Activate meter cover open Power limit level detection Phase voltage Key version number Current Power CIU EV800 Physical features ⚫ Big LCD with wide viewing angle ⚫ The size of digits is 8.5mm x 4.5mm; ⚫... - Page 28 User manual for G3 OBIS code Unit display space Energy unit Communication Phase indicator Forward energy Reverse energy Low battery voltage Relay connected Relay disconnected Token acceptance Token rejection Status indication （S1~S8） Balance credit indication Display Mode: There are three types of display modes as follows, ⚫...
- Page 29 User manual for G3 Time, Meter No. SGC No. Meter Software Version No. Last 5 accepted credit tokens, etc. The automatic scroll contents are configurable. ⚫ Keypad display ⚫ Because the CIU has no Keypad, customer key in code through the IR remote controller.
- Page 30 User manual for G3 IR Remote controller The communication between IR Remote controller and CIU is infrared. The IR Remote controller has a keypad, once customer stroke the button on the keypad, the infrared signal will transfer to the CIU. The CIU will respond if the customer key in a complete order.
- Page 31 User manual for G3 Active energy consumed in 3 last Active energy consumed in 4 month last month. Active energy consumed in 5 last Active energy consumed in 6 month. last month. Last recharge token with date and Last recharge token with date time and time Last recharge token with date...
-
Page 32: Payment Management
User manual for G3 Payment Management Support for prepaid and postpaid switching, the following features are supported in prepaid mode: ⚫ Measurement deduction ⚫ STS function ⚫ Short code query ⚫ Emergency overdraft ⚫ Friendly mode ⚫ Anti-hoarding function When the following events occur on the meter, the relay will automatically disconnect: insufficient balance, STS mode, overload, CIU and meter `pairing. -
Page 33: Recharge
User manual for G3 Recharge Consumers go to the existing vending point and buy electricity; the consumers will be issued a standard 20-digit token. The electricity consumers type in the 20-dight token using the keypad and presses enter. When the user has keyed in an incorrect digit, he/she could correct it by using the backspace key. -
Page 34: Management Token
User manual for G3 Management token Any of the following Management tokens may be submitted: ⚫ Setting the maximum power. ⚫ Clearing the credit balance. ⚫ Changing the meter key. In terms of the STS standard the meter requires 2 token codes to change the key. -
Page 35: Measurement
User manual for G3 Measurement Meter connection ⚫ Single-phase two-wire meter is wired with L1 and N. ⚫ The single-phase three-wire meter is divided into two types. The zero-line enters and doesn’t enter to the meter. The wiring point in previous type is the L1+L2+N connection mode, and the wiring point in behind type is L1+L2 connection mode. - Page 36 User manual for G3 Prepay information（balance, balance status, total charging amount, relay status, relay mode, relay operating reason, ） Monthly frozen content and capacity Data Storage capacity Total import active energy +A Total export active energy -A Single meter’s Payment mode(prepayment or post payment) monthly data for 12 months Prepay information（balance, balance status, total...
-
Page 37: Communication
User manual for G3 Communication Photoelectric to RS-485 RS485 Wi-SUN DC power module DLMS DLMS DLMS Optional DLMS GPRS/3G/4G HX645 WIFI DLMS Picture 8.1 G3 cabinet working principle The product communicates with the main station through the 3G/4G or Wi-SUN module on the DC (data collector) of the cabinet. -
Page 38: Local Communication
User manual for G3 Local Communication HHU is used to meter reading and device maintenance. It supports to use HHU to set parameters and read energy data on the site. Besides, the HHU has secure measures like the access permission and password management to avoid the non-authorized operation. - Page 39 User manual for G3 ⚫ 485A2-485B2: RS485 for meter reading. It is capable to connect a total meter Power module Door open Meter reading Maintenance There are three terminals in power module:...
- Page 40 User manual for G3 ⚫ Door open: Connect with door open sensor. ⚫ Meter reading: reserved for meter reading. ⚫ Maintenance: Used to log printing.
-
Page 41: Led Indication
User manual for G3 LED Indication Meter LED indication ① 1000imp/kWh pulse LED: When LED blinks, it means there is active energy consumption. ② Reserved for extending ③ PWR/ : Current status of the relay, connection indicates led light, disconnection indicates led flash. ④... -
Page 42: Data Collector Led Indication
User manual for G3 Data Collector LED indication a) Data collector LED: ① Run: Blinking red indicates normal running status ⚫ ② RS485: Blinking red indicates data receiving ⚫ Blinking green indicates data sending ⚫ ③ GPS: Red light on indicates didn’t received GPS info ⚫... -
Page 43: Ciu Led Indication
User manual for G3 CIU LED indication d) Credit status LED (1) The LED supports three levels of visual LED alarm and to indicate the incoming of supply. ⚫ Normal credit balance: LED in green ⚫ Credit Balance less than alarm value level 1: LED in red ⚫... -
Page 44: Event Record
User manual for G3 Event record The collector can save the latest 250 event records. Each kind of event can be configured to report to master station when detected. Index Data Source Data initialization and version modification collector record Parameter modification record collector Meter relay event meter... -
Page 45: Parameter Setting And Query
User manual for G3 Parameter setting and query Supports following parameter settings and query commands form master station remotely or HHU locally: ⚫ Collector archive, such as meter No.; ⚫ Collector Communication parameter, such as IP address and port of master station;... -
Page 46: Overall Dimensions
User manual for G3 Overall dimensions Dimension of all devices 12 spots standard Cabinet:... - Page 47 User manual for G3 12 spots cabinet with breaker...
- Page 48 User manual for G3 18 spots cabinet without breaker...
- Page 49 User manual for G3 Data collector: Communication module in data collector...
- Page 50 User manual for G3 Meter: 1 phase 2 wire 1 phase 3 wire...
- Page 51 User manual for G3 CIU EV500: CIU EV800...
-
Page 52: Installation
User manual for G3 Installation: Installation accessories: ⚫ Hoop bracket It is used in the case of pole installation. The bracket fits no matter cylindric pole or cuboid pole. And the bracket is made of power coated galvanized steel. ⚫ Cross arm... - Page 53 User manual for G3 ⚫ Long bolt...
- Page 54 User manual for G3 ⚫ Hanger bracket (two brackets in one meter cabinet) For pole has 232mm distance of preset two installation holes...
-
Page 55: Installation
User manual for G3 For pole has 300mm distance of preset two installation holes Installation Attention before installation ⚫ Make sure all the accessories are complete before installation. ⚫ The meter cabinet should be installed vertically; the inclination angle should no more than 5°. ⚫... - Page 56 User manual for G3 holes with 232mm or 300mm distance between each other. Meanwhile, bolts and nuts used to connect cabinet and pole are prepared by customer. In this situation our hanger bracket can perfectly match the pole. ⚫ Installation Tool: 6" monkey spanner or electric drill with hexagon head ⚫...
- Page 57 User manual for G3 b) Then, raise the cabinet up with the bolts. Insert the bolts into the holes.
- Page 58 User manual for G3 c) Fasten the screw nut with gaskets in the end side. d) Finished. Pole without preset holes Once the pole on site doesn’t have preset installation hole, here we have a special hoop bracket. The hoop bracket can fit different types of the pole no matter the cuboid pole or cylinder pole.
- Page 59 User manual for G3 ⚫ Installation Tool: 6" monkey spanner, percussion drill ⚫ Accessories: Special hoop bracket...
- Page 60 User manual for G3 ⚫ Step: a) Install the u-bar on the hanger bracket on cabinet. The nuts(M10) should be fastened tightly with bolts(M10*35) to connect U-bar and hanger bracket; b) Mark the installation spot on the pole. Rise the cabinet up and close to the marked spot;...
- Page 61 User manual for G3 c) Lock the nuts (M12) and four long bolts which near to the cabinet. Make sure four long bolts across the hole of the U bar;...
- Page 62 User manual for G3 d) Put another two u-bars and Lock the last four nuts(M12); e) Finished.
- Page 63 User manual for G3...
-
Page 64: Wall Installation
User manual for G3 Wall installation ⚫ Installation Tools: percussion drill with drill head (direct 10mm) , 6" monkey wrench, pencil. ⚫ Installation Accessories: 2pcs expansion bolts (M10*100), hanger bracket ⚫ Step / Method a) According to the bracket distance in below picture, mark hole positions and distance on the wall. - Page 65 User manual for G3 b) Select an alloy drill with same diameter of the expansion screw tight circle (inflation tube). Note that we have two types of hanger bracket. The distance marked in above picture is 300mm. Another one is 232mm.
- Page 66 User manual for G3 d) The washers and bolts are outside of the wall, use wrench to tighten them with nut (as the figure shown below). Hang the meter cabinet.
- Page 67 User manual for G3 Insert the expansion bolt tube into hole but don't remove the nut, because sometime the hole is too deep and if bolt fall in, it will be hard to take it out. Fasten the screws. Finished. ⚫...
- Page 68 User manual for G3 don't install it on soft place or it may fall down, such as of mortar joint of the wall. Insert the expansion bolt tube into hole but don't ⚫ remove the nut, because sometime the hole is too deep and if bolt fall in, it will be hard to take it out.
-
Page 69: Wiring Instructions
User manual for G3 Wiring Instructions Wiring tools Cross screwdriver Hexagon Wrench Wiring diagram... - Page 70 User manual for G3...
-
Page 71: Transportation And Storage
User manual for G3 Transportation and Storage During the transportation and packing process, the products shall not be dramatically shocked, and shall be transported and stored according to the regulations. Inventory and storage should be made in a shelf with original package.
