User manual for single-phase meter
User Manual
Single Phase Electronic Meter
HXE12-DL
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HXE12-DL and is the answer not in the manual?

Questions and answers

Carel Basson
April 16, 2025

Will it be possible to push power back into the grid with a Hexing HEX12-DL meter. My old meter was replaced with the HEX12-DL, 4 weeks ago, and it was possible for me to push power back into the grid with the old meter.

Summary of Contents for HEXING HXE12-DL

  • Page 1 User manual for single-phase meter User Manual Single Phase Electronic Meter HXE12-DL...
  • Page 2 User manual for single-phase meter Revision history Index Date Name Remarks...
  • Page 3 Copyright © 2013 Hexing Electrical Co., Ltd. All rights reserved. No part of this publication may be reproduced, transmitted, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Hexing Electrical Co., Ltd.
  • Page 4: Table Of Contents

    User manual for single-phase meter Content ................................1 1 Overview ............................1 2 Appearance ............................. 2 3 Standard ............................2 4 Working Principle .......................... 4 5 Measurement ..........................5 5.1 Active energy Measurement ................... 5 5.2 Instantaneous Measurement ..................5 6 LCD display ...........................
  • Page 5 User manual for single-phase meter 13.1 Clean ..........................20 13.2 Error and function check ..................... 20 13.3 Reinstall ........................21 14 Scarp Processing ........................21 15 Transportation and Storage ......................21 16 Parameters ..........................23 Annex A Display OBIS ........................25...
  • Page 6: Overview

    User manual for single-phase meter 1 Overview This manual is for single phase energy meter with active energy measurement. HXE12-DL electronic meter is developed and manufactured by Hexing. It features in high accuracy, low power consumption and reliable stability and superior anti-tampering functions.
  • Page 7: Appearance

    User manual for single-phase meter 2 Appearance Description LCD display Pulse LED(active energy) Nameplate Meter Cover Meter Cover Seal Active Pulse output Terminal block Terminal cover Seal Display button Alarm LED Optical port 3 Standard Standard Description Electricity metering equipment (a.c.) IEC 62052-11 –...
  • Page 8 User manual for single-phase meter Electricity metering equipment (AC) IEC 62053-23 - Particular requirements - Part 23: Static meters for reactive energy (classes 2 and 3) Electricity metering (a.c.) IEC 62054-21 – Tariff and load control – Part 21: Particular requirements for time switches Electricity metering IEC 62056-21 - Data exchange for meter reading, tariff and load control...
  • Page 9: Working Principle

    User manual for single-phase meter 4 Working Principle Back light MicroControler LCD Display Data process Measuring System Optical Interface Calibration Time of use RS-485 Interface or Active Pulse output Signal processing Non-volatile Memory Event record Power Supply Backup Supply Button...
  • Page 10: Measurement

    User manual for single-phase meter 5 Measurement 5.1 Active energy Measurement  Total Active energy(|+A|+|-A|)  Import Active energy(|+A|)  Export Active energy(|-A|)  Measurement range is 00000000-99999999 kWh 5.2 Instantaneous Measurement  Voltage  Current  Active power  Power factor ...
  • Page 11 User manual for single-phase meter • LCD operation temperature range is -30 ℃ ~+80 ℃ • LCD shall be high contrast ratio • LCD shall be wide viewing angle • LCD polarizer shall be anti-ultraviolet function...
  • Page 12: Display Segments

    User manual for single-phase meter 6.2 Display segments Segments Description Digit display OBIS code and Current tariff Value Unit Communication indicator Alarm indicator, The alarm can be configured as historical or real-time. The alarm event as below: Reverse Terminal cover open Meter cover open Historical alarm: The alarm always be on, and turn off after the event is...
  • Page 13: Display Mode

    User manual for single-phase meter Current direction indicator |-> Forward |<- Reverse No current(No load indicator) Low battery indicator 6.3 Display mode This meter is designed with three display modes:  Auto mode display Meter default display mode is auto-scrolling display, after meter runs for a certain time (for auto-scrolling display circle, default as 6 seconds), it will switch to the next screen display automatically.
  • Page 14: Led Indication

    User manual for single-phase meter Inner clock diagram  Supports calendar, time and leap year automatic switch function.  The meter is equipped with a clock module, which calculates the time by a 32768Hz crystal oscillator.  If utility request higher precision of clock, the crystal oscillator will be calibrated in factory and the accuracy can be less than 0.5s/day at 23℃.
  • Page 15: Alarm Led Indication

    User manual for single-phase meter LED support configurable into always on or off, default is always off. 8.2 Alarm LED indication When tamper events occur, alarm LED will light on all the time. When tamper events cleared, alarm LED will light off. The alarm event can be configured as below: Reverse, Terminal cover open, Meter cover open.
  • Page 16: Overall Dimensions And Installation

    User manual for single-phase meter Optical port Communication standards: IEC62056-21C 300bps for standby, 4800 bps for communication(2400~9600bps configurable) 10 Overall dimensions and installation 10.1 Meter Connection Please follow the instruction to arrange the wire connection: a) Use copper cable as the lead-in wire to terminal block. b) Screw out the wire-fasten screw so that the connection wires can be inserted into.
  • Page 17: Meter Dimension

    User manual for single-phase meter 1P2W LNNL  Auxiliary terminal wiring diagram 5-6 : Active Pulse output  10.2 Meter Dimension Long terminal cover  Terminal drawing...
  • Page 18: Installation Dimension

    User manual for single-phase meter 10.3 Installation Dimension 11 Installation and un-installation 11.1 Installation tools Cross screwdriver Electric drill...
  • Page 19: Preparation Before Installation

    User manual for single-phase meter Wire stripper Lead sealing pliers Hairsprings Screw 11.2 Preparation before installation  The meter should be installed in ventilated and dry place to ensure the meter’s safety and reliability. In the dirty or risky area, the meter should be installed in a protection box.
  • Page 20: Installation Procedure

    User manual for single-phase meter components, the meter should be carefully protected during the installation in order to avoid any damage. Make sure that the power is cut off before the meter installation, otherwise it will cause a threat to life. The fuse should be disconnected and put it in a safe place to avoid the accidental power-on.
  • Page 21 User manual for single-phase meter of products. We insist on the recommended length of the stripped wire to ensure that the bare metal part is long enough and can be fixed by two connection screws at the same time. However the bare part should not exceed the terminal box wiring holes, ensure the safety and insulation effect.
  • Page 22: Testing After Installation

    User manual for single-phase meter To ensure the correct wiring, it is recommended to use the appropriate testing tools (such as multi-meters) for input/output test. 9. Close the terminal cover, and sealed it. 11.4 Testing after installation Power on the meter, the LCD display properly. 11.5 Un-installation 1.
  • Page 23 User manual for single-phase meter If a new meter cannot be installed for the moment, please envelop the voltage and current connection cables in insulating material and avoid exposing any bare metal part, otherwise it will pose a threat to life.
  • Page 24: Service

    (METER model can be obtained from the METER nameplate) 3. Package the METER, ensure the METER will not be damaged during the transport. Try to use the original package. Don’t put in a METER with missing part 4. Send the electric METER to a certified Hexing service center...
  • Page 25: Maintenance

    User manual for single-phase meter 13 Maintenance There is no need to verify the METER within the life cycle. METER maintenance can be executed based on local regulations. Recommended every 5~10 years. 13.1 Clean Use dry cloth to clean the surface of the METER and wipe the stains and insects. Warning: Flowing water and high pressure water equipment is not allowed to clean the METER, which may lead to short circuit.
  • Page 26: Reinstall

    User manual for single-phase meter 13.3 Reinstall In order to avoid the change of asset management, it’s recommended to reinstall the METER at the former position. The installation process detailed in chapter 16 "Installation and un-installation". 14 Scarp Processing This chapter describes the right method of meter scarp processing. Compliant ISO 14001 environmental certification specification, the components of the meter is maximum extent separable, thus to provide corresponding abandoned and recycling station after disassembled.
  • Page 27 User manual for single-phase meter there are no harmful substances in the air that might cause corrosion.
  • Page 28: Parameters

    User manual for single-phase meter 16 Parameters Electrical Voltage 230V Basic current Maximum current 100A Starting current ≤0.4%Ib(Active) Frequency 50Hz Burden in current circuit <1VA Burden in voltage circuit <2W/10VA Meter life 10 years Impulse constant 1000imp/kWh External influence Protection IP54(Indoor) Operating temperature -40℃~70℃...
  • Page 29 User manual for single-phase meter Dimension(H x W x D) 155mmx132mmx50mm(with long terminal cover) Mounting Front projection mounting Sealing Sealing provisions for terminal with sealing screw Terminal hole diameter 10mm x 9mm (DC) Terminal cover Long terminal cover or Meter Cover material Recycled Opaque PC+ glass fiber with a transparent window Meter Base material Recycled Opaque PC+ glass fiber...
  • Page 30: Annex A Display Obis

    User manual for single-phase meter Annex A Display OBIS Items OBIS Voltage A C400 32.7.0 Current A C410 31.7.0 Total active power C420 1.7.0 Active power A C421 21.7.0 Total reactive power C430 3.7.0 Reactive power A C431 23.7.0 Total power factor C450 13.7.0 Power factor A...
  • Page 31 User manual for single-phase meter Hexing Electrical Co., Ltd. www.hxgroup.com Add: shangchen Industrial Zone; 1418 Moganshan Road, Hangzhou, China...
