Figure 17. Lift the battery at an angle less than 30 degrees
6. Slide and lift the battery off the palm-rest and keyboard assembly.
Installing the battery
CAUTION:
The information in this installation section is intended for authorized service technicians only.
Prerequisites
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The following images indicate the location of the battery and provide a visual representation of the installation procedure.
40
Removing and installing Field Replaceable Units (FRUs)
