User Manual
Release 1.4
PAT-Clamp-1
Docking station for a single PAT series test cell
© 2024 EL-Cell GmbH

Advertisement

loading
Need help?

Need help?

Do you have a question about the PAT-Clamp-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for EL-CELL PAT-Clamp-1

  • Page 1 User Manual Release 1.4 PAT-Clamp-1 Docking station for a single PAT series test cell © 2024 EL-Cell GmbH...
  • Page 2 PAT-Clamp-1 Disclaimer EL-Cell GmbH makes no assurances or warranties with respect to this manual and, to the extent permitted by law, limits its liability for violation of any implied warranty to the substitution of this manual for another. In addition, EL-Cell GmbH reserves the right to revise this publication at any time without notice to anyone.
  • Page 3 User Manual PAT-Clamp-1 Manufacturer and Customer Service EL-Cell GmbH Tempowerkring 8 21079 Hamburg – Germany Telephone: +49 40 79012-734 Telefax: +49 40 79012-736 Email: info@el-cell.com Website: el-cell.com Technical Support Telephone: +49 40 79012-734 Email: support@el-cell.com Website: el-cell.com/support/technical-support/ Please always quote the serial number on the nameplate when contacting customer service.
  • Page 4: Table Of Contents

    User Manual PAT-Clamp-1 Content 1 Product Description ............................5 2 Technical Data ..............................6 4 Installation ............................... 7 5 Cleaning ................................8 6 Operation Modes............................9 7 Cable Colors and Naming Conventions ....................10 8 Unpacking..............................11 10 Warranty ..............................11 Page 4 of 11 Release 1.4...
  • Page 5: Product Description

    PAT-Clamp-1 1 Product Description The PAT-Clamp-1 is a docking station for a single PAT series test cell. When docked into the PAT-Clamp-1, the test cell may be tested by any potentiostat or battery tester. Other manuals cover the compatible test cells and the PAT-Core concept in detail: (https://el- cell.com/support/manuals).
  • Page 6: Technical Data

    2 Technical Data Operating temperature: -20 to +70°C ▪ Humidity: non-condensing ▪ Dimensions PAT-Clamp-1 H: 86 mm (width) x 62 mm (depth) x 27/83 mm (height without/ ▪ with PAT-Cell) Weight: 0.12 kg (without/with PAT-Cell) ▪ Protection Class: IP20 according to EN 60529 ▪...
  • Page 7: Installation

    PAT-Clamp-1 4 Installation Place the PAT-Clamp-1 on a flat, dry, and clean surface. This surface can be a benchtop, inside a temperature chamber, or in a glove box. Then, connect the cell cable of your potentiostat or battery tester channel to either the banana sockets at the front of the PAT-Clamp-1 or the Sub-D connector on the opposite side.
  • Page 8: Cleaning

    User Manual PAT-Clamp-1 5 Cleaning Wipe the PAT-Clamp-1 with a moist tissue. Do not use aggressive chemicals for cleaning. Protect the PAT-Clamp-1 from dust and moisture. Page 8 of 11 Release 1.4...
  • Page 9: Operation Modes

    6 Operation Modes Connect the cell cable of your potentiostat or battery tester channel to the banana sockets at the front of the PAT-Clamp-1. The table below lists the different operation modes. Operation mode 1: Cell voltage control (1 vs 2)
  • Page 10: Cable Colors And Naming Conventions

    User Manual PAT-Clamp-1 7 Cable Colors and Naming Conventions The potentiostat's cell cable leads' naming convention and color codes are not standardized between manufacturers. The table below is an incomplete list of some popular instruments. Important note: The application of our test cells is not limited to the potentiostats listed below.
  • Page 11: Unpacking

    ▪ 10 Warranty For a period of one year from the date of shipment, EL-Cell GmbH (hereinafter Seller) warrants the goods to be free from defects in material and workmanship to the original purchaser. During the warranty period, Seller agrees to repair or replace defective and/or nonconforming goods or parts without charge for material or labor or, at the Seller’s option, demand return of...
