User Manual PAT-Stand-1 Manufacturer and customer service EL-Cell GmbH Tempowerkring 8 21079 Hamburg – Germany Telephone: +49 40 79012-734 Telefax: +49 40 79012-736 Email: info@el-cell.com Website: el-cell.com Technical support Telephone: +49 40 79012-734 Email: support@el-cell.com Website: el-cell.com/support/technical-support/ Please always quote the serial number on the nameplate when making customer service inquiries.
User Manual PAT-Stand-1 Preamble 1.1 Purpose and target audience This manual covers the structure, function, operation and maintenance of the device described. It is intended for the end users of the device. An end user can be described as any person who interacts directly with the device.
User Manual PAT-Stand-1 1.3 Obtaining documents and information A current version of the documentation is available on the following website : https://el-cell.com/support/manuals/ Alternatively, you can scan this QR code, to access the website: Page 6 of 14 Release 1.6...
PAT-Stand-1 Product description The PAT-Stand-1 is a docking station for a single PAT series test cell. When docked into the PAT-Stand-1, the test cell may be tested by any potentiostat or battery tester. The compatible test cells are covered in detail by other manuals: (https://el-cell.com/support/manuals).
(instead of connecting to the banana sockets at the front). Sub-D Connector „Aux“: Used for incoming external signal sources, like dilatometry signal data. 4 mm banana sockets : Used for transmitting cell signals from the PAT-Stand-1 to a potentiostat. Adapters for connection of 2 mm banana plugs are included.
Signal Installation Place the PAT-Stand-1 on a flat, dry, clean surface. This can be, for example, on a bench top, inside a temperature chamber or glove box. Then connect the cell cable of your potentiostat or battery tester channel to the banana sockets or Sub-D connector of the PAT-Stand-1.
Operation modes Connect the cell cable of your potentiostat or battery tester channel to the banana sockets at the front of the PAT-Stand-1. For the different operation modes, see the table below. Operation mode 1: Cell voltage control (1 vs 2)
User Manual PAT-Stand-1 Cable colors and naming conventions The naming convention and color codes of the potentiostat´s cell cable leads are not standardized between manufacturers. The table below is an incomplete list of some popular instruments. Important note: The application of our test cells is not limited to the potentiostats listed below.
Check the contents of the packages against the list given below to verify that you have received all of the required components. Contact EL-CELL if anything is missing or damaged. NOTE: Damaged shipments must remain within the original packaging for freight company inspection.
User Manual PAT-Stand-1 Storage and disposal 10.1 Storage The device may only be stored under the following conditions: dry and in a closed, dust-free room • frost-free • 10.2 Disposal The device must not be disposed of in normal household waste. Observe the applicable legal regulations.
User Manual PAT-Stand-1 Warranty For a period of one year from the date of shipment, EL -Cell GmbH (hereinafter Seller) warrants the goods to be free from defects in material and workmanship to the original purchaser. During the warranty period, Seller agrees to repair or replace defective and/or nonconforming goods or parts without charge for material or labor or, at the Seller’s option, demand return of...
