Mounting
1. Disconnect the power supply.
2. Slide the mounting bracket off the meter body.
3. Fit the meter in the mounting hole, attach the fixing plate and
tighten the nut.
4. Connect the voltage, which is the operating signal of the con-
trolled device, to the terminals of the counting input.
Wiring diagram
- 2 -
