BOXLIGHT frontrow UNITY Quick Start Manual

Quick Start Guide
How to identify your UNITY
UNITY is available in a Classroom and Campus version. UNITY is designed for classroom audio and voice. UNITY Campus adds support for
bells, paging, intercom, and alerts.
Note: Each version is available in a horizontal or vertical orientation.
UNITY Classroom
UNITY Faceplate Common Buttons
Volume/Mute
Dual function volume control, right to increase volume, left to
decrease volume.
Press the knob to mute all audio.
Un-mute by pressing the knob or rotating to the left or right.
Faceplate Locking Feature
Optional feature activated via the UNITY web interface.
When the lock icon is illuminated, the Volume/Mute control,
Microphone, Bluetooth, Diamond and Circle buttons are locked.
The Intercom and Alert buttons do not lock.
Microphone Pairing
Button initiates paring between the UNITY and the Action! and
Bravo! microphones.
Bluetooth Pairing
Button press initiates paring between the UNITY and a Bluetooth
audio device.
Lock
Volume (Turn knob)
Mute (Push button)
Bluetooth Pairing
Microphone
Pairing
UNITY Campus
Classroom and Conductor
specific options
UNITY Classroom
These actions are usually customized by your school. See the
MyFrontRow app or check with your IT administrator for details.
Diamond Button
Button press initiates the same action as the Diamand button on
the Action microphone.
Circle Button
Button press initiates the same action as the Circle button on the
Action microphone.
Diamond Button
UNITY Campus
Intercom Call Button
Button press initiates an intercom call to the school office.
Communication with the office will be "hands-free".
Alert Button
Button press (& HOLD) initiates a school Alert.
This Alert is unique to your school.
Intercom Call Button
1
Circle Button
HOLD
2
SECONDS
Alert Button
