BOXLIGHT MimioFrame
Setup SOP
2022, 08, 17

Advertisement

loading
Need help?

Need help?

Do you have a question about the MimioFrame and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BOXLIGHT MimioFrame

Summary of Contents for BOXLIGHT MimioFrame

  • Page 1 BOXLIGHT MimioFrame Setup SOP 2022, 08, 17...

  • Page 2: Table Of Contents

    Table of contents Parts List Accessories List Parts Description Assembly Teaching Assembly Teaching Calibration Troubleshooting...

  • Page 3: Parts List

    Parts List Parts Description Parts Description Connection Element Frame edge ( AD segment ) Frame edge Connection Element ( CB segment ) (Outlet) Fixing Screw Frame edge ( BA segment ) Frame edge USB control cable ( DC segment )

  • Page 4: Accessories List

    Accessories List Parts USB2.0 Cable Double-sided Description Dummy Pen Spare Cable Download card 3M x 1 Tapes Photos...

  • Page 5: Parts Description

    Parts Description - AD segment The PCB board in the edge can be The PCB board in the edge can be pulled out and pushed in pulled out and pushed in Side Edge Front Edge Parts Description USB control cable socket PCB connection cable PCB connection cable socket Insulation protective tape...
  • Page 6 Parts Description - BA segment The PCB board in the edge can be The PCB board in the edge can be pulled out and pushed in pulled out and pushed in Side Edge Front Edge Parts Description PCB connection cable socket Insulation protective tape PCB connection cable socket...
  • Page 7 Parts Description - CB segment Side Edge Front Edge Parts Description PCB connection cable...
  • Page 8 Parts Description - DC segment Side Edge Front Edge Parts Description PCB connection cable...

  • Page 9: Assembly Teaching

    Assembly Teaching Sequence 1 Sequence 2 Sequence 3 Connect the D end of the side Connect the B end of the side Connect the B end of the strip to the PCB on both sides strip to the PCB on both sides side strip to the PCB on both with a cable with a cable...
  • Page 10 Assembly Teaching Lock the connection element and fixing screws into the connecting edge according to the picture.
  • Page 11 Assembly Teaching Schematic diagram of Mimio Frame assembly completed...
  • Page 12 Assembly Teaching Connect the Mimio Frame to the NB (computer) and perform Signal Testing to confirm that the assembly is error-free...
  • Page 13 Start up MimioFrame Calibration Tool 1. The current tool version is V5.23. 2. After MimioFrame is assembled, connect the touch frame USB cable to the computer. 3. Execute the IndraRed Touch file without installation on the computer...
  • Page 14 Signal Testing Before installing to the board, perform Signal Testing first to confirm whether the touch frame wiring is normal...
  • Page 15 Signal Testing There is no error message in the Signal Testing (green tick icon), indicating that the detection wiring is normal.
  • Page 16 Assembly Teaching Attach the Mimio Frame to the whiteboard with double-sided tape...

  • Page 17: Calibration

    Calibration Connect Mimio Frame and NB with USB control cable and execute 9-point calibration...
  • Page 18 Start up MimioFrame Calibration Tool 1. The current tool version is V5.23. 2. After MimioFrame is assembled, connect the touch frame USB cable to the computer. 3. Execute the IndraRed Touch file without installation on the computer...
  • Page 19 9-Point Calibrate 1. After installing MimioFrame on the board, connect the touch frame USB to the computer, 2. Perform 9-point calibrate for touch positioning...
  • Page 20 9-Point Calibrate 1. Enter the 9-point calibrate function page, and click the 9 positioning points in sequence. 2. After the 9-point calibrate is completed, it can be used normally.

  • Page 21: Troubleshooting

    Troubleshooting When the finger does not touch the board, the signal test infrared scan shows an error message Error message 1 Error Message...
  • Page 22 Possible reasons : 1. The frame is falling off or not sticking to the flat white board. 2. The infrared edge of the frame is blocked by foreign object. Objects Solution : Fix the edge strip close to the white board, and remove the infrared blocking edge strip.
  • Page 23 Troubleshooting When the finger does not touch the board, the signal test infrared scan shows an error message Error message 2 Error Message Error Message...
  • Page 24 Possible reasons : 1. The frame is falling off or not sticking to the flat white board. 2. Frame connection PCB board cable is not connected or loose. Objects Solution : Fix the edge strip close to the white board, if the problem is still not eliminated, you need to try to reconnect the PCB board cable.
  • Page 25 Troubleshooting The computer cannot read the Mimio Frame device...
  • Page 26 Possible causes and elimination methods : 1. The USB cable is not connected to the computer or the USB cable is connected too long, causing signal attenuation. (USB connection length exceeds 5M, a signal extender needs to be installed) 2. Check whether the computer has anti-virus software or firewall and other monitoring software installed to block the external usb device...
