Summary of Contents for Spa Electrics atom EMP
- Page 1 POND LIGHT INSTALLATION & OWNER’S MANUAL...
-
Page 2: Table Of Contents
CONTENTS READ THIS FIRST TOOLS REQUIRED PRODUCT SUPPORT AND INFORMATION INCLUDED PARTS FLOOR BRACKET ASSEMBLY INSTALLATION - MOUNT BRACKET INSTALLATION - LIGHT ASSEMBLY LIGHT REMOVAL CONNECTIONS TROUBLESHOOTING NOTICE NOT INTENDED FOR OPERATION OUT OF WATER... -
Page 3: Read This First
• Temperature range for installation, operation and servicing: +5°C ~ +40°C (+41°F ~ +104°F) IMPORTANT NOTE It is recommended that the ATOM lighting range is operated using a Spa Electrics LV25-12 or LV50- 12 transformer. • DO NOT use electronic or switch-mode power supplies with ATOM lights. These power supplies will damage the light and void your product warranty. -
Page 4: Tools Required
AQUATIC LIFE The EMP Series Pond Lights produce very bright colours at specific wavelengths, specialist advice should be sort before use with aquatic life. Wavelengths used: BLUE: 465nm GREEN: 560nm RED: 620nm WHITE 4000K: 580nm (dominant) Based on in-house testing it has been noted that the EMP Series pond light produces a 1ºC temperature rise in 45l of water @ 25ºC. -
Page 5: Included Parts
INCLUDED PARTS POND MOUNTING BRACKET ASSEMBLY MOUNTING PLATE WALL BRACKET LIGHT ASSEMBLY 4 X MOUNTING 4 X SCREW 2 X THUMB 2 X HARD 2 X RUBBER SCREWS ANCHORS WHEELS WASHERS WASHERS PLUG & CABLE SOLD SEPERATELY FLOOR BRACKET (P/N: POND BASE FOOT) LV25-12 / LV50-12 DUAL TRANSFORMERS... -
Page 6: Floor Bracket Assembly
FLOOR BRACKET ASSEMBLY PLACE RUBBER WASHER OVER THREAD INSERT MOUNTING PLATE INTO BASE NOTE GENTLY PRY BASE ARMS APART TO FIT MOUNTING PLATE PLACE HARD WASHER OVER THREAD & TIGHTEN THUMB-WHEEL... -
Page 7: Installation - Mount Bracket
INSTALLATION - MOUNT BRACKET WALL BRACKET INSTALLATION FASTEN BRACKET TO FLOOR USING APPLY RTV 2 X MOUNTING NOTE SILICON TO SCREWS PROVIDED. SCREW THREAD. TIGHTEN SCREWS BY HAND ONLY DRILL CONCRETE WALL USING 4.5- 5mm MASONRY BIT AND INSERT 2 X SCREW ANCHORS. - Page 8 FLOOR BRACKET INSTALLATION FASTEN BRACKET TO FLOOR USING 4 X APPLY RTV MOUNTING SCREWS SILICON PROVIDED. TO SCREW NOTE THREAD. TIGHTEN SCREWS BY HAND ONLY DRILL CONCRETE WALL USING 4.5-5mm MASONRY BIT AND INSERT 2 X SCREW ANCHORS. FIBREGLASS CONCRETE DRILL FIBREGLASS WALL USING 3mm DRILL BIT.
-
Page 9: Installation - Light Assembly
INSTALLATION - LIGHT ASSEMBLY REMOVE PLUG DUST COVER REMOVE DUST COVER FROM PLUG USING PHILLIPS-HEAD (NO.2) SCREW-DRIVER NOTE ENSURE SEAL IS SEATED FLAT IN PLUG BASE NOTE DO NOT REMOVE RED DUST COVER UNDERWATER... - Page 10 ASSEMBLE PLUG TO LIGHT ALIGN TERMINAL PINS AND FIRMLY ASSEMBLE PLUG TO LIGHT FASTEN PLUG TO LIGHT USING 3 x (M3.5 X 21mm) FASTENERS & NO.2 PHILLIPS-HEAD SCREWDRIVER IMPORTANT NOTES → DO NOT OVERTIGHTEN SCREWS → DO NOT USE POWER-TOOLS →...
- Page 11 ATTACH LIGHT TO BRACKET “CLICK”...
-
Page 12: Light Removal
LIGHT REMOVAL PUSH DOWN BUTTON WITH FLAT BLADE & HOLD ROTATE ANTI-CLOCKWISE & RELEASE FROM LOCKING RING... -
Page 13: Connections
CONNECTIONS HOW TO CONNECT SINGLE LIGHT TO G.P.O. 25VA POOL LIGHT TRANSFORMER HOW TO CONNECT MULTIPLE LIGHTS TO G.P.O. 50VA TRANSFORMER DAISY-CHAIN TRANSFORMERS UP TO 10A (MAX) POOL LIGHT POOL LIGHT... - Page 14 HOW TO CONNECT MULTIPLE LIGHTS TO G.P.O. 100VA TRANSFORMER DAISY-CHAIN TRANSFORMERS UP TO 10A (MAX) POOL LIGHT POOL LIGHT POOL LIGHT POOL LIGHT...
-
Page 15: Troubleshooting
Light colours not Incorrect operating mode Refer to MULTI PLUS setup synchronized selected procedure (pg. 9) If these issues cannot be resolved with the above recommended actions, please contact your local Spa Electrics reseller or Spa Electrics directly. Web: www.spaelectrics.com... - Page 16 NOTE PLEASE STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE © COPYRIGHT 2024 SPA ELECTRICS PTY. LTD. ALL RIGHT RESERVED 2024 12 02...
