Spa Electrics ARGON-P Owner's Manual

Plungie pools
Hide thumbs

Advertisement

Quick Links

Download this manual
PLUNGIE POOLS
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the ARGON-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Spa Electrics ARGON-P

Summary of Contents for Spa Electrics ARGON-P

  • Page 1 PLUNGIE POOLS OWNER’S MANUAL...

  • Page 2: Table Of Contents

    CONTENTS READ THIS FIRST TOOLS REQUIRED PRODUCT SUPPORT AND INFORMATION WARRANTY POLICY INCLUDED PARTS LIGHT REMOVAL LIGHT ASSEMBLY POST INSTALLATION CHECK KEY DIMENSIONS TROUBLESHOOTING ELECTRICAL GROUNDING FCC COMPLIANCE STATEMENT NOTICE FRESH WATER USE ONLY HORIZONTAL MOUNT ONLY NOT INTENDED FOR OPERATION OUT OF WATER FOR SUPPLY CONNECTION, USE ONLY AN ISOLATING LOW VOLTAGE POWER SUPPLY WITH UNGROUNDED OUTPUT, EVALUATED FOR SWIMMING POOL USE...

  • Page 3: Read This First

    Niche to ensure the light can be accessed above the waterline. CLEANING • Only use warm water and a soft brush or cloth to clean ARGON-P lights. DO NOT use detergents or spirits as this can damage the light and void your warranty. USE OF PRODUCT •...

  • Page 4: Important Note

    IMPORTANT NOTE • The ARGON-P Series light must only be powered by a 12V AC iron core type transformer. • DO NOT use electronic or switch-mode transformers with ARGON-P Series lights. These transformers will damage the light and void your product warranty.

  • Page 5: Warranty Policy

    (pool and spa) light (”the product”) is installed ("the owner"). i. New Pool Construction Products- Spa Electrics will, in its option, repair or replace any defective part of the New Pool Construction Products during the first (36) THIRTY SIX month period commencing from the date of installation of the product.

  • Page 6: Included Parts

    INCLUDED PARTS PLUNGIE 80FT NICHE ASSEMBLY (P/N: N3P 18AWG 80 US) LIGHT MOUNTING BRACKET LIGHT ASSEMBLY LIGHT RIM 50MM CAST-IN FITTING LVX50 TRANSFORMER...

  • Page 7: Light Removal

    LIGHT REMOVAL PUSH AND LEVER OFF LIGHT RIM WITH FLAT BLADE INSERT FLAT BLADE SCREWDRIVER INTO NICHE ABOVE TOP 12 O’CLOCK ARROW AND LEVER OFF LIGHT RIM ROTATE AND PULL OUT LIGHT ASSEMBLY ROTATE LIGHT ASSEMBLY COUNTER-CLOCKWISE SO THE ARROW ON THE LIGHT ASSEMBLY IS AT 10 O’CLOCK.
  • Page 8 REMOVE PLUG FROM LIGHT UNSCREW PLUG COLLAR COUNTER-CLOCKWISE UNTIL IT IS FREE SPINNING DISCONNECT THE TERMINALS DISCONNECT LIGHT ASSEMBLY FROM PLUG BY PULLING APART IMPORTANT NOTE CABLE SHOULD BE SECURED ABOVE WATER AND WEATHER PROTECTED WHILE LIGHT IS DETACHED...

  • Page 9: Light Assembly

    LIGHT ASSEMBLY CONNECT THE TERMINALS ALIGN THE TERMINAL PINS ON PLUG AND BACK OF LIGHT ASSEMBLY AND FIRMLY CONNECT TOGETHER IMPORTANT NOTES • DO NOT ADD SEALANTS, GREASES OR ADHESIVES • ENSURE ALL SURFACES ARE CLEAN AND DRY • DO NOT ASSEMBLE UNDERWATER FASTEN PLUG TO LIGHT TO LOCK INTO PLACE: TWIST COLLAR CLOCKWISE...
  • Page 10 TWIST ON THE LIGHT ASSEMBLY 1: PLACE THE LIGHT ASSEMBLY OVER 2: THEN TWIST CLOCKWISE TO 12 THE MOUNTING BRACKET AT 10 0’CLOCK O’CLOCK 3: ENSURE THE 12 O’CLOCK MARKER ON THE MOUNTING BRACKET LINES UP WITH THE 12 O’CLOCK MARKER ON THE LIGHT ASSEMBLY ATTACH LIGHT RIM...

  • Page 11: Post Installation Check

    POST INSTALLATION CHECK TEST SYSTEM TEST THE LIGHTING SYSTEM BY CONNECTING TO A LOW VOLTAGE TRANSFORMER AND POWER ON TO CONFIRM THE LIGHT FUNCTIONS AS EXPECTED TURN ON BREAKER TO LOW VOLTAGE POOL LIGHT TRANSFORMER...

  • Page 12: Key Dimensions

    KEY DIMENSIONS POOL WALL 1.1” 28mm...

  • Page 13: Troubleshooting

    Electrics for repair Light colours not Incorrect operating mode Refer to MULTI PLUS setup synchronized selected procedure If these issues cannot be resolved with the above recommended actions, please contact your local Spa Electrics reseller or Spa Electrics directly. Web: www.spaelectrics.com...

  • Page 14: Electrical Grounding

    Therefore, luminaires with polymeric/non-current carrying metal parts are not required to be grounded / bonded. Manufacturers Statement Spa Electrics ARGON luminaires with their plastic housing designs and plastic niches do not require grounding / bonding. Spa Electrics ARGON lights have also been determined to comply with the applicable requirements for wet-niche, LED type Swimming Pool and Spa Luminaires.
  • Page 15 IMPORTANT NOTE PLEASE STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE The underwater lighting specialists spaelectrics.com © COPYRIGHT 2023 SPA ELECTRICS INC. ALL RIGHT RESERVED US 2023 12 15...
