VINYL POOLS

EMV

ED-ATOM

INSTALLATION & OWNER'S MANUAL

Table of Contents

Need help?

Do you have a question about the ED-ATOM and is the answer not in the manual?

Questions and answers

Summary of Contents for Spa Electrics ED-ATOM

Page 1 VINYL POOLS ED-ATOM INSTALLATION & OWNER’S MANUAL...
Page 2: Table Of Contents
CONTENTS READ THIS FIRST TOOLS REQUIRED PRODUCT SUPPORT AND INFORMATION INCLUDED PARTS FINISHED INSTALLATION INSTALLATION PROCEDURE LIGHT ASSEMBLY LIGHT CONNECTION LIGHT REMOVAL CABLE ADJUSTMENT & REMOVAL TROUBLESHOOTING KEY DIMENSIONS NOTICE HORIZONTAL MOUNT ONLY NOT INTENDED FOR OPERATION OUT OF WATER...
Page 3: Read This First
1.0mm²). See Page 16 for more information). CLEANING • Only use warm water and a soft brush or cloth to clean ED-ATOM lights. DO NOT use detergents or spirits as this can damage the light and void your warranty.
Page 4: Tools Required
TOOLS REQUIRED Hole Saw - Ø65mm ~ Ø70mm (2 5/8” ~ 2 Box cutter / Knife 3/4” saw) Flat-blade screw driver (for light- No. 2 Phillips screwdriver head removal) IMPORTANT NOTES • The use of power tools for product assembly is NOT recommended as these devices can cause faults and damage to light components.
Page 5: Included Parts
INCLUDED PARTS NICHE ASSEMBLY PLUG & CABLE NICHE CAP CONICAL NUT CONICAL WASHER CLAMP RING 6X SCREWS LIGHT...
Page 6: Finished Installation
FINISHED INSTALLATION All light conduits must be run in individual lengths back to transformer location. POWER SUPPLY An air-loop or junction box must be installed (TRANSFORMER) as part of each conduit run to prevent pool siphoning. NOTE: Conduit should contain a draw-wire to allow easy installation of power cable.
Page 7: Installation Procedure
INSTALLATION PROCEDURE MOUNTING HOLE PREPARATION * * MAY NOT BE REQUIRED IF PRE-PUNCHED / DRILLED HOLES AVAILABLE FOR LIGHT MOUNTING ESTIMATED WATERLINE Ø65~Ø70mm 470mm (MAX) ” ”) 120mm (MIN) HOLESAW BELOW ESTIMATED WATERLINE DRILL HOLE THROUGH STEEL WALL ORIENTATION OF NICHE “TOP” IMPORTANT FEED CABLE THROUGH...
Page 8 ASSEMBLE WASHER AND NUT TIGHTEN NUT 20mm OR 25mm BELL FIRMLY TIGHTEN MOUTH CONDUIT GLUED BY HAND ONLY TO CONDUIT TAKE-OFF (SEE *GLUING NOTE BELOW) * GLUING NOTE ENSURE P.V.C. SOLVENT CEMENT IS SUITABLE FOR NON-PRESSURE APPLICATIONS AND USE WITH A.B.S. PLASTIC...
Page 9 REMOVE NICHE CAP ASSEMBLE VINYL CLAMP RING VINYL LINER THIS FASTENER INSTALLED OVER LOCATED AT TOP STEEL WALL *RECOMMENDED FASTENING ORDER FIRMLY TIGHTEN FASTENERS BY HAND ONLY IN NUMBERED ORDER *...
Page 10 TRIM VINYL CLAMP RING CUT & REMOVE VINYL INSIDE CLAMP RING REMOVE PROTECTIVE CAP REMOVE PROTECTIVE...
Page 11 REMOVE TERMINAL COVER NOTE ENSURE SEAL IS SEATED FLAT IN PLUG BASE REMOVE TERMINAL COVER FROM PLUG TERMINAL USING PHILLIPS-HEAD COVER (NO.2) SCREW-DRIVER NOTE DO NOT REMOVE TERMINAL COVER UNDERWATER SERVICING RETAIN TERMINAL COVER IN CASE LIGHT NEEDS REMOVAL. SEE PAGE 15 FOR MORE INFO...
Page 12 FASTEN PLUG TO LIGHT ALIGN TERMINAL PINS AND FIRMLY ASSEMBLE PLUG TO LIGHT FASTEN PLUG TO LIGHT USING 3 x (M3.5 X 25mm) FASTENERS & NO.2 PHILLIPS-HEAD SCREWDRIVER IMPORTANT NOTES • DO NOT OVERTIGHTEN SCREWS • DO NOT USE POWER-TOOLS •...
Page 13: Light Assembly
LIGHT ASSEMBLY COIL INSIDE NICHE INSERT LIGHT INTO CLAMP RING ROTATE 15 DEGREES COUNTER-CLOCKWISE FROM ‘TOP’ TO ALIGN WITH LOCKING MECHANISM ROTATE CLOCKWISE “CLICK” TO LOCK LIGHT IN PLACE...
Page 14: Light Connection
WITH A SINGLE EM DC LIGHT, MAKE THE APPROPRIATE CABLE CONNECTION TO THE CONTROLLER. ED-ATOM POOL LIGHT ENSURE “SLX/FLX” MODE IS SELECTED IN THE CONTROLLERS SETTINGS UNDER “Select Light Type”. DO NOT USE “Spa Electrics” MODE. Select Light Type SLX/FLX LumiPower Spa Electrics...
Page 15: Light Removal
LIGHT REMOVAL PUSH & HOLD BUTTON WITH FLAT BLADE HOLD DOWN BUTTON WITH FLAT-BLADE ROTATE COUNTER-CLOCKWISE & REMOVE FROM LOCKING RING ROTATE & RELEASE LIGHT FROM NICHE...
Page 16 PLUG REMOVAL REMOVE PLUG FROM LIGHT UNSCREW 3x FASTENERS USING NO.2 PHILLIPS-HEAD SCREWDRIVER ASSEMBLE TERMINAL COVER TO PLUG & STORE IN NICHE ASSEMBLE TERMINAL COVER TO PLUG USING NO.2 PHILLIPS-HEAD SCREWDRIVER PLUG CAN BE STORED WITHIN NICHE AS PICTURED...
Page 17: Cable Adjustment & Removal
CABLE ADJUST / REMOVAL ATOM lights (for vinyl pools) are supplied with 700mm of cable pre-installed within the niche. In circumstances where additional cable-length is required, the cable can be extended to a maximum of 1000mm and stored within the niche. (Applicable for cables up to 1.0mm The following diagrams illustrate how the cable can be adjusted and/or removed.
Page 18 CABLE ADJUST / REMOVAL CONTINUED... 1000mm (MAX) * AFTER CABLE ADJUSTMENT 700mm * (STANDARD) * CABLE LENGTH NOTE CABLE LENGTH MEASURED FROM ALWAYS ENSURE POOL LIGHT CAN FRONT OF CLAMP RING TO PLUG’S BE RAISED ABOVE WATERLINE FOR CABLE-ENTRY POINT INSPECTION &...
Page 19: Troubleshooting
Return product to your local high voltage and/or Spa Electrics reseller or Spa incorrect power supply. Electrics for repair If these issues cannot be resolved with the above recommended actions, please contact your local Spa Electrics reseller or Spa Electrics directly.
Page 20: Key Dimensions
KEY DIMENSIONS NICHE 182mm OVERALL NICHE LENGTH 175mm FROM POOL WALL TO CONDUIT INSTALLED LIGHT POOL WALL 38mm...
Page 21 PAGE INTENTIONALLY LEFT BLANK...
Page 22 PAGE INTENTIONALLY LEFT BLANK...
Page 23 PAGE INTENTIONALLY LEFT BLANK...
