Spa Electrics AGF Installation & Owner's Manual

Fibreglass pools
Hide thumbs

Advertisement

Quick Links

Download this manual
FIBREGLASS POOLS
AGF
INSTALLATION & OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the AGF and is the answer not in the manual?

Questions and answers

Related Manuals for Spa Electrics AGF

Summary of Contents for Spa Electrics AGF

  • Page 1 FIBREGLASS POOLS INSTALLATION & OWNER’S MANUAL...

  • Page 2: Table Of Contents

    CONTENTS READ THIS FIRST TOOLS REQUIRED PRODUCT SUPPORT AND INFORMATION INCLUDED PARTS FINISHED INSTALLATION INSTALLATION PROCEDURE LIGHT REMOVAL LIGHT ASSEMBLY CONNECTIONS KEY DIMENSIONS NOTICE FRESH WATER USE ONLY HORIZONTAL MOUNT ONLY NOT INTENDED FOR OPERATION OUT OF WATER FOR SUPPLY CONNECTION, USE ONLY AN ISOLATING LOW VOLTAGE POWER SUPPLY WITH UNGROUNDED OUTPUT, EVALUATED FOR SWIMMING POOL USE...

  • Page 3: Read This First

    READ THIS FIRST This document details the general and installation information for the ARGON underwater lighting system. All ARGON lights are manufactured by Spa Electrics in Australia from only the highest quality materials. For more information about Spa Electrics & our products, please visit www.spaelectrics.com.au GENERAL NOTES •...

  • Page 4: Important Note

    • Pool chemicals & pH levels: Due to the corrosive nature of unbalanced pool chemicals, Spa Electrics strongly recommends that your pool water is balanced prior to installing your pool lights or any plastic or stainless-steel components and tested weekly to maintain these levels.

  • Page 5: Included Parts

    INCLUDED PARTS AGF CABLE, PLUG & NICHE ASSEMBLY LIGHT ASSEMBLY LIGHT RIM CONICAL NUT CONICAL WASHER FLAT WASHER LV25-12 / LV50-12 DUAL / LV100Q-12 TRANSFORMERS (INCLUDED IN SINGLE / DUAL / TRI OR QUAD LIGHT KITS)

  • Page 6: Finished Installation

    FINISHED INSTALLATION FIBREGLASS FIBREGLASS POOL WALL NICHE ARGON FLAT CONICAL CONICAL LIGHT WASHER WASHER...

  • Page 7: Installation Procedure

    INSTALLATION PROCEDURE DRILL HOLE THROUGH POOL WALL * * MAY NOT BE REQUIRED IF PRE-PUNCHED / DRILLED HOLES AVAILABLE FOR LIGHT MOUNTING ESTIMATED WATERLINE Ø64mm HOLESAW 400mm (MAX) 100mm (MIN) BELOW ESTIMATED WATERLINE EASILY ACCESSIBLE FLAT SURFACE ORIENTATION OF NICHE “TOP” POSITION TOP ARROW UPWARDS...
  • Page 8 ASSEMBLE WASHERS AND NUT ASSEMBLE COMPONENTS ON TO CABLE IN ORDER. CONICAL CONICAL WASHER FLAT WASHER APPLY SILICONE APPLY NEUTRAL CURING APPLY LARGE APPLY SMALL SILICONE TO BOTH SIDES AMOUNT AMOUNT OF POOL WALL WARNING DO NOT USE ACID CURING APPLY SMALL SILICONES.

  • Page 9: Tighten Nut

    TIGHTEN NUT FIRMLY TIGHTEN BY HAND ONLY REMOVE EXCESS SILICONE REMOVE EXCESS SILICONE...
  • Page 10 ATTACH CONDUIT 25mm CONDUIT...

  • Page 11: Light Removal

    LIGHT REMOVAL PUSH AND LEVER OFF LIGHT RIM WITH FLAT BLADE INSERT FLAT BLADE SCREWDRIVER INTO NICHE ABOVE TOP 12 O’CLOCK ARROW AND LEVER OFF LIGHT RIM ROTATE AND PULL OUT LIGHT ASSEMBLY ROTATE LIGHT ASSEMBLY COUNTER-CLOCKWISE SO THE ARROW ON THE LIGHT ASSEMBLY IS AT 10 O’CLOCK.
  • Page 12 REMOVE PLUG FROM LIGHT UNSCREW PLUG COLLAR COUNTER-CLOCKWISE UNTIL IT IS FREE SPINNING DISCONNECT THE TERMINALS DISCONNECT LIGHT ASSEMBLY FROM PLUG BY PULLING APART IMPORTANT NOTE CABLE SHOULD BE SECURED ABOVE WATER AND WEATHER PROTECTED WHILE LIGHT IS DETACHED...

  • Page 13: Light Assembly

    LIGHT ASSEMBLY CONNECT THE TERMINALS ALIGN THE TERMINAL PINS ON PLUG AND BACK OF LIGHT ASSEMBLY AND FIRMLY CONNECT TOGETHER IMPORTANT NOTES • DO NOT ADD SEALANTS, GREASES OR ADHESIVES • ENSURE ALL SURFACES ARE CLEAN AND DRY • DO NOT ASSEMBLE UNDERWATER FASTEN PLUG TO LIGHT TO LOCK INTO PLACE: TWIST COLLAR CLOCKWISE...
  • Page 14 COIL CABLE ANTI-CLOCKWISE MINIMUM 600mm CABLE INSIDE NICHE COIL CABLE ANTI-CLOCKWISE...
  • Page 15 TWIST ON THE LIGHT ASSEMBLY 1: PLACE THE LIGHT ASSEMBLY OVER 2-3: TWIST LIGHT ASSEMBLY CLOCKWISE THE MOUNTING BRACKET WITH THE TOP TO 12 O’CLOCK ARROW AT 10 0’CLOCK ARROW ATTACH LIGHT RIM 1: LINE UP BASE OF LIGHT RIM 2: PUSH IN AT TOP UNTIL WITH BASE OF LIGHT ASSEMBLY LIGHT CLICKS INTO PLACE...

  • Page 16: Connections

    CONNECTIONS HOW TO CONNECT SINGLE LIGHT TO G.P.O. 25VA POOL LIGHT TRANSFORMER HOW TO CONNECT MULTIPLE LIGHTS TO G.P.O. 50VA TRANSFORMER DAISY-CHAIN TRANSFORMERS UP TO 10A (MAX) POOL LIGHT POOL LIGHT...
  • Page 17 HOW TO CONNECT MULTIPLE LIGHTS TO G.P.O. 100VA TRANSFORMER DAISY-CHAIN TRANSFORMERS UP TO 10A (MAX) POOL LIGHT POOL LIGHT POOL LIGHT POOL LIGHT...

  • Page 18: Key Dimensions

    KEY DIMENSIONS 22mm 136mm Ø130mm...
  • Page 19 PAGE INTENTIONALLY LEFT BLANK...
  • Page 20 NOTE PLEASE STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE © COPYRIGHT 2024 SPA ELECTRICS PTY. LTD. ALL RIGHT RESERVED 2024 08 08...
