FISHER PRICE J7826

Owner's Manual

Shop genuine replacement parts for FISHER PRICE

J7826

Find Your FISHER PRICE Ride On Parts - Select From 999 Models

-------- Manual continues below --------

Table of Contents

Need help?

Do you have a question about the POWER WHEELS Barbie Trail Rider and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher-Price POWER WHEELS Barbie Trail Rider

Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE J7826 Owner's Manual Shop genuine replacement parts for FISHER PRICE J7826 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
Page 2 Owner's Manual with Assembly Instructions For Model J7826 ™ Product features may vary from the picture above. Please read this manual and save it with your original sales receipt. Tools needed for assembly: Hammer and Safety Scissors (both not included). Use only with a Power Wheels ®...
Page 3: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be or call 1-800-348-0751. damaged by riding this vehicle indoors. Fisher-Price ® will not be • To register your vehicle, please visit us on-line at responsible for damage to the floor if the vehicle is used indoors.
Page 4: B Warnings And Cautions
WARNINGS AND CAUTIONS ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.
Page 5: C Parts
PARTS • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •...
Page 6: Parts Picture
PARTS PICTURE Note: Some parts are assembled on both sides of the vehicle. This illustration shows assembly on right side only. Part Not Shown Vehicle Handlebar Round Bushing - 2 Label Sheet Cowling 6 Volt Battery " Washer - 4 Seat Super 6 Volt Charger Cotter Pin...
Page 7: Battery Charging
BATTERY CHARGING ELECTRICAL HAZARD ELECTRICAL HAZARD WARNING CAUTION • Battery can fall out and injure a child if Use the charger in dry locations only. vehicle tips over. Always use battery retainer. • PREVENT FIRE About Thermal Fuses - Never modify the electrical system. Your Power Wheels ®...
Page 8: Ebattery Charging
ASSEMBLY BATTERY CHARGING WARNING A-Style Charger Connector Children can be harmed by small parts, A-Style Battery sharp edges and sharp points in the vehicle's Connector unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
Page 9 ASSEMBLY Round Bushing Motor Assembly Pins Ring End Front Axle Wheel " Washer Hubcap Rear Wheel Rear Axle Assembly Cap Nut Driver Round Assembly Bushing Tool Motor Assembly Cap Nut • Face the back end of the vehicle. Hint: You will use the other rear wheel driver to properly position the rear axle assembly into the motor assembly.
Page 10 ASSEMBLY Front Tabs Front Tabs PRESS HERE To Snap Side Tabs Cowling Side Tab Side Tab Shifter Handle Rear Tab • Press firmly on each side of the cowling to snap the four side tabs into the slots in the vehicle. Make sure the rear tab stays aligned with the slot.
Page 11 ASSEMBLY Steering Handlebar Column Assembly Upper Steering Lower Steering Linkage Linkage Steering Steering Column Bushing Bottom View Hole • Lift the front end of the vehicle. • Slide the straight end of the steering column through the hole in the upper steering linkage and out through the hole in the vehicle.
Page 12: G Decoration
DECORATION Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •...
Page 13: H Battery Installation
BATTERY INSTALLATION Battery IMPORTANT! Use only a Power Wheels ® 6 volt battery with A-style Motor Connector connector and built-in thermal fuse. Use of any other battery will Harness damage your vehicle. Make sure that you charge the battery for Connector at least 18 hours using the enclosed Power Wheels ®...
Page 14: I Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care Disposal If a battery leak develops, avoid contact with the leaking acid and • Your Power Wheels ® battery is a non-spillable sealed lead-acid place the damaged battery in a plastic bag. See information below battery.
Page 15: J Safe Driving Rules
SAFE DRIVING RULES Teach Safety Rules to Children RIDING HAZARD While children can quickly develop the skill necessary to drive this vehicle, it is important to remember that their judgment skills are still WARNING very immature. Unsupervised driving by children can lead to serious injury.
Page 16: K Vehicle Operation
VEHICLE OPERATION Reverse IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price ® Hint: Once your child is comfortable operating the vehicle forward, will not be responsible for damage to the floor if the vehicle is introduce reverse.
Page 17: Lvehicle Care
LIMITED WARRANTY VEHICLE CARE • Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on a regular basis for Bumper-to-Bumper* cracks or broken pieces. Limited Warranty • During snowy or rainy weather, the vehicle should be stored inside or under a protective cover.
Page 18: Problems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 9 AM and 7 PM (EST) Monday through Friday and 11 AM and 5 PM EST Saturday.
Page 19 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Short run time (Less than Undercharged battery Charge the battery. A new battery should have been charged for at 1 - 3 hours per charge) least 18 hours before using the vehicle for the first time. After first- time use, recharge the battery for at least 14 hours after each use.
Page 20 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE SOLUTION Sometimes the vehicle doesn’t Loose wire or connector Check all wires around the motors and all connectors to make run, but other times it does sure they are tight. ® Motor or electrical switch damage Contact your local Power Wheels authorized service center for diagnosis and repair.
Page 21 Authorized Service Center. For the location nearest you, visit us on-line at www.powerwheels.com. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2006 Mattel, Inc. All Rights Reserved. Fisher-Price and Power Wheels are U.S. trademarks of Mattel, Inc.
