Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 74350 Owner's Manual Shop genuine replacement parts for FISHER PRICE 74350 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
Page 2 ® Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 74350 Tools needed for assembly: Phillips Screwdriver, Hammer, Slotted Screwdriver, and Safety Scissors. Use only with a Power Wheels ® Type H 6 Volt Battery, a Power Wheels ®...
Page 3: Table Of Contents
Parts Important Information ..............2 Warnings .
Page 4: Warnings
Warnings WARNING • Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
Page 5: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
Page 6 Parts Key Assembly Small Parts Bag 6-Volt Charger Microphone 25 Amp Fuse - 2* Radio Dial Shifter 6 Volt Battery Steering Wheel Cap Radio Knob - 2 Gas Cap Assembly Not Shown: Label Sheet, Literature Bag Traction Band - 4 #8 x 1"...
Page 7: Parts Diagram
Parts Diagram Vehicle Body Windshield Key Assembly Steering Column Windshield Frame 25 Amp Fuse Grille Dash 6 Volt Battery Sport Bar Hood Cap Nut - 2 Sport Bar Cover Set Microphone #6 x " Screw - 11 Taillight Lens - 2 Radio Knob - 2 #6 x 1 "...
Page 8: Battery Charging
Battery Charging WARNING CAUTION Use the charger indoors only. • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the Please Note: battery could result in serious injury. • Your new battery must be charged for at least 18 •...
Page 9 Battery Charging 25 Amp Fuse GOOD FUSE "BLOWN" FUSE • Plug the charger into a standard wall outlet. • If you are charging the battery for the first time, insert a Note: If power flow to the wall outlet is controlled by a 25 amp fuse into the battery.
Page 10: Assembly
Assembly Do not omit any steps. Please set aside at least 45 minutes for assembly. Steering Column Guides Vehicle Body Inset Dash Square Opening Steering Column • Insert two #8 x 1” screws through the holes in the dash Bottom View and into the vehicle body.
Page 11 Assembly Steering Wheel Cap Radio Knobs Steering Wheel Shifter Activity Panel • Fit the steering wheel cap into the center of the steering • From the front of the activity panel, snap in the wheel with the screw holes aligned. radio knobs.
Page 12 Assembly Windshield Frame Slot Microphone Windshield Plastic • Fit the windshield into the windshield frame. • Insert five #6 x " screws through the holes in the wind- shield and into the windshield frame. • Tighten the screws with a Phillips screwdriver. Do not over-tighten.
Page 13 Assembly Hood Grille Sport Bar Half of Sport Bar Cover (BAC) Holes • Raise the hood. • Fit the tabs at the bottom of the grille into the slots in the vehicle body. • Press near the top of the grille to snap it into the •...
Page 14 Assembly Taillight Lens Taillight Sport Bar Housing Seat Hole Rear of Vehicle • Using safety scissors, separate the taillight lenses and taillight housings from the plastic connectors. Dispose of Hole the plastic connectors. • Fit a taillight lens in a taillight housing. •...
Page 15 Assembly Pretend Engine Traction Spark Plug Band Wire Set Spark Plug Wire End Ridge Wheel Hole • Snap the center of the spark plug wire set onto the pretend engine. • Fit each of the spark plug wire ends into the holes on the Bottom View sides of the pretend engine.
Page 16: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! Keep the following guidelines in mind when applying labels: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils.
Page 17: Battery Installation/Pretend Engine Assembly
Battery Installation/Pretend Engine Assembly Battery Connector Battery Pretend Engine Hood Cover Motor Harness Connector • Fit the pretend engine cover over the battery, motor • Lift the hood. harness connector and battery connector. • Place the battery in the battery compartment. Make sure •...
Page 18: Battery Care And Disposal
Battery Care and Disposal Care Disposal If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is a sealed lead-acid acid and place the damaged battery in a plastic bag. See battery. It must be recycled or disposed of in an environ- information below for proper disposal.
Page 19: Rules For Safe Driving
Rules for Safe Driving • While driving across a steep slope, the vehicle may tilt and tip over. The wheels could lose traction, WARNING causing the vehicle to slip. • While driving up a steep incline, the motor may stop •...
Page 20: How To Operate Your Vehicle
How to Operate How to Operate Your Vehicle Your Vehicle • Push the bottom button (REV) on the FORWARD/REVERSE switch to drive in REVERSE • Press down on the foot pedal . The vehicle will go in reverse at a maximum of 2 •...
Page 21: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Affairs, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center.
Page 22 Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the battery suddenly stopped connector is tightly plugged into the motor harness connector, and that there are no loose wires around the motors.
Page 23 Problems and Solutions Guide Problem Possible Cause Solution Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use.
Page 24 Problems and Solutions Guide Problem Possible Cause Solution Vehicle constantly blows fuses Wrong type of fuse used Your vehicle requires a Power Wheels ® 25 amp fuse in the battery. Make sure the Power Wheels 25 amp fuse is ® properly installed.
Page 25: Statement Of Limited Warranty
Statement of Limited Warranty law or any indirect or consequential damages for breach of 90-day limited warranty for the Power warranty. Some states do not allow the exclusion or limita- Wheels ® Ride-On Toy Vehicle tion so this limitation may not apply to you. A 6-month battery warranty applying only to Should you need service or assistance with your the 6 volt battery which was included by...
Page 26 Authorized Service Centers WEST LOS ANGELES - California Electric Service Center, STUART - Appliance Doctors, 3166 S.E. Dixie Highway, NEW ALBANY - Wells Hardware, Inc., 1011 Vincennes 2314 S. Westwood Blvd., 90064, (310) 475-2532 34997, (561) 287-6437 Street, 47150, (812) 944-4523 YUCAIPA - Aire-Rite Heating &...
Page 27 Authorized Service Centers TANEYTOWN - MacHenry Services, 68 Frederick Street, MISSOURI ELMIRA - Capabilities, Inc., 1149 Sullivan Street, 14901, 21787, (410) 756-6659, (800) 276-1301 (607) 734-2006 INDEPENDENCE - Mar-Beck Appliance Service Co., WASHINGTON D.C. (BELTSVILLE) - Philips Consumer GREAT NECK - Turnpike Appliance Service Center, 45 4476 South Noland Road, 64055, (816) 478-1889 Electronics, 10800 Rhode Island Avenue, 20705, Northern Boulevard, 11021, (516) 466-0644...
Page 28 Authorized Service Centers STRYKER - Short’s Hardware, 115 N. Depot Street, 43557, GREENWOOD - Bikes & Boards & Mopeds, 203A (419) 682-4231 Montague Avenue, 29646, (864) 229-2453 VERMONT TOLEDO - Broadway Sales and Appliance Repair, 1621 SENECA - Seneca Micronics, 110 East North First, 29678, RUTLAND - Appliance Service Center Ltd., 152 Woodstock Broadway, 43609, (419) 241-9731, (800) 436-5415 (864) 882-6593...
Page 29 © CHRYSLER CORPORATION 1998. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A. ©1998 Mattel, Inc. - All Rights Reserved. Fisher-Price and Power Wheels are U.S. trademarks of Mattel, Inc. Printed in the U.S.A. 74350-0920...
