  • Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 78476 Owner's Manual Shop genuine replacement parts for FISHER PRICE 78476 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
  • Page 2 ™ Product features may vary from the picture above. Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sales receipt. For Model 78476 Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver, Hammer, and Pliers (not included); Cap Nut Assembly Tool (included). Use only with a Power Wheels ®...

  • Page 3: Table Of Contents

    Table of Contents Important Information ..............2 Warnings .

  • Page 4: Warnings

    Warnings WARNING • Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.

  • Page 5: Parts

    Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
  • Page 6 Parts Console Microphone 6 Volt Charger 6 Volt Battery Handlebar Steering Bushing Rear Axle Cap Nut Foam Spacer* Handlebar Neck Installation Tool Hex Bushing - 6 Not Shown: Label Sheet, Literature Bag * Do not discard the foam spacer packaged with the battery. Save it for use in the vehicle's battery compartment. #6 x "...

  • Page 7: Parts Diagram

    Parts Diagram Console - Headlight 2" Screw - 2 Vehicle Body Console - Lower Rear Axle Cowling Steering Bushing Microphone Seat #6 x " Screw 6 Volt Battery Rear Wheel - 2 25. #8 x 1" Screw - 2 Hand Grip - 2 Rear Hubcap - 2 Handlebar 26.

  • Page 8: Battery Charging

    Battery Charging CAUTION WARNING Use the charger in dry locations only. • The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the Important Notes: battery could result in serious injury. • Your new battery must be charged for at least •...
  • Page 9 Battery Charging A-Style Charger Connector A-Style Battery Connector NO GAP • Plug the charger into a standard 120 volt wall outlet. Incorrect Correct Note: If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. •...

  • Page 10: Assembly

    Assembly Rear Axle Motor Assembly Pins Rear Axle Rear Axle Assembly Cap Nut Rear Wheel Driver • Fit a cap nut onto one end of the rear axle. • Tap the other end of the rear axle with a hammer to •...
  • Page 11 Assembly Hex Bushing Washer Bushing Rear Hubcap Cap Nut Cap Nut Bushing Assembly Tool Front Wheel Front Hubcap Cap Nut Cap Nut Assembly Tool Rear Washer Wheel Driver • Slide a washer onto one of the front axles. • Slide a washer onto the rear axle. •...
  • Page 12 Assembly Front Tab Front PRESS HERE To Snap Side Tabs Cowling Side Side Shifter Rear Tab Handle Channel • Press firmly on each side of the cowling to snap the four side tabs into the slots in the vehicle body. Make sure the rear tab stays aligned with the slots.
  • Page 13 Assembly Lower Console/Headlight Upper Console Handlebar Headlight Lower Console Neck #6 x " screw #8 x 1" screw • Position the handlebar upright. Note: For packaging reasons, the console/headlight has • Fit the neck under the handlebar, with the holes in the been pre-assembled at the factory.
  • Page 14 Cap Nut Steering Column Handlebar Steering Assembly Column Cap Nut • Fit a cap nut on the curved end of the steering column. • Support the steering column and tap the cap nut with a • Slide the handlebar assembly onto the steering column, hammer to secure it on the end of the steering column.
  • Page 15 Assembly Microphone "T" End Handgrip Hole Handlebar • Bend the plastic tip at the end of the microphone cord so that it forms a "T". BARBIE is a U.S. trademark of Mattel, Inc. • Insert the "T" end of the microphone cord into the hole in the console.

  • Page 16: Label Decoration

    Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •...
  • Page 17 Label Decoration Left Side...

  • Page 18: Battery Installation

    Battery Installation Important Note: Use only a Power Wheels ® battery with Motor A-style connector and built-in thermal fuse. Use of any Harness other battey can damage your vehicle. Make sure Connector that you charge the battery for at least 18 hours using the enclosed Power Wheels ®...

  • Page 19: Battery Care And Disposal

    Battery Care Battery Care and Disposal and Disposal Care Disposal If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is a sealed lead-acid acid and place the damaged battery in a plastic bag. See battery.

  • Page 20: Rules For Safe Driving

    Rules for Safe Driving • While driving across a steep slope, the vehicle may WARNING tilt and tip over. The wheels could lose traction, causing the vehicle to slip. • While driving up a steep incline, the motor may • Adult supervision is required. Children stop and the vehicle could roll backwards at an do not have the judgement necessary to unsafe speed.

  • Page 21: How To Operate Your Vehicle

    How to Operate How to Operate Your Vehicle Your Vehicle Driving Forward To Stop Shifter • Your vehicle has a patented, electronic braking system that automatically stops the vehicle when your child’s foot is lifted from the pedal. • Make sure your child is comfortable with steering the vehicle and automatically knows how to stop.

  • Page 22: Problems And Solutions Guide

    Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Affairs, toll-free at 1-800-348-0751 between 8 AM and 5 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center.
  • Page 23 Vehicle was running but suddenly stopped Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Tripped thermal fuse The built-in thermal fuse in the battery may "trip" and shut suddenly stopped (cont.) down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe.
  • Page 24 Problems and Solutions Guide Problem Possible Cause Solution Problem Possible Cause Solution Vehicle runs sluggishly (cont.) Battery needs charging After approximately 3 hours of constant use, the battery needs charging. Battery is old and will not accept Even with proper care, a rechargeable battery does not last full charge forever.

  • Page 25: Authorized Service Centers

    Authorized Service Centers We are continually expanding our Authorized Service Center Network. Please check this listing for the Authorized Service Center nearest you. If there is not one in your area, please call Power Wheels ® Consumer Affairs at 1-800-348-0751. ALABAMA SAN DIEGO - California Electric Service Center, 3430 POMPANO BEACH - Philips Consumer Electronics, 2099 W.
  • Page 26 Authorized Service Centers INDIANAPOLIS - Sullivan Hardware Do-It Center, LOWELL - Lowell Appliance Service Center, Inc., 564 Dutton LINCOLN - Sperry TV, 1115 North 47th St., 68503, 7021 N. Keystone, 46220, (317) 255-9230 Street, 01854, (508) 454-8731 (402) 464-9181 NEW ALBANY - Wells Hardware, Inc., 1011 Vincennes Street, MAYNARD - Gramp’s Garage, 16 Main Street, 01754, LINCOLN - Sperry TV, 2013 Highway 2, 68502, 47150, (812) 944-4523...
  • Page 27 Authorized Service Centers HICKORY - First Flight Bicycles, 2435 N. Center Street, 28601, PUERTO RICO UTAH (704) 324-9350 GATINEAU - Les Equipements Brabant & Fils, 776B Blvd. OREM - The Mending Shed, 1735 South State Street, 84058, RALEIGH - Authorized Appliance Service Center, Maloney, J8P 1G6, (819) 663-2526 (801) 225-8012, (800) 339-9297 800 North Person Street, 27604, (919) 834-3476...
  • Page 29 Authorized Service Center list in this manual. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2000 Mattel, Inc. All rights reserved. Fisher-Price, Power Wheels by Fisher-Price and BARBIE are U.S. trademarks of Mattel, Inc. Printed in the U.S.A.

This manual is also suitable for:
