Ajax SpaceControl S Jeweller user manual
Ajax SpaceControl S Jeweller is a wireless key fob for managing security
modes. It features a panic button and protection against accidental pressing.
The device allows users to arm/disarm an Ajax system, enable the night mode,
or activate an alarm.
Ajax SpaceControl S Jeweller operates as part of the Ajax system. The key fob
communicates with the
fob can be used to manage any third-party security control panel through the
uartBridge
or
ocBridge Plus
Since the communication is two-way, you will know whether the system has
received the key fob command.
Users can configure the key fob in
Windows.
This product line is developed for projects. Only accredited Ajax Systems partners can
sell, install, and administer Superior products.
Updated October 10, 2024
hub
via the secure
Jeweller
integration module.
Ajax apps
protocol. In addition, the key
for iOS, Android, macOS, and

Advertisement

loading
Need help?

Need help?

Do you have a question about the SpaceControl S Jeweller and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AJAX SpaceControl S Jeweller

Summary of Contents for AJAX SpaceControl S Jeweller

  • Page 1 It features a panic button and protection against accidental pressing. The device allows users to arm/disarm an Ajax system, enable the night mode, or activate an alarm. Ajax SpaceControl S Jeweller operates as part of the Ajax system. The key fob communicates with the via the secure Jeweller protocol.

  • Page 2: Functional Elements

    You can assign functions to the buttons only when using the key fob with uartBridge or ocBridge Plus. You can not change the commands assigned to the buttons when using the key fob with an Ajax hub. Compatible hubs and range extenders The device requires an Ajax hub with OS Malevich 2.25...

  • Page 3: Operating Principle

    Operating principle 00:00 00:12 Ajax SpaceControl S Jeweller controls security modes and sends an alarm signal to the central monitoring station when the panic button of the key fob is pressed. The communication range between the key fob and the hub is up to 1,300 meters.

  • Page 4: Adding To The System

    Ensure the hub is turned on and has internet access via Ethernet, Wi-Fi, and/or mobile network. . Ensure that the space is in disarmed mode and the hub is not starting an update. To do this, check statuses in the Ajax app.
  • Page 5 To connect the key fob to a third-party security control panel through uartBridge ocBridge Plus , follow the recommendations in the manual for the corresponding integration module. Icons The icons display some of the Ajax SpaceControl S Jeweller states. To access them: 1. Sign in to the Ajax app...
  • Page 6 The device was not transferred to the new hub. Learn more States The states include information about the device and its operating parameters. The states of Ajax SpaceControl S Jeweller can be found in Ajax apps: 1. Sign in to the Ajax app 2. Select the space.
  • Page 7 4. Select Ajax SpaceControl S Jeweller from the list. Parameter Value Charge level of the key fob battery. Two states are available: ОК Battery charge Learn more Status of Panic button. Available states: Panic Enabled Disabled Displays the selected type of protection against accidental activation: Off —...
  • Page 8 Device ID Device identifier. Device No. The number of the device loop (zone). Settings To change Ajax SpaceControl S Jeweller settings, in the Ajax app 1. Go to the Devices tab. 2. Select Ajax SpaceControl S Jeweller from the list.
  • Page 9 Configuration is available only if group mode is enabled. Selecting the key fob user. The key fob is unassigned: The key fob events are sent to Ajax apps under the key fob name. The key fob settings determine security mode management rights.
  • Page 10 Ajax sirens activates connected to the Alert with siren if panic button is pressed system. Ajax SpaceControl S Jeweller activates all sirens, regardless of the groups they are in. User guide Opens the device user manual. Allows a user to deactivate the device without deleting it from the system.

  • Page 11: Maintenance

    Clean the key fob enclosure from dust, cobwebs, and other contaminants as they appear. Use a soft, dry cloth for cleaning appliances. To clean Ajax SpaceControl S Jeweller, do not use any substances containing alcohol, acetone, gasoline, or other active solvents.

  • Page 12: Technical Specifications

    The value of the battery level is not updated regularly, but only after pressing one of the buttons on the key fob. When the battery is low, the user will receive a notification in the Ajax app, and the key fob LED will slowly light up and go out red each time the button is pressed.
  • Page 13 The warranty for the products of the “Ajax Systems Manufacturing” Limited Liability Company is valid for 2 years after purchase. If the device does not operate properly, we recommend contacting support service first, as most technical issues can be resolved remotely.
