1. Scope

This chapter contains a description and specifications of the Qseal-auto, a Battery
Powered Tube sealer with handle from Conroy Medical AB.

1.1 Introduction

Qseal-auto is a fully automatic system for sealing PVC tubes, especially for tubes in
blood pack systems. Following the sealing procedure the tube is easily pulled apart, due
to the distinct sealing pattern, with no damage to the blood inside the tubes.
The Main unit is connected by the Coaxial cable to the Hand unit, where the sealing
takes place when the Seal button is pressed. Different types or sizes of tubes can be used
and the necessary sealing time is self-adjustable to fit the tubes that are being used.
Qseal-auto works with radio frequency (RF) energy to generate heat for sealing. The in-
tended clinical benefit of Qseal-auto is safe sealing of tubes and bags. Intact seals mini-
mize the risk for contamination and discards of blood component and provide safety for
the user and patient. Users are requested to be cautious of potential electrical shocks or
hazards while handling this sealer. Always turn the power switch off before disconnecting
cables or cleaning.

1.2 Performance and Specifications

The table below lists the physical specifications.
Parameter
REF CS524:
Type of PVC tube:
4
Value/ Description
Qseal-auto, a complete sealing system, which includes
Main unit, Hand unit, Coaxial cable, Battery charger and
Operator's manual.
Different types and sizes of tubes up to 6.2 mm (0.24") outer
diameter can be sealed due to a sophisticated sensing system,
which automatically adapts sealing time.
