IMPORTANT
Due to the safety regulations governing air and maritime
transport, the machine battery comes separate. Follow
the steps below to connect it:
Before proceeding, make sure that the on/off
switch (11) and the master switch (15) are OFF.
1) Turn the machine onto its back. Remove the three screws
(O) and the four feet (Q) to take off the protective screen.
2) Plug in the yellow connector. Then replace the protective
screen and return the machine to its natural position. Using
the power adapter supplied with the machine, charge it to
100% before using it.
