XAG JetSeed Quick Start Manual

Granule spreading system
Hide thumbs Also See for JetSeed:

Advertisement

Table of Contents

JetSeed™
Granule Spreading System
Quick Start Guide
Version 1.1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JetSeed and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XAG JetSeed

Summary of Contents for XAG JetSeed

  • Page 1 JetSeed™ Granule Spreading System Quick Start Guide Version 1.1...
  • Page 2 Dear user, thank you for choosing XAG products. For safety reasons and the best experience possible, XAG recommends that you read through the User Manual and Disclaimer in this document before attempting to use the JetSeed™ Granule Spreading System. Contact Us If you have any questions about this document, please contact our Technical Support via email: info@ xa.com...

  • Page 3: List Of Items

    List of Items Before unpacking and using the product, please carefully check if it contains all the items listed below. Please contact your dealer if there are any missing items. Screw Kit × 1 Spreader × 1 Granule Container × 1 Small Rolling Feeder ×...

  • Page 4: System Assembly

    System Assembly Pre-Assembly Preparations Before assembling the spreading system, please remove the spraying system and some parts first. 1. Disassemble the Head Cover 2. Disassemble the Antenna Frame Lift the head cover from the front, and push the Remove six antenna frame fixing screws, and head cover backwards.
  • Page 5 4. Remove the Water Pump Unit Drain the liquid in the tubes, unplug the 4 tubes, and place them back into the central hatch. Unscrew the fixing screws of the tube adapter and the water pump unit to remove the water pump unit and the tube adapter.
  • Page 6 System Installation 1. Install the Head Cover Buckle 2. Assemble the 4G Antenna Frame and Install the head cover buckles indicated in the List Granule Container Holder of Items to the antenna frame. Install the granule container holder into the 4G antenna frame in the direction of the arrows, and then put the 4G antenna frame back in its original place (6 pieces of M3*10 screws).
  • Page 7 5. Install the Spreader Install the spreader to the position shown in the figure below, tighten the 4 screws on top (M3*8) first and then the 2 at bottom (M3*20).
  • Page 8 6. Assemble the Granule Container Install the granule container to the position shown in the figure below (2 pieces of M3*8 screws at bottom and 2 pieces of M3*10 screws on two sides). Bottom Side 7. Install the Air Diffuser Install the air diffusers on the T-pipe: Align the triangle mark on the air diffuser with the dot on the T-pipe, and then rotate in the lock in a clockwise direction until the dot on the air diffuser aligns with the dot of the T-pipe.
  • Page 9 Replacing Rolling Feeder 1. Remove the old rolling feeder Unscrew the fixing screws of the rolling feeder cover, remove the rolling feeder cover and the V-shaped stopper, and hold and pull out the rolling feeder from left. Rolling feeder cover Right Left V-shaped stopper...
  • Page 10 c. Install the V-shaped stopper back to its original position. d. Install the rolling feeder cover back to its original position.

  • Page 11: Use Instructions

    Use Instructions JetSeed™ Granule Spreading System is compatible with the 2019 P30 Plant Protection UAS. 1. Firmware Upgrade Click on the portrait in the upper left corner of the Xplanet app -- Select "Device" (P-Series UAS) -- Click to “Check For Updates” and upgrade the firmware of the “Spreading System” to the latest version.
  • Page 12 2. Calibration Click on the device icon in the Xplanet app and select the "Spreading System" icon to enter the calibration page. Before calibration, please prepare a bag and an electronic spring scale. Spreader 1 Please select an operation Spreading System Operating Mode Stop Granule Container...
  • Page 13 How to calibrate: Step 1: Place the bag on the electronic scale and return to zero. Step 2: Fill the container with granules, raise the drone, and place the bag around the outlet of the air diffusers. Step 3: Click "Manage" on the Spreading System page, and add or delete “Granule type" as required. Step 4: Click “Calibrate”, the Spreading System will automatically discharge the granules.
  • Page 14 3. Manual Test Spreader 1 “Doser" and "Airflow volume” are displayed at the bottom of the Spreading System page. By controlling the rotation speed of the rolling feeder and fans, Spreading System the user can manually test whether the Spreading System is working properly.

  • Page 15: Technical Specifications

    4. To the maximum extent permitted by law, XAG shall not be liable for any losses caused by users' failure to use the product in accordance with this document and the “Product Manual/Operation Manual”.
  • Page 16 All information of this User Manual (including but not limited to any text description, illustrations, photos, methods and processes, etc.) belongs to XAG Co., Ltd. and is protected by copyright law. Without written authorization, no individual or institution is allowed to reproduce, extract, translate, distribute, or otherwise reproduce or quote any content...
